CYP MA-U42 Bedienungsanleitung

MA-U42

4 x 2 HDMI Matrix with Amplier & USB Hub

OPERATION MANUAL

registered trademarks of HDMI licensing Administrator, Inc.

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.00 26/02/2020 Preliminary release

CONTENTS

1. Introduction..................................................1

2. Applications ..................................................2

3. Package Contents .........................................2

4. System Requirements .................................. 2

5. Features.........................................................3

6. Operation Controls and Functions ..............4

6.1 Front Panel.............................................................4

6.2 Rear Panel...............................................................5

6.3 RS-232 Pinout and Defaults.............................7

6.4 WebGUI Control ...................................................7

6.4.1 Video Select Tab ..................................... 10

6.4.2 EDID Tab.................................................... 12

6.4.3 HDCP Tab.................................................. 14

6.4.4 Audio Select Tab .................................... 15

6.4.5 Trigger Tab................................................ 18

6.4.6 System Tab ............................................... 19

6.5 Telnet Control..................................................... 21

6.6 Serial and Telnet Commands........................ 21

7. Connection Diagram ..................................43

8. Specications..............................................44

8.1 Technical Specications ................................. 44

8.2 Video Specications......................................... 45

8.3 Audio Specications........................................ 47

8.3.1 Digital Audio ........................................... 47

8.3.2 Analogue Audio..................................... 48

8.4 Cable Specications ........................................ 49

9. Acronyms.....................................................50

1. INTRODUCTION

This 4 by 2 matrix switch with amplifier is designed for use in

environments needing a wide range of exibility when it comes to inputs,

outputs, and control. The three most common video input interfaces

(HDMI, DisplayPort, and VGA w/stereo audio) are included along with

a pair of HDMI outputs, providing the ultimate in source compatibility

and exibility. This unit is HDCP 2.2 compliant and supports resolutions

up to a maximum of 4K@60Hz (4:4:4, 8-bit) for HDMI and Display ports.

The included microphone input, with optional 48V phantom power and

support for automatic ducking, feeds directly into a DSP mixer, allowing

for powerful presentations with live voiceovers or even an impromptu

karaoke session. Pass-through of multiple digital audio formats such as

LPCM (up to 8 channels), bitstream and HD bitstream are supported.

Additionally, the integrated stereo amplifier provides up to 40 watts of

power (20W per channel) for local speakers to output the audio from the

selected source, offering a flexible sound experience (LPCM 2.0 sources

only).

This matrix also includes a USB 3.0 hub with one host port (Type-B),

plus three device ports (Type-A) for a exible KVM conguration. It also

provides an interface for a remote control keypad or trigger interface,

which can be easily installed within a podium or table making this matrix

ideal for use in meeting rooms, classrooms, and auditoriums which need

comprehensive video and audio integration with USB expansion. This

unit is controllable via front panel controls, WebGUI, Telnet, Triggers, and

RS-232.

2. APPLICATIONS

Lecture room display and control

Showroom display and control

Meeting room presentation and control

Classroom display and control

3. PACKAGE CONTENTS

1× UHD+Multi-Format HDMI Switcher with Amplier

1× 24V/3.75A DC Power Adapter

1× Power Cord

2× 5-pin Terminal Block

1× 3-pin Terminal Block

2× 2-pin Terminal Block

1× Shockproof Feet (Set of 4)

1× Operation Manual

4. SYSTEM REQUIREMENTS

HDMI, DisplayPort, or VGA source equipment such as media players,

video game consoles, PCs, or set-top boxes.

HDMI receiving equipment such as HDTVs, monitors or audio

ampliers.

The use of Premium High Speed HDMI cables is highly recommended.

5. FEATURES

HDMI 2.0 and DVI 1.0 compliant

HDCP 1.x and 2.2 compliant

4 video inputs (2×HDMI, 1×DisplayPort, 1×VGA w/ analogue audio)

2 matrixed HDMI outputs

HDMI and DisplayPort inputs support resolutions up to 4K@60Hz (4:4:4,

8-bit)

VGA input supports resolutions up to 1080p60Hz

HDMI outputs support resolutions up to 4K@60Hz (4:4:4, 8-bit)

Supports Deep Colour input and output up to 12-bit (HDMI/

DisplayPort only)

Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output

(HDMI/DisplayPort only)

Supports pass-through of 8 channel LPCM, bitstream & HD bitstream

audio formats

Audio mixer function allows the mixing of audio from any LPCM 2.0

audio source with the microphone input

Microphone input supports 48V phantom power and feeds into a DSP

mixer allowing adjustable mix levels, automatic ducking, audio output

mixing, volume, and mute controls

High performance, 2 channel, class D amplier with 20 watts of power

per channel and independent volume control

USB 3.0 hub with one host port (Type-B) and three device ports

(Type-A)

Trigger Control Keypad support for easy, single-button, function

activation (Optional)

Comprehensive EDID and HDCP management

Controllable via front panel controls, RS-232, Telnet, WebGUI, and

triggers

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER

HDMI

12DP VGA

VIDEO SELECT

LINE IN

VIDEO

USB 1 USB 2

LINE IN MIC IN MIC MUTE

MIN MAX

OUT

MUTE

AUDIO

SELECT

MIC

GAIN

MASTER VOL.

