Crestron CNX-BIPAD8

Professional Audio Distribution Processor

Operations Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

All brand names, product names and trademarks are the property of their respective owners.

Crestron CNX-BIPAD8 Professional Audio Distribution Processor

Operations Guide – DOC. 8160A Contents •i

Contents

Professional Audio Distribution Processor: CNX-BIPAD8 1

Introduction 1

Features and Functions 1

Specifications 3

Physical Description 4

Industry Compliance 7

Setup 7

Network Wiring 7

Identity Code 8

Rack Mounting 9

Stacking 10

Hardware Hookup 10

Typical Room Configurations 11

Signal Distribution to More than Eight Rooms 12

Expanded Distribution of Local Audio Sources 13

Programming Software 15

Earliest Version Software Requirements for the PC 15

Programming with SIMPL Windows 15

Uploading and Upgrading 19

Communication Settings 19

Uploading a SIMPL Windows Program 21

Firmware Upgrade 23

Problem Solving 24

Troubleshooting 24

Further Inquiries 25

Future Updates 25

Return and Warranty Policies 26

Merchandise Returns / Repair Service 26

CRESTRON Limited Warranty 26

Crestron CNX-BIPAD8 Professional Audio Distribution Processor

Operations Guide – DOC. 8160A Professional Audio Distribution Processor: CNX-BIPAD8 •1

Professional Audio Distribution

Processor: CNX-BIPAD8

Introduction

Features and Functions

The Crestron Bi-Directional Professional Audio Distribution Processor,

CNX-BIPAD8, is a second-generation product in Crestron’s audio distribution

product line. The unit is an 8-channel preamplifier that has all of the capabilities of

the CNX-PAD8A product plus the ability to route balanced line audio to and from

remote locations utilizing low cost CAT5 cables and Crestron’s CNXRMCLV,

C2N-DAP8RC, or C2N-DAP8 room boxes. The Cresnet system supplies power to

the unit.

Functional Summary

The CNX-BIPAD8 controls the selection of up to 24 stereo audio sources, and then

distributes the audio to up to eight room amplifiers or Crestron room control boxes.

The unit’s sixteen stereo head end audio inputs are RCA type connectors with loop

through. These inputs plus the eight additional CAT5 stereo inputs pass through a

stereo 24x8 cross-point switch. Each output of the cross-point switch goes to a

differential driver to the CAT5 connectors. The same cross-point outputs also go to

the CNX-BIPAD8 preamplifiers and mute relays before they go to the RCA output

connectors. The cross point switch makes it possible to route any of the 24 audio

• 16 line level/unbalanced stereo source inputs (L/R audio) plus

loop-through

• 8 CAT5 bi-directional inputs and outputs for professional-grade

balanced audio to/from remote locations, using CNXRMCLV or

C2N-DAP8/C2N-DAP8RC local room boxes

• 8 RCA outputs with built-in volume/tone preamplifiers and mute

relays

• Built-in 24x8 stereo crosspoint switch

• Input level compensation adjustments

• Daisy-chaining for distribution up to 32 Rooms

Professional Audio Distribution Processor Crestron CNX-BIPAD8

2 •Professional Audio Distribution Processor: CNX-BIPAD8 Operations Guide - DOC. 8160A

inputs to any of the eight outputs. The following simplified diagram illustrates the

internal signal routing.

Simplified Audio Signal Routing

Up to four units can be daisy-chained via the RCA loop-through connectors to

extend distribution to up to 32 rooms.

The CNX-BIPAD8 preamplifier circuits provide the following controls for each of

the eight RCA outputs:

• Loudness — Activates the loudness function, commonly found on stereo

amplifiers, to boost low- and high-frequency signals at low volume settings

to compensate for natural hearing limitations at lower volume levels.

• Volume — Sets minimum and maximum volume levels and controls the

relative audio level within that range.

• Balance, Bass, and Treble — Specifies levels for these settings relative to a

50% neutral or balanced signal.

• Mono — Changes the audio setting from stereo to mono (monaural) mode.

• Compensation — Source gain compensation that normalizes input levels

from different sources; for example, setting the volume range of a VCR

equal to that of a CD player.

• Mute — Electronically attenuates signal.

• On/Off — Activates electronic relays that cut sound to a room.

Optional source and numeric keypads or any other Crestron network panel or

touchpanel may be added to the individual rooms to interface with the CNX-

BIPAD8. For more information regarding such devices, refer to the Downloads |

Product Manuals section of the Crestron website (www.crestron.com).

NOTE: Unit does not ship with default parameters for adjustable values (bass,

treble, or compensation). These values must be set in the program for the unit to

operate correctly.

