Crestron ST-PK Programming Kit

Operations Guide - DOC. 5662C Contents •• i

Contents

STS Programming Kit: ST-PK 1

Description.................................................................................................................................................1

Kit Description...........................................................................................................................1

SmarTouch™ STS Description...............................................................................................1

Software......................................................................................................................................2

Leading Specifications.............................................................................................................3

Setup...........................................................................................................................................................4

STS Equipment..........................................................................................................................4

Applying Power.........................................................................................................................6

Identity Code.............................................................................................................................6

Preparing the System for Programming..................................................................................7

Preparing the System for Operation.......................................................................................8

Problem Solving.........................................................................................................................................9

Troubleshooting........................................................................................................................9

Further Inquiries......................................................................................................................11

Return and Warranty Policies...............................................................................................................12

Merchandise Returns / Repair Service.................................................................................12

CRESTRON Limited Warranty..............................................................................................12

Crestron ST-PK Programming Kit

Operations Guide - DOC. 5662C STS Programming Kit: ST-PK •• 1

STS Programming Kit: ST-PK

Description

Kit Description

The ST-PK is the Crestron programming kit for the SmarTouch STS. The kit provides

the necessary cables, adapters, and software to successfully design and upload

unique touchpanel projects. Components of the kit are clearly listed, refer to “STS

Equipment” on page 4. The ST-PK can be used time and time again to revise current

touchpanel projects of the SmarTouch STS or to create new ones.

SmarTouch™ STS Description

The SmarTouch STS is a Crestron radio-frequency (RF) wireless control system that

is designed for numerous applications ranging from the boardroom to complete home

automation. Electronic devices or subsystems can be controlled from anywhere via

the wireless user interface. Users are no longer tethered by a wired control panel or

limited to infrared line-of-sight control, as with most ordinary wireless controllers.

There are six SmarTouch STS configurations available. All configurations are

functionally identical except for the touchpanel component which can be grayscale or

color, the type of input power required which can be 120V or 220V, and the

communication frequency. The table shown below provides a breakdown of

SmarTouch STS configurations. For the purpose of this Operations Guide, the term

“SmarTouch STS” is used to describe a SmarTouch configuration and its

components.

Table of SmarTouch Configurations

SMARTOUCH STS

CONFIGURATION DISPLAY POWER

(VOLTAGE) TRANSMISSION

FREQUENCY

STS

Grayscale

120V AC

433.92 MHz

STS-C Color 120V AC 433.92 MHz

STSI

Grayscale

220V AC

433.92 MHz

STSI-C Color 220V AC 433.92 MHz

STSI/UK

Grayscale

220V AC

418 MHz

STSI-C/UK Color 220V AC 418 MHz

Programming Kit Crestron ST-PK

2•• STS Programming Kit: ST-PK Operations Guide - DOC. 5662C

This RF system is primarily comprised of two units, a touchpanel and the control

processor. Refer to the system diagram shown below. The touchpanel is a LCD

interface that communicates via RF signals to the control processor, which is

discretely placed. The control processor interfaces with the controllable electronic

equipment in the system to complete commands without delay.

SmarTouch STS Diagram

RF SIGNALS

CONTROLLED DEVICES

CONTROL

PROCESSOR

TOUCHPANEL

IR/RS-232

INTERFACE

Features of the SmarTouch STS wireless control system include:

•high-clarity LCD touchpanel displays choice of custom icons and

graphics.

•touchpanel case is lightweight and contoured and easily held in one

hand.

•advanced Crestron RF technology allows complete freedom of

movement -up to 500 feet through walls, indoors or outside.

•touchpanel power options include rechargeable power pack or AC

power supply.

•control processor includes Cresnet network port for expansion.

•exclusive Crestron/Windowssoftware gives you system programming

options (use the included templates or create fully customized

environments).

Software

NOTE: Use the provided software, VisionTools™ Pro to design user interface pages

for the SmarTouch STS. The latest revision of the Crestron Database is available from

the Software Downloads page (Cresdb Library) of the Crestron website

(www.crestron.com).

Crestron ST-PK Programming Kit

Operations Guide - DOC. 5662C STS Programming Kit: ST-PK •• 3

VisionTools™ Pro (VT Pro) is a Crestron design and programming Windows-based

software for the SmarTouch STS. Unlimited control screen variations incorporating

two and three-dimensional graphics and text are possible with VT Pro. A set of pages

which make up a project can be designed for each STS application. Each touchpanel

can be organized with the ideal, color-oriented control environment with custom

control graphics: icons, two and three-dimensional buttons, and floor plans. The

project is uploaded to the touchpanel and programmed into the flash PROM. The

touchpanel uses the programmed project until another is uploaded from the PC. The

PC may be disconnected from the control processor except during reprogramming.

