CYCLOPS PARALYSER 755 Bedienungsanleitung
PARALYSER 755, 775,
775b &785
USER INSTRUCTIONS
Proudly designed and engineered
in Australia by Dynamco Pty Ltd.
CYCL PS
VEHICLE SOLUTIONS
P755 P775 P775B 785 User - 2008.1 1 16/07/2008 3:24:11 PM
THIS CARD SHOULD NOT BE LEFT IN YOUR VEHICLE.
IT MUST BE KEPT IN A SAFE SECURE PLACE.
-2-
CYCL PS
VEHICLE SOLUTIONS
P755 P775 P775B 785 User - 2008.2 2 16/07/2008 3:24:11 PM
-3-
Contents
INTRODUCTION 4
OPERATIONS 5
REMOTE CONTROLS 5
ARMING AND DISARMING 5
ARM/DISARM SIREN CONFIRMATION 6
SILENT ARMING 6
AUTOMATIC ARMING 6
DOME LIGHT FUNCTION 7
PANIC FEATURE (Car Location) 7
OPEN DOOR WARNING 7
IMMOBILISATION 8
ALARM PROTECTION ZONES 8
DIAGNOSTICS 8
DIAGNOSTIC TABLE 9
EMERGENCY OVER-RIDE 9
PIN OVER-RIDE PROCEDURE 10
PROGRAMMABLE OPTIONS 11
OPTION CHANGE PROCEDURE 11
PROGRAMMABLE OPTIONS TABLE 12
PROGRAMMABLE OPTION DESCRIP-
TIONS 13
CHANGING PIN CODE 15
BATTERY REPLACEMENT 16
SPECIFICATIONS 17
PROBLEM SOLVING 18
WARRANTY 19
WARRANTY REGISTRATION 20
P755 P775 P775B 785 User - 2008.3 3 16/07/2008 3:24:11 PM
CYCLOPS P755, P775,
P775B & P785 ALARM /
IMMOBILISER USER GUIDE
INTRODUCTION
Congratulations on having one of the world’s most advanced alarm/
engine immobilisers installed in your vehicle. This manual describes
the features and functions of all four systems. Where as day to day
use of the system only involves pressing the remote control, many
features of the systems will provide additional convenience for the
user. Please read this manual to gain a full understanding of what
service a Cyclops 7 Series system can provide to you.
LEGEND:
55
P755 feature
75
P775 feature
75B
P775B feature
85
P785 feature
ALL
Featured in all systems
-4-
CYCL PS
VEHICLE SOLUTIONS
P755 P775 P775B 785 User - 2008.4 4 16/07/2008 3:24:12 PM
-5-
OPERATIONS
REMOTE CONTROLS
ALL
All systems are supplied with two rolling code
remote controls. Each time a button is pressed,
the code advances to a completely new code.
Each code is only ever used once.
ARMING AND DISARMING
ALL
To arm the system press the main button on the remote control. The
vehicle indicators will flash twice. The blue status LED on the dash
will flash when the alarm/immobiliser is armed. To disarm the system,
press the main button. The indicators will flash once. The system
features a transponder disarm function. An electronic transponder
antenna will detect a valid remote control when in range. This will
disarm the system automatically if the ignition is turned on.
P755 P775 P775B 785 User - 2008.5 5 16/07/2008 3:24:12 PM
-6-
ARM/DISARM SIREN CONFIRMATION
75B75 85
Each time the alarm is armed the siren will chirp twice to confirm the
arm operation. The siren will chirp if the automatic arming function
arms the system. The siren will also chirp once when the system is
disarmed by remote control.
SILENT ARMING
75B75 85
The arm/disarm confirmation chirps can be suspended for one
operation by momentarily pressing the secondary button on the
remote control before pressing the main button. The chirp will re-
enable upon the next operation. The siren chirps can be permanently
cancelled by changing option #13 (see “Programmable Options”
section for details).