Crestron CNX-BIPAD8 Professional Audio Distribution Processor

Operations Guide – DOC. 8160A Professional Audio Distribution Processor: CNX-BIPAD8 •3

Specifications

Specifications for the CNX-BIPAD8 are listed in the following table.

CNX-BIPAD8 Specifications

SPECIFICATION DETAILS

Power Requirements 20 Watts (0.83 Amp @ 24 VDC)

Default NET ID 44

Control System Update Files 1, 2, 3

2-Series Control System Update

File

CNMSX-AV/Pro Update File

CNRACKX/-DP Update File

ST-CP Update File

CEN/CN-TVAV Update File

Version 2.004.CUZ or later

Version 5.12.63X.UPZ or later

Version 5.12.63W.UPZ or later

Version 4.02.4S.UPZ or later

Version 5.12.63V.UPZ or later

CNX-BIPAD8 Firmware Bipad-22.upg

RCA input ports (labeled 1 – 16) RCA jacks – Sixteen sets of four: two for left and right

audio; two for stereo loop-through.

RCA output ports (labeled ROOMS) RCA jacks – Eight pairs for left and right preamplified (line

level) audio for corresponding room power amplifiers.

CAT5 I/O ports (labeled ROOMS) RJ-45 Jacks – Eight shielded jacks for balanced line

audio to/from remote locations; one CAT5 stereo input

and output per connector.

Tone specifications (per channel) Flatness (8 to 60 KHz flat mode) ±0.2 dB

Bass gain range (100 Hz) ±12 dB

Bass step size (100 Hz) 2 dB

Treble gain range (10 KHz) ±12 dB

Treble step size (10 KHz) 2 dB

Preamp specifications (per channel) Input impedance 47K Ohms

Total harmonic distortion (THD) <0.02%

S/N ratio >100 dB

Maximum input level (flat mode) 3.2 Vrms

Maximum output level 2.5 Vrms

Channel separation >90 dB

Gain range (excluding mute) -80 dB to +20 dB

Volume steps 100 (1 dB/step)

Mute > 120 dB (relay)

100 dB (electronic mute)

Rack space required 2U high, 1U wide

Environmental temperature 41° to 122°F (5° to 50°C)

Humidity 10% to 90% RH (non-condensing)

Dimensions Height: 3.47 in (8.81 cm)

Width: 17.10 in (43.43 cm)

Depth: 8.44 in (21.44 cm)

Weight 6.2 lb (2.8 kg)

1. The latest versions can be obtained from the Downloads | Software Updates section of the Crestron

website (www.crestron.com). Refer to NOTE on the next page.

2. Crestron 2-Series control systems include the AV2, CP2, CP2E, MP2, MP2E, PAC2, PRO2, and

RACK2.

3. CNX update files are required for either CNMSX-AV/Pro or CNRACKX/-DP. Filenames for CNX

update files have a UPZ extension and are in one EXE or zipped UPZ file. To avoid program problems,

make certain you are using the update file with the correct suffix letter (e.g., S, V, W, X).

Professional Audio Distribution Processor Crestron CNX-BIPAD8

4 •Professional Audio Distribution Processor: CNX-BIPAD8 Operations Guide - DOC. 8160A

NOTE: Outputs from the RCA and RJ-45 CAT5 connectors (ROOMS 1-8) are the

same signals. The RCA outputs first pass through preamplifier and tone/volume

control circuits; the balanced outputs from the CAT5 connectors are unprocessed.

NOTE: Crestron software and any files on the website are for Authorized Crestron

dealers and Crestron Authorized Independent Programmers (CAIP) only. New users

may be required to register to obtain access to certain areas of the site (including the

FTP site).

Physical Description

The CNX-BIPAD8 is housed in a black enclosure with labeling on the front and rear

panels. Ten LEDs on the front panel indicate the unit’s current status. All

connections are made to the back of the unit. Refer to the following illustrations of

the front and rear panels and the physical views on the next page.

Two mounting ears are provided for rack mounting, and four square rubber feet are

supplied for stability and to prevent slippage in tabletop placement or stacking

configurations.

