CYBEX CX-445T Bedienungsanleitung

Cybex CX-445T Treadmill

Owner’s Manual

Cardiovascular Systems

Part Number LT-19800-4 H

www.cybexinternational.com

Cybex CX-445T Treadmill

Owner’s Manual

Cardiovascular Systems

Part Number LT-19800-4 H

Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc. Safety Sentry™ is a registered trademark of Cybex

international, Inc. Polar®is a registered trademark of Polar Electro Inc.

DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We reserve

the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify

any person of such revisions or changes.

10 Trotter Drive Medway, MA 02053 • 888-462-9239 • 508-533-4300 • FAX 508-533-5183

www.cybexinternational.com • [email protected] • LT-19800-4 H • January 2010

Cybex 445T Treadmill Owner’s Manual

Page i

Front Pages

About this Manual. . . . . . . . . . . . . . . . . . . iii

FCC Compliance Information. . . . . . . . . . iii

1 Safety

Important Voltage Information . . . . . . . 1-1

Grounding Instructions . . . . . . . . . . . . . 1-1

Important Safety Instructions . . . . . . . . 1-2

Warning Decals . . . . . . . . . . . . . . . . . . 1-4

Caution Decals. . . . . . . . . . . . . . . . . . . 1-8

Emergency Stop Key (e-stop) . . . . . . . 1-8

2 Setup and Assembly

Warnings/Cautions . . . . . . . . . . . . . . . . 2-1

Choosing and Preparing a Site . . . . . . 2-1

Electrical Power Requirements . . . . . . 2-2

Assembling the Treadmill. . . . . . . . . . . 2-2

Extension Handrails - Optional. . . . . . 2-10

Testing the Treadmill Operation. . . . . 2-12

Setting Operation Options . . . . . . . . . 2-13

3 Operation

Terms and Symbols Used . . . . . . . . . . 3-1

Quick Operation Guide. . . . . . . . . . . . . 3-2

Detailed Operation Guide. . . . . . . . . . . 3-2

Stopping the Treadmill . . . . . . . . . . . . . 3-5

Immobilization Method . . . . . . . . . . 3-5

Emergency Dismount . . . . . . . . . . . 3-5

Emergency Stop . . . . . . . . . . . . . . . 3-5

Safety Sentry™ . . . . . . . . . . . . . . . . . . 3-6

Control During Operation . . . . . . . . . . . 3-6

Data Readouts . . . . . . . . . . . . . . . . . . . 3-6

Displaying Heart Rate. . . . . . . . . . . . . . 3-7

Heart Rate Zone. . . . . . . . . . . . . . . . . . 3-8

Meaning of % Grade . . . . . . . . . . . . . . 3-8

Use of Programs. . . . . . . . . . . . . . . . . . 3-9

Audio/Video . . . . . . . . . . . . . . . . . . . . 3-10

Table of Contents

4 Preventive Maintenance

Warnings/Cautions . . . . . . . . . . . . . . . . 4-1

Regular Maintenance Activities . . . . . . 4-1

Cleaning Your Treadmill. . . . . . . . . . . . 4-1

Running Belt Maintenance . . . . . . . . . . 4-3

Other Preventive Maintenance. . . . . . . 4-5

Service Schedule . . . . . . . . . . . . . . . . . 4-6

5 Customer Service

Contacting Service . . . . . . . . . . . . . . . . 5-1

Serial Number and Voltage . . . . . . . . . 5-1

Return Material Authorization (RMA) . . 5-2

Damaged Parts. . . . . . . . . . . . . . . . . . . 5-2

Ordering Parts . . . . . . . . . . . . . . . . . . . 5-3

Appendix A Technical Specifications . . . A-1

Appendix B Program Overview . . . . . . . . B-1

Appendix C Parts List . . . . . . . . . . . . . . . . C-1

Appendix D Exploded Views. . . . . . . . . . . D-1

Appendix E Schematic. . . . . . . . . . . . . . . . E-1

Cybex 445T Treadmill Owner’s Manual

Page ii

Cybex 445T Treadmill Owner’s Manual

Page iii

About This Manual

An Owner’s Manual is shipped with each unit. To purchase additional copies of this manual or any other

Cybex manual, please do one of the following:

• fax your order to 508-533-5183

• contact Cybex Customer Service at 888-462-9239

• or contact Cybex Customer Service at 508-533-4300

To contact Cybex with comments about this manual you may send email to [email protected].

