CYP CDM-150 Bedienungsanleitung

Video System

Converter

Operation Manual

CDM-150

TABLE OF CONTENTS

1. Introduction.................................................................................1

2. Main Features............................................................................. 1

3. Hardware Description................................................................ 2

3.1 Front Panel.............................................................................2

3.2 Rear Panel............................................................................. 2

4. Connections and Installation.................................................... 3

5. Specifications.............................................................................. 3

1. Introduction

The Video System Converter is designed to convert video signal of different TV

systems to NTSC or PAL signal selectable,for the connected display to work

properly. It is a convenient device for users to connect source and display of

different TV systems, with the on-panel H.POS. adjusters which is easy to

fine-tune screen offset caused by display of different type. The installation is

simple, just plug in video cables of input / output and power adapter, then

switch between NTSC and PAL to get the preferable result.

2. Main Features

● Supports digital conversion from NTSC, N4, PAL, PAL M, PAL N, and SECAM to

NTSC/PAL.

● Converts 525 lines to/from 625 lines.

● Converts refresh frequency between 60Hz and 50Hz.

● Provides color bar pattern when there is no signal present.

● System is capable with 8 Mb field memory.

3. Hardware Description

The following sections describe the hardware components of this converter

box.

3.1. Front Panel

1. The LED indicator will illuminate when the unit is powered on.

3.2. Rear Panel

1. Video input: Connect to video source using video composite cable.

2. H. POS. Center: To adjust the display to right/left.

3. DC 5V/1A: Plug the 5VDC power supply into the unit and connect the

adaptor to AC wall outlet.

4. NTSC/PAL: Select the output signal. NTSC supports 3.58 format only.

5. Video output: Connect to display using video composite cable.

INPUT OUTPUT

DC5V NTSC

PAL

H. POS.

CENTER

1 32 4 5

POWER

CDM-150

Video system converter

4. Connections and Installation

5. Specifications

INPUT OUTPUT

DC5V NTSC

PAL

H. POS.

CENTER

DVD Player

NTSC or PAL Video Recorder

PAL

NTSC

SECAM

Satellite Receiver

NTSC

PAL TV

Camcorder

Set-Top-Box

Input Systems

Output Systems

Input Port

Output Port

Sampling Frequency

Digital Code Bit

Line

Field

Power Supply

Dimensions(mm)

Weight(g)

Chassis Material

Silkscreen Color

Operating Temperature

NTSC, N4, PAL, PAL-M, PAL-N, SECAM

NTSC 3.58, PAL

Video

Y: 13.5MHz

R-Y: 6.75MHz

B-Y: 6.75MHz

R: 8 bits

G: 8 bits

B: 8 bits

525/625

60/50

5V/1A DC (US/EU standards, CE/FCC/UL certified),

Center positive

146(W) x 95(D) x 33(H)

144

Plastic

Milk White

0°C ~ 40°C

2007.9.26 MPM-CDM150

Home page: http://www.cypress.com.tw

CYPRESS TECHNOLOGY CO., LTD.
