CYP CMSI-424E Bedienungsanleitung

CMSI-424E

HDBaseT™ 4×4 HDMI Matrix over 4 CAT5e/6/7

with 2 HDMI Outputs

Operation Manual

5-Play™

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

RDV1 13/09/12 Preliminary Release

VS1 11/07/12 Updated format/diagrams

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 2

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front Panel.........................................3

6.2 Rear Panel .........................................4

6.3 Side Panel ..........................................5

6.4 Remote Control.................................5

6.5 IR Pin Assignment ..............................6

6.6 RS-232 Protocols ................................6

6.7 RS-232 and Telnet Commands ........7

6.8 Telnet Control ....................................8

6.9 Web GUI Control.............................10

7. Connection Diagram .......................... 12

8. Specications ...................................... 13

9. Acronyms ............................................. 13

1. INTRODUCTION

The HDBaseT™ 4 by 4 HDMI Matrix over CAT5e/6/7 with two additional

simultaneous HDMI outputs supports the transmission of video

(resolutions up to 1080p Full HD and 1920x1200@60Hz), multi-channel

digital audio and control via IR, RS-232 or Web GUI/Telnet IP from

four high denition sources to four HDBaseT outputs over a single

CAT5e/6/7 cable (up to 100m) for each output. Output A and C have

additional mirrored HDMI outputs.

It supports high resolution digital audio formats such as LPCM 7.1 CH,

Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio as well as

3D content that can be displayed when connecting a 3DTV and 3D

source. Power over Ethernet (PoE) support means that compatible

receivers do not need their own seperate power supplies, allowing for

greater exibility in installations and the LAN serving function allows

devices such as Smart TVs to be connected to the network/internet.

2. APPLICATIONS

• Domestic HDMI Matrix system

• Video/TV wall display and control

• Security surveillance and control

• Commercial advertising, display and control

• University Lecture hall display and control

• Retail Sales and demonstration

3. PACKAGE CONTENTS

• 4x4 HDMI Matrix over 4 CAT5e/6/7 with 2 HDMI outputs

• 1×IR Extender Cable*

• 1×IR Blaster Cable*

• 1×24V/3.75A DC adaptor

• 1×Remote control

• Operation manual

*Additional IR Blasters and extenders can be purchased seperately

4. SYSTEM REQUIREMENTS

• HDMI equipped source devices, connect with HDMI cables or DVI

equipped source, connect with DVI to HDMI cables

• HDMI equipped displays (TVs or monitors) or HDMI equipped AV

receivers, connect with HDMI cables

• Industry standard CAT5e/6/7 cables

• HDBaseT™ Receivers (i.e. CH-506RX, CH-507RX or CH-1109RX)

5. FEATURES

• HDMI, HDCP 1.1 and DVI compliant

• Supports HDMI 3D features

• Supports resolutions VGA~WUXGA and 480i~1080p dependent upon

the output display’s EDID settings

• Supports distances up to 100 meters through CAT6/7 cables and

80m for CAT5e

• Supports 3D signal display dependent upon the output display's

EDID settings

• Supports simultaneous HDMI and CAT 5e/6/7 display on outputs A

and C

• Supports PoE* (Power over Ethernet) on compatible receivers only

• Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters

at 12-bit resolution

• Supports bi-directional IR from input and output locations

• Supports RS-232, remote control, on-panel control and IP Control

(Telnet or Web GUI)

• 1U size design

• Supports external and internal EDID settings

• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD

Master Audio transmission

• Supports LAN serving function through the LAN/CONTROL port

Note:

1. The PoE function is designed for powering compatible receiver

units only—non-PoE receivers will need their own power supply.

Receivers of another brand may not be compatible.

2. Do not connect the LAN port to CAT outputs of this device or to

CAT inputs or receiver. Doing so may demage the unit.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

OUT

34IN

CMSI-424E

4X4 HDMI MATRIX

POWERLOCK MENU AB

61 2 3 4 5

LCM : Displays the setting information of each input and output

setting.

IR Window: IR Receiver window (accepts the remote control signal

of this device only).

POWER: Press this button to power the device on/off. The LED will

illuminate green when the power is on, red when it is in 'Standby'

mode.