CNX-BIPAD8 Front Panel

CNX-BIPAD8 Rear Panel

Crestron CNX-BIPAD8 Professional Audio Distribution Processor

Operations Guide – DOC. 8160A Professional Audio Distribution Processor: CNX-BIPAD8 •5

CNX-BIPAD8 Physical Views

3.310 in

(8.407 cm)

3.480 in (8.84 cm)

with Optional

Feet Mounted

3.469 in

(8.811 cm)

19.000 in

(48.26 cm)

17.100 in

(43.43 cm)

8.440 in

(21.437 cm)

16.910 in

(42.951 cm)

ROOMS

42 53 8761

NET

POWER

P R O F E S S I O N A L A U D I O D I S T R I B U T I O N P R O C E S S O R

CRESTRON

CNX-BIPAD8

8.250 in

(20.955 cm)

RIGHT

LEFT

1234567

RIGHT

LEFT

910 1311 12 14 15

RIGHT

LEFT

1 2 3 4 6 7 8

ROOMS

SETUP

24 Y Z G

NET

CRESTRON ELECTRONICS INC. ROCKLEIGH N.J. 07674 USA

CNX-BIPAD8 Ports

All connections to the CNX-BIPAD8 are made through the ports on the rear panel.

Refer to the illustrations and descriptions, which follow.

NET

The 4-pin network connector is used to connect the CNX-BIPAD8 to the Cresnet

system. Data and power for the CNX-BIPAD8 is provided via the connection. Refer

to “Network Wiring” on page 7.

24 Y Z G

NET

Professional Audio Distribution Processor Crestron CNX-BIPAD8

6 •Professional Audio Distribution Processor: CNX-BIPAD8 Operations Guide - DOC. 8160A

ROOMS

The eight, shielded RJ-45 connectors provide for balanced line audio to/from remote

locations in the facility; one CAT5 stereo input and output per connector. Signal

connections for the jacks are given in the following table.

Pin # Signal

1 Audio In L +

2 Audio In L -

3 Audio In R +

4 Audio Out L -

5 Audio Out L +

6 Audio In R -

7 Audio Out R +

8 Audio Out R -

NOTE: For additional information on audio/video connections over CAT5, refer to

the latest version of the Crestron CAT5 Wiring Reference Guide (Doc. 6137) which

is available from the Downloads | Product Manuals section of the Crestron website

(www.crestron.com).

The eight pairs of RCA jacks output pre-amplified (line-level) and volume/tone

processed audio to corresponding room power amplifiers. Each room output contains

left and right audio channels. (These are the same signals as the unprocessed outputs

from the CAT5 connectors.)

1 – 16 (Source Connectors)

The sixteen sets of four RCA jacks connect independent audio sources to the CNX-

BIPAD8. Of each set, two of the connectors are used for left and right audio

channels; the other two are parallel stereo loop-throughs.

(Chassis Ground)

Use this chassis screw to connect the audio source(s) common ground(s) to the

CNX-BIPAD8.

Indicators

Ten LED indicators on the front panel indicate the unit’s current status.

CNX-BIPAD8 Indicators

ROOMS

42 53 8761

NET

PWR

P R O F E S S I O N A L A U D I O D I S T R I B U T I O N P R O C E S S O R

CRESTRON

CNX-BIPAD8

PWR (Power)

This LED illuminates when 24 volts DC is supplied to the CNX-PAD8.

JACK, REAR VIEW

(TAB POSITION DOWN)

Pin 1

Inhaltsverzeichnis

Andere Crestron Computerhardware Handbücher

Crestron

Crestron 3 Series Bedienungsanleitung

Crestron

Crestron C2IR-8 Anleitung zur Verwendung

Crestron

Crestron CNXIR-8 Bedienungsanleitung

Crestron

Crestron DIN-AP3 Original Betriebsanleitung

Crestron

Crestron DSP-860 Maßzeichnung

Crestron

Crestron CNXRY-16 Bedienungsanleitung

Crestron

Crestron DigitalMedia DMC-CPU3 Bedienungsanleitung

Crestron

Crestron CNXAO-8 Bedienungsanleitung

Crestron

Crestron C2VEQ-4 Bedienungsanleitung

Crestron

Crestron CNXIO-16 Bedienungsanleitung

Crestron

Crestron CNX-PAD8A Bedienungsanleitung

Crestron

Crestron DIN Rail Control Processor DIN-AP2 Anleitung zur Verwendung

Crestron

Crestron TPS-GA-TPI Bedienungsanleitung

Crestron

Crestron IRP2 Bedienungsanleitung

Crestron

Crestron 4 Series Bedienungsanleitung

Crestron

Crestron CLS-EXP-DIMU Bedienungsanleitung

Crestron

Crestron C2N-IO Bedienungsanleitung

Crestron

Crestron DIN-AP3MEX Original Betriebsanleitung

Crestron

Crestron CNXVTC-3 Bedienungsanleitung

Crestron

Crestron 3 Series Bedienungsanleitung

Crestron

Crestron ST-CP Bedienungsanleitung

Crestron

Crestron CNXRY-8 Bedienungsanleitung

Crestron

Crestron DigitalMedia DMC-VID4 Bedienungsanleitung

Crestron

Crestron UPX-2 Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