FCC Compliance Information

WARNING: Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate

the equipment.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television

reception (which can be determined by turning the equipment off and on) the user is encouraged to try

to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio TV technician for help.

Cybex 445T Treadmill Owner’s Manual

Page iv

Cybex 445T Treadmill Owner’s Manual

Safety

Page 1-1

1 - Safety

IMPORTANT:Read all instructions and warnings before using the treadmill.

Important Voltage Information

Before plugging the power cord into an electrical outlet, verify that the voltage requirements for your area

match the voltage of the treadmill that you have received. The power requirements for the Cybex 445T

treadmill include a grounded, dedicated circuit, rated for one of the following: 115 VAC ±5%, 60 Hz and

20 amps; 220 VAC, 60 Hz and 12 amps or 230 VAC ±5%, 50 Hz and 12 amps. See the serial number

decal for the exact voltage requirements of your treadmill.

WARNING: Do not attempt to use this unit with a voltage adapter. Do not attempt to use this unit

with an extension cord.

WARNING: Do not plug more than one unit into a single circuit.

Grounding Instructions

This treadmill must be grounded. If it should malfunction or break down, grounding provides a path of

least resistance for electric current to reduce the risk of electric shock. This product is equipped with a

cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into

an appropriate outlet that is properly installed and grounded in accordance with all local codes and

ordinances.

DANGER: Improper connection of the equipment-grounding conductor can result in a risk of

electric shock. Check with a qualiﬁed electrician or service provider if you are in doubt

as to whether the treadmill is properly grounded. Seek a qualiﬁed electrician to perform

any modiﬁcations to the cord or plug. Cybex is not responsible for injuries or damages

as a result of cord or plug modiﬁcation.

This treadmill is for use on a nominal 115 VAC

±5%, 60 Hz and 20 amps, 220 VAC; 60 Hz, 12

amps or 230 VAC ±5%, 50 Hz and 12 amps and

a grounded, dedicated circuit. Make sure that

the treadmill is connected to an outlet having the

same conﬁguration as the plug. Do not use a

ground plug adapter to adapt the power cord to a

non-grounded outlet.

115 VAC Euro Plug 220 VAC UK

NEMA 5-20 CEE 7/7 NEMA 6-15 230 VAC

Cybex 445T Treadmill Owner’s Manual

Safety

Page 1-2

Important Safety Instructions

(Save These Instructions)

DANGER:To reduce the risk of electric shock, always unplug this treadmill from the electrical

outlet immediately after using it and before cleaning it.

WARNING: Serious injury could occur if these precautions are not observed. To reduce the risk

of burns, ﬁres, electric shock, or injury:

User Safety Precautions

• Obtain a medical exam before beginning any exercise program.

WARNING: Heart rate monitoring systems may be inaccurate. Over exercise may result in serious

injury or death. If you feel faint stop exercising immediately.

• Stop exercising if you feel faint, dizzy, or experience pain at any time and consult your physician.

• Obtain instruction before using.

• Read and understand the Owner’s Manual and all warnings posted on the unit before using.

• Read and understand emergency stop procedures.

• DO NOT wear loose or dangling clothing while using.

• Keep all body parts, towels, and the like free and clear of moving parts.

• Place your feet on the two top steps when starting or stopping the treadmill.

• Use the treadmill handrails for support and to maintain balance.

• Keep children away from the treadmill. Teenagers and disabled persons must be supervised.

• DO NOT use the unit if you exceed 350 lbs. (158 kg). This is the rated maximum user weight.

• Report any malfunctions, damage or repairs to the facility.

• Replace any warning labels if damaged, worn or illegible.

• Stop and place the treadmill at 0 degrees incline (level) after each use.

• Disconnect power before servicing.

Facility Safety Precautions

• Instruct all users on how to clip the e-stop clip onto their clothing and carefully test it prior to using the

treadmill.

• Instruct all users to use caution when mounting and dismounting the treadmill.