Use Crestron’s STS Wizard to reduce to project development phase to just nine

steps. This “drag-n-drop” Windowssoftware assures thorough system

configuration. For a simple system, set up takes just a few minutes. Touchpanel

templates may be modified for a more custom system.

For additional software information, refer to the help file provided with the software.

A SmarTouch tutorial is provided as a guide for the novice programmer. Lotus

ScreenCam movies for the Wizard are also available from the latest version of the

Crestron ControlCD. Let these movies demonstrate the simplicity of STS Wizard.

Learn how to use and get the most from Crestron software.

Leading Specifications

The table below provides a summary of leading specifications for the SmarTouch STS

and its primary components. Dimensions and weight are rounded to the nearest

hundredth unit.

Leading Specifications of the SmarTouch STS

SPECIFICATION

DETAILS

Touchpanel Power Options ST-BTP: Rechargeable NiCad power pack

(Fully charged battery, 2800 mAh capacity,

can last up to 10 days depending on

touchpanel settings and usage.)

AC (domestic)

: 12V DC, 1.0A, 120V Input

(P/N PW-1210 or equivalent)

AC (internat'l)

: 12V DC, 1.0A, 230V Input

(P/N PWI-1210 or equivalent)

ST-DS: Docking Station provides power as

long as it is receiving power from its external

AC power pack.

Control Processor Power Options

AC (domestic):

12V DC, 0.5A, 120V Input

(P/N PW-1205 or equivalent)

AC (internat'l)

: 12V DC, 1.0A, 230V Input

(P/N PWI-1210 or equivalent)

VisionTools™ Pro Version 1.1.3 or later

Crestron Database Version 11.7.211 or later

Touchpanel Dimensions & Weight

(without rechargeable power pack and

AC power pack)

Height: 5.70 in (14.48 cm)

Width: 8.75 in (22.23 cm)

Depth: 3.33 in (8.45 cm)

Weight: 1.85 lb (0.84 kg)

Control Processor Dimensions &

Weight (without AC power pack) Height: 1.70 in (4.32 cm)

Width: 7.07 in (17.95 cm)

Depth: 6.32 in (16.06 cm)

Weight: 1.90 lb (0.86 kg)

Programming Kit Crestron ST-PK

4•• STS Programming Kit: ST-PK Operations Guide - DOC. 5662C

As of the date of manufacture, the unit has been tested and found to comply with

specifications for CE marking.

NOTE: Equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

The equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

nReorient or relocate the receiving antenna.

nIncrease the separation between the equipment and receiver.

nConnect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

nConsult the dealer or an experienced radio/TV technician for help.

Setup

STS Equipment

The items required to program STS equipment, listed below, are provided as part of

the programming kit (ST-PK). These kit items can be used time and time again to

program or reprogram each system.

STS Kit Equipment

EQUIPMENT PART

NUMBER DESCRIPTION

Software SAXD2535-1AY1 Software package for creating touch screen

programs.

Programming

Cable Assembly 15710 Provides connection between touchpanel and

control processor. Used during programming

only.

RJ11 Cable

Assembly 15717 Provides connection between control processor

and RJ11/DB9F adapter. Used during

programming only.

RJ11 to DB9F

Adapter 15556-1B Provides connection between RJ11 cable

assembly and a PC. Used during programming

only.

Crestron ST-PK Programming Kit

Operations Guide - DOC. 5662C STS Programming Kit: ST-PK •• 5

Due to variations in installation requirements and overall application, not all possible

peripheral pieces of equipment are supplied with the STS system. The next table in

this section, shown below, provides a list of all equipment that is provided with the

STS system. Except for the STIRP, all products listed in the part number column ship

one item per system.

STS System

EQUIPMENT PART

NUMBER SHIPPED WITH DESCRIPTION

Touchpanel ST-1550 STS or STSI Provides user interface.

ST-1550C STS-C or STSI-C

ST-1550/UK STSI/UK

ST-1550C/UK STSI-C/UK

Control

ST-CP

STS, STS-C, STSI,

Provides commands to

Processor or STSI-C system A/V equipment.

ST-CP/UK

STSI/UK or STSI-C/UK

Rechargeable

Power Pack ST-BTP All Systems Possible power source

for touchpanel.

Docking

Station ST-DS All Systems Provides fast or trickle

charge to ST-BTP.

Infrared Probe

STIRP

(2 per System) All Systems Delivers commands

from control processor.

External AC PW-1205 STS or STS-C Provides power to

Power Pack PWI-1210 STSI, STSI-C, STSI/UK or touchpanel and control

STSI-C/UK processor.

PW-1215 STS or STS-C Provides power

PWI-1215 STSI, STSI-C, STSI/UK or

STSI-C/UK to ST-DS.