AUTOMATIC ARMING
ALL
The immobiliser will automatically disable the engine 40 seconds
after the ignition switch is turned off. Pressing the main remote
control button after the system has automatically armed, will
command the immobiliser to disarm for another 40 seconds.
P755 P775 P775B 785 User - 2008.6 6 16/07/2008 3:24:12 PM
-7-
DOME LIGHT FUNCTION
ALL
When the system is disarmed by remote control, the internal
circuitry can switch on the car’s dome light for 30 seconds. This
feature will be cancelled if the driver turns the ignition switch to the
ON position. Factory setting is disabled to avoid unit damage (see
“Programmable Options” section for details).
PANIC FEATURE (Car Location)
75B75 85
The alarm can be commanded to “panic” for 30 seconds if the main
button is pressed for more than 2 seconds. The panic feature will
sound the siren and flash the indicators. To cancel the Panic Feature,
momentarily press the main button once more. The panic feature is
available only while the system is armed.
OPEN DOOR WARNING
75B75 85
If any connected door is detected as being open while arming, the
alarm will flash the indicators and chirp the siren 8 times. This can
happen if the car has a built-in feature which extends the dome light
time. These cars will need this feature disabled (see “Programmable
Options” section for details).
P755 P775 P775B 785 User - 2008.7 7 16/07/2008 3:24:12 PM
-8-
IMMOBILISATION
ALL
The system includes two independent circuits of immobilisation. Each
circuit starves the engine of one of it’s critical power supplies. The
circuits are designed to be fail-secure, so if a would-be thief was to
cut power to the immobiliser, the circuit design will ensure the car
remains immobilised.
ALARM PROTECTION ZONES
75B75 85
The alarm protects the vehicle by monitoring all door, bonnet and
boot switches, as well as “listening” for the sound of breaking glass.
Additional sensors can be installed to provide movement detection if
required, eg Soft top vehicles.
DIAGNOSTICS
75B75 85
When any circuit triggers the alarm, the number of the zone
responsible will be recorded in the system memory. The number is
flashed back through the indicators and status LED when the alarm
is next disarmed. The zones are listed in the table on page 9.
P755 P775 P775B 785 User - 2008.8 8 16/07/2008 3:24:12 PM
-9-
DIAGNOSTIC TABLE
ALL
ZONE DESCRIPTION
1 Bonnet Switch
2 Auxiliary Trigger
3 Doors / Boot Switch
4 Glass Breakage
EMERGENCY OVER-RIDE
ALL
If either of the remote controls supplied
with the system are lost, broken or
stolen, the immobiliser can be disarmed
by use of a security key and the unique
4 digit Personal Identification Number
(PIN). To disable the security system,
turn the key in the rear of the siren 90
degrees. Then follow the PIN procedure in
the next section.
SIREN
SWITCH SIREN OFF
LOCK
KEY
DUST CAP
85
75B
P755 P775 P775B 785 User - 2008.9 9 16/07/2008 3:24:13 PM
-10-
PIN OVER-RIDE PROCEDURE
ALL
To illustrate the PIN over-ride procedure we will assume a PIN of
4,3,2,1.
If indicators are still flashing, turn the ignition on and allow the
system to reset with all doors closed.
Turn ignition switch to ON position, the status LED will remain lit.
Turn ignition switch to the ACC position and count the LED
flashes.
Turn ignition switch ON when the 4th flash has extinguished.
Turn back to ACC position and count 3 flashes, switch ignition ON.
Turn back to ACC position and count 2 flashes, switch ignition ON.
Turn back to ACC position and count 1 flash, switch ignition ON.
When all four digits have been entered correctly, the car’s indicators
will flash once to confirm that the immobiliser is disarmed. The
engine can be started and the car driven. The automatic arming
feature will ensure car is secured again if the ignition is left off for
more than 40 seconds.
•
•
•
•
•
•
P755 P775 P775B 785 User - 2008.10 10 16/07/2008 3:24:13 PM
