Page1
-
LB-V
Covert Scouting Camera Instruction Manual
Watch the set-up video on our website at:
www.covertscoutingcameras.com
Page3
Table of Contents
Camera Button Control Diagram .............................5
Installing the Batteries .............................................7
Downloading the Mobile App ..................................8
Purchasing Your Plan ...............................................8
Setting up the Wireless Network ...........................10
Select and Link to a LC32 Camera .........................13
Base Unit Tips……….................................................15
4G Test Mode ........................................................16
Upload Delay Settings ............................................19
Max Number of Images Per Day.............................20
Troubleshooting ....................................................22
Tricks and Tips on Field Setup ...............................24
Warranty Policy .....................................................25
International Warranty Policy ...............................28
Page4
Congratulations on your purchase of the LB-V
Covert Scouting Camera! We truly value your
business and will continue to provide you top
quality customer service should you ever need help
with any of our products.
Check out our other products on our website at:
www.covertscoutingcameras.com
We hope you enjoy hassle free performance from
this quality product for years to come.
Page5
Camera Button Control Diagram:
4G antenna 2.4G 4G antenna point
Page6
SIM card
slot
SD card slot
Page7
Installing the Batteries:
Your LB-V can function short term on 4-AA
batteries. Improved battery life on 12-AA, but we
suggest you use 12-AA rechargeable batteries
paired with a solar panel to get the most out of your
camera’s battery life, especially if you do not use
the upload delay and connect more than 3 linked
cameras. Using Covert rechargeable NiMH,
2300mAh, AA batteries will extend the battery life
significantly when paired with a Covert Solar Panel.
DISCLAIMER: Do not use external power source
(Example: Solar Panel) with non-rechargeable AA
battery installed in camera.
Pay attention to the (+) or (-) molded into each
sleeve to determine if you insert the positive or
negative end into the sleeve first. Negative battery
terminal always contacts the spring.
Page8
Downloading the Mobile App:
Search "Covert Wireless" in your Google Play Store
or Apple App Store.
Accessing the Web Portal:
Open your web browser to:
www.covert-wireless.com
Purchasing Your Plan:
Follow these simple steps to activate or renew a
data plan:
1. Open your web browser to:
https://secure.covert-wireless.com
Figure 3
Figure 4
Page9
2. Select the type of plan you would like to
add and create your account.
3. Login and scroll down to “My Services and
Equipment”.
4. Enter the IMEI for your Covert LB-V found
on the inside white label of the camera and
on the outer packaging.
5. Enter your ICCID number found on the SIM
card included in the packaging of your
camera.
Page10
Installing the SD card and SIM card:
Now that you have activated your data plan, you
will need to install a SD card in the side of the base
unit, (Covert SD card recommended). Push in until
it clicks and release. To remove, repeat that
process, the card will pop out enough to remove.
You can use any SD card size up to 32 GB. We
recommend using any type of SDHC (not ultra or
high performance). The SIM card will push in until it
clicks and release, similar to the SD card. To
remove, repeat that process and the card will pop
out enough to remove. See the diagram on page 6
for reference.
You must have the SD card in the camera to be able
to turn the camera on and the SIM card to search
the network.
Setting Up the Wireless Network:
While finding the network connection, you will see
the words Searching Network in red on the screen.
