4.Place each drainlineaminimumof2--inchesup from
the wireform feetand tighten eachclamp boltin placeto
firmly securethe drinline(s)in place.The collarisomitted
forclarity.
5.Check forkinks and eliminatethem.Ifnecessary,
add appropriatesize 45° barbto barbconnectors.
INSTALLATIONPROCEDUREFORFLOOR DRAINSWITHFUNNELS
6.Mount the wireform supportinthe centerof the floordrain
funneland clampit’sfourlegsof the supportontothe drain
funnelsecurely.Ifnecessary,reform the legstofitand
attachfirmlytothe drainfunnel.
10.Check forkinks and eliminatethem.Ifnecessary,
add appropriatesize 45° barbto barbconnector(s).
7.The funneltakesthe place of the plastic splashguard
collar.The collarisunnecessaryand can be discarded.
8.The adjustableclampswill accomodate 1/2--inch,
3/4--inch,and 1--inchI.D.eithersoft or ridgid(hard)
PVCtubing.Squeezing the twotabstogetherthatare
located on the clamp--locking collarwill loosen a
tightened clamp.
9.Place each drainline 2--inchesup fromthe top of the
funneland tighten eachclamp boltin placetofirmly
securethe drainline(s)in place.