MA-U42

6 7 8 9

2 3 4 5

1POWER LED: This LED will illuminate to indicate the unit is on and

receiving power.

2VIDEO SELECT Buttons & LEDs: Press the A and B buttons to

sequentially switch through the available inputs for each of the two

HDMI outputs. The OUT A/B LEDs will illuminate to indicate which

source is currently selected for each output.

3AUDIO SELECT Button & LEDs: Press this button to toggle between

the front panel Line Input and Output A’s currently selected video’s

native audio as the source route to Output A and the analogue audio

outputs. The LED will illuminate to indicate which source is currently

selected.

Note: When Mic In has been selected via the WebGUI, both LEDs will

remain o.

4MUTE Button & LED: Press to toggle between muting or unmuting

all primary audio sources on Output A and the analogue outputs. The

LED will illuminate to indicate that mute is active.

Note: Microphone sourced audio and the audio on output B is not

aected by this setting.

5MASTER VOL. Knob: Turn this knob to increase or decrease the audio

volume level of both analogue outputs as well as HDMI output A.

Note: This control is only active when the volume control toggle is set to

“Panel” in the WebGUI.

6USB 3.0 Device Ports 1 & 2 (Type-A): Connect directly to standard

USB devices such as a mouse, keyboard or ash drive to extend their

USB functionality to the host connected to the USB 3.0 Host Port.

7LINE IN Port: Connect to the stereo analogue output of a device such

as an audio player or PC.

MIC IN Port: Connect to a standard microphone using a 6.35mm plug.

Note: If the microphone requires 48V phantom power, that setting must

be activated within the WebGUI.

8MIC MUTE Button & LED: Press to toggle between muting and

unmuting microphone-sourced audio output. The LED will illuminate

to indicate that mute is active.

9MIC GAIN Knob: Turn this knob to manually set the microphone

input’s gain level. Gain level is directly related to the knob’s position.

Note: This control is only active when the volume control toggle is set to

“Panel” in the WebGUI.

6.2 Rear Panel

HDMI 1 IN HDMI 2 IN DP IN VGA IN LINE IN HDMI A OUT HDMI B OUT

TRIGGER IN

LAN

SERVICEUSB

TX RX

RS-232 DC 24V

AMPLIFIER OUT

AUDIO OUT

1 2 3 4 5 6 7 8 9

10 12 13 14 1511

1HDMI 1 IN Port: Connect to HDMI source equipment such as a media

player, game console, or set-top box.

2HDMI 2 IN Port: Connect to HDMI source equipment such as a media

player, game console, or set-top box.

3DP IN Port: Connect to DisplayPort source equipment such as a media

player, PC, or set-top box.

4VGA IN Port: Connect to VGA source equipment such as a PC or

laptop.

Inhaltsverzeichnis

Andere CYP Schalten Handbücher

CYP

CYP PUV-2608TX Bedienungsanleitung

CYP

CYP CH-2537TXM-TB Bedienungsanleitung

CYP

CYP EL-C81C Bedienungsanleitung

CYP

CYP EL-5300 Bedienungsanleitung

CYP

CYP EL-41S-4K22 Bedienungsanleitung

CYP

CYP CSC-6030CVE Bedienungsanleitung

CYP

CYP EL-7500V Bedienungsanleitung

CYP

CYP PU-444HBTE Bedienungsanleitung

CYP

CYP EL-5400D Bedienungsanleitung

CYP

CYP CPLUS-V4H1HP Bedienungsanleitung

CYP

CYP EL-42HEAC Bedienungsanleitung

CYP

CYP EL-41PIP Bedienungsanleitung

CYP

CYP EL-42S Bedienungsanleitung

CYP

CYP CED-S11 Bedienungsanleitung

CYP

CYP CMLUX-4H4CAT Bedienungsanleitung

CYP

CYP EL-41X Bedienungsanleitung

CYP

CYP CSSW-91WF Bedienungsanleitung

CYP

CYP CPLUS-31PS Bedienungsanleitung

CYP

CYP EL-5300 Bedienungsanleitung

CYP

CYP EL-21SY Bedienungsanleitung

CYP

CYP CLUX-41W Bedienungsanleitung

CYP

CYP AU-D21 Bedienungsanleitung

CYP

CYP EL-5400 Bedienungsanleitung

CYP

CYP EL-42PIP Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
