CYP CPLUS-V4H4HP Bedienungsanleitung

CPLUS-V4H4HP

4K UHD+ 4 x 4 Matrix with USB Power Supply

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE

RDV1 31/10/16 Preliminary Release

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. Package Contents ................................ 2

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front Panel ........................................3

6.2 Rear Panel.........................................5

6.3 Remote Control................................6

6.4 LCD Menu Tree.................................7

6.5 IR Cable Assignments ......................7

6.6 RS-232 Protocol.................................8

6.7 RS-232 Command ............................9

6.8 Telnet Control .................................12

6.9 WebGUI...........................................13

6.9.1 Switch ...........................................15

6.9.2 EDID Settings ................................18

6.9.3 System Setting .............................21

6.9.4 Admin log out..............................21

7. Connection Diagram .......................... 22

8. Specications ...................................... 23

8.1 Technical Specication.................23

8.2 Support Timing................................24

8.3 HDMI Cable Length .......................25

1. INTRODUCTION

This 4K UHD 4 by 4 Matrix provides the ability to connect up to four

4K UHD HDMI sources to up to four 4K UHD HDMI displays and freely

switch between them. This unit comes with full support for 18Gbps

(600Mhz) resolutions up to, and including 4K@60Hz (4:4:4, 8-bit) as

well as support for 48-bit Deep Color, HDR (High Dynamic Range), HD

audio and other features dened by the HDMI 2.0 specication. With

a comprehensive EDID management feature that includes the ability

to select between built in default EDID, EDID copied from connected

sink devices, as well as a congurable EDID, this matrix can solve

many interconnectivity problems. This unit also features four USB ports

which supply up to 5V/1A power for use with connected optical ber

or AOC ber cable extenders. By using these specialized cables your

HDMI content can be extended much further than would be possible

with normal HDMI cables. The built in OSD has the ability to display user

editable general information text so each output can display up to 2

lines of customized text on top of the video source in the color of your

choice. This unit provides an intuitive set of front panel controls with an

OSD as well as RS-232, telnet, WebGUI, and IR remote control options.

2. APPLICATIONS

• Smart Home Control

• Control Center

• Function Room

• Product Showroom

• Ballroom

3. PACKAGE CONTENTS

• Matrix unit x 1

• 24V/3.75A Adaptor with power cord x 1

• Remote control unit x 1 (CR-177)

• Rack ear set x 1

• Operation manual x 1

4. PACKAGE CONTENTS

• HDMI source equipment such as media players, video game

consoles or set-top boxes.

• HDMI receiving equipment such as HDTVs, monitors or audio

ampliers.

• The use of “Premium High Speed HDMI” cables is highly

recommended.

5. FEATURES

• HDMI input and output with 18Gbps (600MHz) 4K UHD support

• DVI 1.0 compliant with the use of an HDMI-DVI adaptor

• HDCP 1.4 and 2.2 compliant

• Supports HD resolutions up to 3840x2160@60 Hz (YUV 4:4:4, 8-bit) &

4096x2160@60 Hz (YUV 4:4:4, 8-bit)

• Supports 48-bit Deep Color up to 1080p60

• Supports pass-through of LPCM 7.1, bitstream and HD bitstream

audio formats

• Supports six internal EDIDs, four external EDIDs copied from

connected devices, and four user provided EDIDs

• Four USB ports to supply 5V/1A power to optical ber and AOC ber

extension cables

• OSD with user customizable information text

• Intuitive control interface including telnet, WebGUI, OSD, IR remote

and RS-232

• Easy rmware update via USB thumb drive in eld

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER

IN 1IN 2IN 3IN 4

OUT AOUT BOUT COUT D

ENTER

PRESET

ALLLOCK

MUTE

CONFIRM

CANCEL

4x4 4K UHD+ Matrix

1 2 3 4 5 7

6 8

9 10

1Power: Press this button to power the unit on (green LED) or place it

into stand-by mode (red LED).

2IR Receiving Window: Accepts IR signals from the included IR

remote for control of this unit only.

3IN 1~4 & OUT A~D: Press the “OUT” keys (A~D) of the outputs you

wish to route a source to (they will ash to indicate selection).

Next, press the “IN” key of the input (1~4) you wish to route to

the selected outputs. Finally, press “CONFIRM” to conrm your

selection and execute the routing change.

4CONFIRM: Press this button to conrm newly made input/output

routing selections.

CANCEL: Press this button to cancel newly made input/output/

preset routing selections before they have been conrmed.

5MENU: Press to enter the LCD menu, or to back out from menu

items.

ENTER: Press to conrm a selection within the LCD menu or to go

deeper into a menu item.

- / +: Press to move up and down or adjust selections within menus.

6ALL: Press this button to select all outputs simultaneously for routing.

Next, press the “IN” key of the input (1~4) you wish to route to all

outputs. Finally, press “CONFIRM” to conrm your selection and

execute the routing change.

7PRESET: Press to enter the preset recall menu in the LCD window.

Press the “+/-” buttons followed by the “ENTER” button to select

and activate the preferred preset.

8LOCK: Press to lock all button functions on the front panel. Press

and hold for 3 seconds to release the lock function. The LCD will

display “Lock” when the function is active.

9MUTE: The “MUTE” button functions as a blank audio/video source.

To use it, follow the standard matrix routing instructions, but use

the “MUTE” button as the input to blank out the selected outputs.

When a “MUTE” input is in use it will show up as “M” within the

routing display.

10 LCD window: Displays the unit’s menu, settings and information.

6.2 Rear Panel

CONTROL

SERVICE

RS232 IR IN

DC 24V

11234

234

HDMI IN

OPTICAL /HDMI OUT

BCD

V+

GND

GND GND

V+

USB POWER OUTPUT

(5V/1A)

1 2 3 4 5 6 7 8

1HDMI IN 1~4: Connect to HDMI source equipment such as media

players, game consoles or set-top boxes.

2OPTICAL / HDMI OUT A~D: Connect the HDMI outputs to devices

such as HDMI TVs, monitors or ampliers for digital video and

audio output. Connect the optical outputs to powered speakers

or ampliers for digital audio output using an appropriate optical

cable. The audio from each optical output will be the same as the

HDMI output it is paired with.

3USB POWER OUTPUT 1 ~ 4: Each USB port provides 5v/1A of power

intended for use with HDMI over AOC (Active Optical Cables) ber

optic video extension cables.

4SERVICE: This slot is reserved for rmware update use only.

5CONTROL: Connect directly, or through a network switch, to your

PC/laptop to control the unit via telnet/WebGUI.

6RS232: Connect directly to a PC, laptop or other serial control

device to send RS-232 commands to control the unit.

7IR IN: Connect to the provided IR Extender to extend the IR control

range of the unit. Ensure that the remote being used is within direct

line-of-sight of the IR Extender.

8DC 24V: Plug the 24V DC power adapter into the unit and connect

it to an AC wall outlet for power.
