Cybex Treadmill

Product Number 770T-CT

Owner’s Manual

Cardiovascular Systems

Part Number LT-22983-4 D

www.cybexintl.com

Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc. Safety Sentry™ is a registered trademark of Cybex

International, Inc. Polar®is a registered trademark of Polar Electro Inc.

DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to

revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such

revisions or changes.

10 Trotter Drive Medway, MA 02053 • 888-462-9239 • 508-533-4300 • FAX 508-533-5183

www.cybexintl.com • [email protected] • LT-22983-4 D

Cybex Treadmill

Product Number 770T-CT

Owner’s Manual

Cardiovascular Systems

Part Number LT-22983-4 D

Cybex 770T-CT Treadmill Owner’s Manual

Table of Contents

FCC Compliance Information ..........7

Safety

Important Voltage Information..........9

Grounding Instructions ...............9

Important Safety Instructions .........10

User Safety Precautions.............10

Facility Safety Precautions ...........11

Warning Decals....................12

Caution Decals ....................15

Emergency Stop Key (e-stop).........15

CSAFE Port ......................17

Assembly and Setup

Warnings/Cautions .................19

Choosing and Preparing a Site........19

Electrical Power Requirements........20

Assembling the Treadmill ............20

Setup ...........................33

Testing the Treadmill Operation .......35

Operation

Terms Used.......................37

User Control Symbols Used ..........38

CardioTouch Symbols Used ..........39

CardioTouch Symbols Used (continued) 40

Console Display ...................41

CardioTouch Screen and User Controls. 42

Quick Operation Guide..............43

Detailed Operation Guide............44

Stopping the Treadmill ..............46

Safety Sentry .....................47

Control During Operation ............47

Data Readouts ....................48

Displaying Heart Rate...............48

Heart Rate Zone...................49

Meaning of % Grade................50

Preprogrammed Workouts ...........50

iPod Functions ....................51

Preventive Maintenance

Warnings.........................53

Regular Maintenance Activities........53

Cleaning Your Treadmill .............53

Running Belt Maintenance ...........55

Other Preventive Maintenance........57

Service Schedule ..................58

Appendix A - Technical Specica-

tions

Specications .....................65

Cybex 770T-CT Treadmill Owner’s Manual

FCC Compliance Information

WARNING: Changes or modications to this unit not expressly approved by the

party responsible for compliance could void the user’s authority to

operate the equipment.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

Modications not expressly approved by the manufacturer could void the user’s authority to operate

the equipment under FCC rules

Cybex 770T-CT Treadmill Owner’s Manual

Safety

IMPORTANT: Read all instructions and warnings before using the treadmill.

Important Voltage Information

Before plugging the power cord into an electrical outlet, verify that the voltage requirements for the

site match the voltage of the treadmill that has been received. The power requirements for the Cybex

770T-CT Treadmill include a grounded, dedicated circuit, rated for one of the following:

100 VAC, 50/60 Hz, 20A•

115 VAC, 60 Hz, 20A•

208 VAC, 60 Hz, 15A•

220 VAC, 60 Hz, 15A•

230 VAC, 50 Hz, 13A, UK•

240 VAC, 50 Hz, 15A•

See the front warning decal for the voltage requirements of the treadmill.

WARNING: Do not attempt to use this unit with a voltage adapter. Do not attempt to use

this unit with an extension cord.

WARNING: Do not plug more than one unit into a single circuit.

Grounding Instructions

This treadmill must be grounded. If it should malfunction or break down, grounding provides a path of

least resistance for electric current to reduce the risk of electric shock. This product is equipped with

a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged

into an appropriate outlet that is properly installed and grounded in accordance with all local codes

and ordinances.

DANGER: Improper connection of the equipment-grounding conductor can result in a

risk of electric shock. Check with a qualied electrician or service provider

if there is doubt as to whether the treadmill is properly grounded. Seek

a qualied electrician to perform any modications to the cord or plug.

Cybex is not responsible for injuries or damages as a result of cord or plug

modication.

Cybex 770T-CT Treadmill Owner’s Manual

This treadmill is for use on a grounded, dedicated circuit. Make sure that the treadmill is connected to

an outlet having the same conguration as the plug. Do not use a ground plug adapter to adapt the

power cord to a non-grounded outlet.

115 VAC Euro Plug 220 VAC UK Danish

NEMA 5-20 CEE 7/7 NEMA 6-15 230 VAC IEC320

Important Safety Instructions

(Save These Instructions)

DANGER: To reduce the risk of electric shock, always unplug this treadmill from the

electrical outlet immediately after using it and before cleaning it.

User Safety Precautions

WARNING: Heart rate monitoring systems may be inaccurate. Over exercise may result

in serious injury or death. If you feel faint stop exercising immediately.

Obtain a medical exam before beginning any exercise program.•

Stop exercising if you feel faint, dizzy, or experience pain and consult your physician. • Obtain instruction before using.•

Read and understand the Owner’s Manual and all warnings posted on the unit before using. • Read and understand emergency stop procedures.• DO NOT• wear loose or dangling clothing while using the treadmill.

Keep all body parts and other items free and clear of moving parts.

• Place your feet on the two top steps when starting or stopping the treadmill.• Use the treadmill handrails for support and to maintain balance.• Keep all children (12 and under) away. Teenagers (13 and over) and disabled must be supervised.• DO NOT• use the unit if you exceed 400 lbs. (181 kg). This is the rated maximum user weight.