The next table in this section, shown below and on the next page, lists some

peripheral equipment that can be purchased separately for the STS system. The part

number for each item (except for the ST-RMK) is supplied with the appropriate

domestic or international external AC power pack. Keep in mind that all the individual

items of the system (listed in the STS System table, above) can be purchased

separately as well.

STS Peripheral Equipment

EQUIPMENT

PART

NUMBER DESCRIPTION

Rack Mount ST-RMK Provides rack space for STS units.

Input/Output

Expansion

Module

ST-IO Provides isolated relays/digital input.

Volume

Control

Module

ST-VC Provides volume controls - 3 independent, professional

quality VOLUME/TONE control, balanced or unbalanced

I/O.

Current

Sensor ST-CS Provides dual capacity for measuring the average

current of each half cycle of an AC load.

Programming Kit Crestron ST-PK

6•• STS Programming Kit: ST-PK Operations Guide - DOC. 5662C

STS Peripheral Equipment (Continued)

EQUIPMENT

PART

NUMBER DESCRIPTION

RS-232/422

COM Module

ST-COM Provides two independent bidirectional serial ports that

support RS-232/422-based communication.

Lutron

Interface

ST-LT Provides a direct interface to Lutron's GRAFIK EYE.

Power

Control

Module

ST-PC Provides two switchable AC outlets.

Video Sensor ST-VS Detects the presence of a video signal coming out of the

baseband video port for up to four independent sources.

IR/Serial

Learner CNXLIR Creates driver files that can be added to the User

Database of the SmarTouch software package.

Applying Power

The touchpanel can be powered via an external AC power pack, while resting in the

ST-DS, or via the ST-BTP. Each of these supplied items have their own Operations

Guides which details proper usage. Refer to the table below for the required document

number. This table does not account for the latest revision letter of each document.

Devices that Power the SmarTouch STS Touchpanel

POWER OPTION NOMENCLATURE DOCUMENT

NUMBER

Domestic External AC Power Pack

PW-1210

5762

International External AC Power Pack PWI-1210 5763

Docking Station

ST-DS

5738

Battery Pack ST-BTP 5746

The control processor can only be powered via the appropriate external AC power

pack. Refer to the table below for power pack’s document number. Again, the table

does not account for the latest revision letter of each document.

SmarTouch STS Control Processor External AC Power Packs

POWER OPTION NOMENCLATURE DOCUMENT

NUMBER

Domestic External AC Power Pack

PW-1205

5759

International External AC Power Pack PWI-1210 5763

Identity Code

All Crestron expansion modules and touchpanels within the Cresnet system require a

unique identity code (NET ID). These codes are recognized by a two-digit

hexadecimal number from 03 to FE. Matching NET IDs between the expansion

modules and touchpanels with the program is required if data is to be successfully

transferred or new touchpanel screens are to be loaded.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Crestron Netzwerk-Hardware Handbücher

Crestron

Crestron QM-FTMC Kurzanleitung

Crestron

Crestron STIRP Bedienungsanleitung

Crestron

Crestron AV2 Bedienungsanleitung

Crestron

Crestron C2N-NPA8 Bedienungsanleitung

Crestron

Crestron HZA-PWR-15A Bedienungsanleitung

Crestron

Crestron 2 Channel Inductor Module CLX-2IND Bedienungsanleitung

Crestron

Crestron Zūm Bedienungsanleitung

Crestron

Crestron QM-WMC Kurzanleitung

Crestron

Crestron ST-COM Bedienungsanleitung

Crestron

Crestron 8 Channel Dimmer Module CLX-2DIM8 Bedienungsanleitung

Crestron

Crestron RACK2 Bedienungsanleitung

Crestron

Crestron C2N-HBLOCK Bedienungsanleitung

Crestron

Crestron CNXLIR Bedienungsanleitung

Crestron

Crestron Zum ZUMMESH-NETBRIDGE Bedienungsanleitung

Crestron

Crestron DigitalMedia DM-RPP-K24 Bedienungsanleitung

Crestron

Crestron Network Device PWE-4803RU Bedienungsanleitung

Crestron

Crestron QM-IEM Bedienungsanleitung

Crestron

Crestron RS-232/42 Bedienungsanleitung

Crestron

Crestron 4 Channel Dimmer Module CLX-1DIM4 Bedienungsanleitung

Crestron

Crestron ST-MB Bedienungsanleitung

Crestron

Crestron 8 Channel Dimmer Module CLX-1DIM8 Bedienungsanleitung

Crestron

Crestron QM-WMIC Kurzanleitung

Crestron

Crestron CNXIRP Bedienungsanleitung

Crestron

Crestron CAEN-CK-7x1 Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
