CryptoBox 550HDC Bedienungsanleitung

FOR

RECORDING

& PLAYBACK

PVR TIMESHIFT

FOR AUTOMATIC

PAUSE & PLAY

ECO

Low power

consumption

in Stand By

ETHERNET

NETWORK

CONNECTION

1x SLOT FOR

SMARTCARD

1xCX

1x SLOT FOR

CAM MODULES

1xCI RS232

FOR

ADVANCED USERS

400MHz

WiFi

SUPPORT *WITH

RECOMMENDED

USB WiFi DONGLE

VFD

DISPLAY

*ONLY FOR

550HD

FOR

MULTIMEDIA

AND MORE...

2xUSB optical

S/PDIF

User Manual

HD Digital Cable Receiver

CryptoBox 550HDC

Content

Safety Precaution ....................................................................3

1. Reference ..................................................................................................4

1.1 General Features .............................................................................4

1.2 Accessories .....................................................................................4

2. Product Overview.....................................................................................6

2.1 Front Panel......................................................................................6

2.2 Rear Panel.......................................................................................7

2.3 Remote Control Unit (RCU)...........................................................8

3. Connection with Other Device ...............................................................10

3.1 Connecting to TV .........................................................................10

3.2 Connecting the CABLE................................................................11

4. Installation ..............................................................................................12

4.1 Powering On.................................................................................12

4.2 Manual search...............................................................................12

4.3 Auto Search ..................................................................................13

4.4 Blind Search .................................................................................13

4.5 Factory Default.............................................................................13

5. Channel Manager....................................................................................14

5.1 Edit Channel .................................................................................14

5.2 Edit Favorite .................................................................................16

5.3 Sort Channels................................................................................16

5.4 User Channel List .........................................................................17

6. Settings ...................................................................................................17

6.1 System Settings.............................................................................17

6.2 OSD Setup ....................................................................................19

6.3 Parental control.............................................................................19

6.4 Times ............................................................................................19

6.5 CA Menu ......................................................................................22

6.6 CI Menu........................................................................................22

6.7 Connecting to the LAN.................................................................23

6.8 USB Update..................................................................................24

6.9 Network Update............................................................................24

6.10 About STB..................................................................................24

7. X-tras ......................................................................................................25

7.1 Calendar........................................................................................25

7.2 Games ...........................................................................................25

7.3 Network Apps...............................................................................25

8. Multimedia..............................................................................................26

8.1 Basic Operations...........................................................................27

8.2 Setting...........................................................................................28

8.3 Play Files ......................................................................................29

9. Basic Operation ......................................................................................32

9.1 Audio ............................................................................................32

9.2 EPG...............................................................................................33

9.3 Subtitle..........................................................................................34

9.4Teletext ..........................................................................................34

9.5 Find channel .................................................................................35

9.6 Program Information ....................................................................35

10. Channel List..........................................................................................36

10.1 OK List .......................................................................................36

10.2 Favorite List................................................................................37

11. USB Control .........................................................................................38

11.1 Recording and Timeshift ............................................................38

11.2 PVR List .....................................................................................39

12. Additional Information.........................................................................39

12.1 Trouble Shooting ........................................................................39



Safety Precaution

This STB has been designed and manufactured to satisfy the international safety

standards. Please read the following safety precautions carefully before operating

this receiver.

Main Supply:

Before operating, please check the units operating voltage is 90~250V AC 50/60Hz.

Overload:

Do not overload a wall outlet, extension cord or adapter, neither use damaged power

cord or touch it with wet hand as this may result in electric shock.

Liquid:

The receiver shall not be exposed to dripping or splashing water, and that no objects

filled with liquids, such as base, shall be placed on the apparatus.

Ventilation:

Keep the slots on top of the receiver uncover to allow sufficient airflow to the unit. Do

not put the receiver on soft furnishings or carpets. Do not expose the receiver to

direct light or do not place it near a heater or in humid conditions. Do not stack other

electronic equipments on top of the receiver.

Cleaning:

Plug out the receiver from the wall outlet before cleaning. Clean the receiver by a

soft cloth or mild solution of washing-up liquid (no solvents).

Connection:

Disconnect the receiver from the mains when you connect it to satellite LNB or

disconnect it from LNB. Failure would possibly cause damage to the LNB.

Location:

Put the receiver indoor in order to avoid lightening, raining or sunlight.

Uncover:

Do not remove the cover, to reduce the risk of electric shock. Contact qualified and

licensed service personnel to repair the receiver, or contact your dealer.

1. Reference

1.1 General Features

DVB-C Compliant (MPEG-II/ MPEG-IV/ H.264)

Sensitive Tuner with Loop-Through

PAL/NTSC Conversion

True full Color (32 bits) on screen display (OSD)

Storing memory: 4000 transponders and 6100 channels

8 favorite group and parental lock supported

Multi-language menu supported

Multi-language audio supported

Multi-language DVB Subtitle output

7 days Electronic Program Guide (EPG)

Teletext output through VBI and OSD

USB 2.0 Interface

CI module Supported

Support many network functions

1.2 Accessories

l Users manual

l Remote Control Unit

l Batteries

Figure 1.Accessories

2. Product Overview

2.1 Front Panel

Figure 2. Front Panel

1. Power LED

Power indicator.

2. Display

It displays channel information. In standby mode it displays local time.

3. Power button

Switch between operation and standby modes.

4. CH+/CH-

Change channel in viewing mode and move the cursor up/down in menu mode.

2.2 Rear Panel

Figure 3. Rear Panel

1. LAN

Connect to the internet using an Ethernet cable.

2. S/PDIF

Digital Audio output (Optical).

3. RS232

Connect to the computer using a serial line.

4. TV SCART

Connect to the TV using a Scart cable.

5. HDMI

Connect to the TV using an HDMI cable.

6. USB2.0

One USB 2.0 Host Port.

7. CABLE IN

Connect the cable.

8. CABLE OUT

Connect another receiver.

9. ON/OFF

Power on/off.

2.3 Remote Control Unit (RCU)

You can control this receiver by this remote controller with full function.

1. POWER: Switch between operation and standby

modes.

2. F1: Accessorial function.

3. SHIFT: Enable/Disable timeshift.

4. MUTE: Mute audio.

5. I I : Pause/Time shift.

6. ◄◄: Fast rewind.

7. ►►:Fast forward.

8. ●: Record.

9. ►: Play.

10. ■：stop recording and playing.

11. MENU: Activate main menu.

12. EXIT: Exit current menu step by step.

13. ▲/▼/◄/►:Navigates through the Menus

14. OK: Confirm

15. RELOAD: Switch to the previous viewed channel.

16.EPG (Electronic Program Guide): Display the

program guide..

17. VOL+/VOL- : Change volume in viewing mode.

18. CH+/CH-: Change program.

19. INFO: Display the program information.

20. FAV: Display favorite channel list you set before.

21. NUMERIC KEY (0~9): Enter a TV/radio channel

number or menu option number.

22. PAGE-/PAGE+: Page up/down on menu or channel

list.

23. MEDIA : Access to the USB menu.

24. SAT: No function.

Figure 4. Remote Control

Unit
