Creality HALOT-ONE PRO Bedienungsanleitung
3D Printer User Manual
V1.0
HALOT-ONE PRO
Create reality，achieve dreams
HALOT-ONE PRO
Dear Consumers,
Thank you for choosing our products.For the best experience,please read the instructions before operating the Printer. Our
teams are always ready to render you the best services. Please contact us via the phone number or e-mail address provided
at the end when you encounter any problem with the Printer.
For a better experience in using our product, you can also access how to use the printer in the following ways:
View the accompanied instructions and videos in the U disk.
Visit our official website www.creality.com to find relevant software/hardware information,contact details and operation and
maintenance instructions.
Firmware/Software Downloads and Upgrades
The product has access to both LycheeSlicer and CHITUBOX. WIFI printing and access to the Creative Cloud are under development.
Download the firmware and HALOT BOX slicing software at: https://www.creality.com
Download the CHITUBOX slicing software at: https://www.chitubox.com
Download the LycheeSlicer slicing software at: https://lychee.mango3d.io
Slicing software supported：
NOTES
1
2
3
4
5
6
7
8
9
10
Do not use the printer any way other than described to avoid personal injury or property damage.
Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment.
Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.
Please use recommended resin in case damage to machine.
Do not use any other power cable except the one supplied. Always use a grounded three-prong power outlet.
Please do not open the plastic cover during usage, otherwise the printing will be interrupted.
Do not wear cotton gloves when operating the printer. Such cloths may become tangled in the printers moving parts leading to burns, possible bodily injury, or printer damage.
Please wait after the print is finished. please wear gloves to take out the print tools.
Children under 10 years should not use the printer without supervision.
11
12
Tips Do not plug or unplug the power cord when power on.
Clean the printer frequently. Always turn the power off when cleaning, and wipe with a dry cloth to remove dust, adhered printing plastics or any other material off the frame,
guide rails, or wheels. Use glass cleaner or isopropyl alcohol to clean the print surface.
Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety
obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any.
Contents
Equipment Introduction 01-01
Equipment Parameters 02-02
Parts List 03-03
04-04
10-15
05-09
16-16
17-17
Assemble the 3D Printer
Use the 3D Printer
Troubleshooting
Print Method
Wiring Connection
18-18
FCC Statement
19-19
IC Cautiont
01
1. Equipment Introduction
Hexalobular socket screw
Leveling screw
Platform plate
Resin vat
Air filter
Power receptacle
Power switch
USB port
Touch screen
Limit sensor
9
7
8
10
11
Tray fixing screw
02
Model Name HALOT-ONE PRO
130*122*160mm (length*width * height)
2560*2400
0.051mm
1-4S/ layer
0.01-0.2mm
236*245*416mm
310*300*530mm
8.4KG
USB Disk，Creality Cloud App, Creality Cloud Online, WiFi Print
中文(简/繁)/ English/ Español/ Deutsche/ Français/ Pусский/ Português/ Italiano/ Türk/Nederlands/Polskie/日本語/한국어
Win7/Win8/Win 10 64bit, Mac system(32-bit is not supported)
Common rigid photosensitive ,Standard resin ,High hardness ,High toughness ,Dental model resin
Integral Light Source(wavelength 405nm)
100-240V~,50/60Hz
100WRated Power
Machine Size
Package Size
Net Weight
Compatible Resin
Machine Language
Gross Weight
Print Method
Slicing Software Operation System
Build Size
XY Axis Resolution
Touch Screen
Light Source Type
Rated Voltage
XY Axis Accuracy
Print Speed
Layer Thickness
Basic Parameters
5 inch touch screen
6.9KG
2. Equipment parameters
03
3. Parts Content List
Print platform x 1 Resin vat x 1 3D printer x 1
Tips: the above accessories are for reference only, please refer to the physical accessories!
Tool list
U disk x 1 Paper funnel x 2
power cable x 1
Release film x 1
Metal blade x 1
Screwdrivers x 1set
678
5Plastic blade x 1
4
Calibration card x 1
3
04
4. Assemble the 3D Printer
Machine body x 1
Plastic cover x 1
Note: put the plastic cover on the machine body and the installation is completed.
05
6. Interface Information
Note: Check whether the light source is normal The UI interfaceis only for reference , the actual UI.
Settings
06
7. Leveling Platform
Note: The platform has been leveled at the factory. If it needs leveling due to transportation or other reasons, please follow the steps below to
adjust the printing platform.
1. Raise the platform, loosen rubber screws on the left
and right sides of the resin vat, and take out the resin vat.
2. Loose the four screws on the connecting
plate on molding platform plate, attach
calibration card on the printing screen,
press Settings →Print Settings→ Z axis
movement →Leveling, Check whether the
platform fits evenly with the paper by
referring to the steps on Page 7.
3.After confirming that the calibration
card fit evenly, lock the four screws of the
platform.