LOCK: Press this button to lock all the buttons on the panel; press

again to unlock. The LED will illuminate when locked.

MENU: Press once to select EDID setting from STD (internal) 1 or TV

(external) 2 then press it again to conrm the selection. Press the

the 'MENU' button to conrm the input or output selection

IN/OUT and 1~4/A~D: Press the OUT button and then the number

buttons to select the required output ports, and press IN button

and then a single number button to select the required input

source, nally press the MENU button to conrm the selection.

For example, if outputs A~B need to be set to input 1 and outputs

C~D need to be set to input 2, then the following sequence of

button presses need to be performed:

Press: OUTABIN1→MENU,

and then press: OUTCDIN2MENU.

Note: If the menu button is not pressed the selection will not be

changed.

6.2 Rear Panel

IR IN IR OUT

HDMI OUT CAT5e/6 OUT

CAT5e/6 OUT

HDMI OUT CAT5e/6 OUT

CAT5e/6 OUT

HDMI IN 1HDMI IN 2 HDMI IN 3HDMI IN 4 DC 24V

V+

GND

GND GND

V+

IR OUT

IR IN

ALL

SERVICE

RS232

IP &

ETHERNET

2 3

1110

7 9

RS-232: Connect to a PC or control system with D-Sub 9-pin cable

for the transmission of RS-232 commands.

IP & ETHERNET: Connect to an active network for LAN serving and

Telnet/Web GUI control (refer to Sections 6.8 and 6.9).When the

Matrix or any compatible LAN equipped receivers are connected

to a network, this allows the network access (including internet

access if available) to be shared between the Matrix and all

connected LAN equipped receivers. Connect any Ethernet

equipped device such as a Smart TV or games console to the LAN

port of a receiver for that device to share the network/internet

access.

Warning: Please do not connect this port directly to the PC/Laptop

as the Telnet function will not work.

SERVICE: Manufacturer use only.

HDMI OUT and CAT5e/6/7 OUT A/C: Simultaneous HDMI and

HDBaseT CAT5e/6/7 output. The HDMI output can be connected

directly to a display or to a point transmitter/receiver set. Connect

the CAT5e/6/7 output to a compatible receiver unit to extend the

signal up to 100 m.

CAT5e/6/7 OUT B/D: Connect from these CAT outputs to the CAT

input port of the receiver units with a single CAT5e/6/7 cable for HDMI

Audio/Video and IR/RS-232 control signal transmission.

Warning: Please do not connect the CAT5e/6/7 output into the

receiver's LAN port.

HDMI IN 1~4: Connect to the HDMI input source devices such as a

DVD player or a Set-top Box with HDMI cable or DVI to HDMI cable.

IR IN 1~4: Connect the IR extenders for IR signal reception. Ensure

that the remote being used is within the direct line-of-sight of the IR

extender.

IR OUT 1~4: Connect the IR blasters for IR signal transmission. Place

the IR blaster in direct line-of-sight of the equipment to be

controlled.

ALL IR OUT: Connect to the IR blaster for IR signal transmission of the

source or display equipment. Place the IR blaster in direct line-of-

sight of the equipment to be controlled.

ALL IR IN: Connect to the IR extender for IR signal reception of the

remote control of this device or the source and display equipment.

Ensure that remote being used is within the direct line-of-sight of

the IR extender.

DC24V: Connect the 24 V DC power supply to the unit and plug the

adaptor into an AC outlet.

6.3 Side Panel

Fan Ventilator: These are fan ventilation areas, DO NOT block these

areas or cover them with any object. Ensure there is adequate

space around the unit for air to circulate.

6.4 Remote Control

POWER: Press this button to switch on the

device or set it to standby mode.

1~4 IN: Input ports selection 1~4.

A~D OUT: Output ports selection A~D.

Note: IR Matrix control from Zones only

require the user to select the desired

input.

CR-121

IN OUT

Inhaltsverzeichnis

Andere CYP Schalten Handbücher

CYP

CYP EL-42S Bedienungsanleitung

CYP

CYP CLUX-21N Bedienungsanleitung

CYP

CYP EL-5300 Bedienungsanleitung

CYP

CYP CLUX-41AP Bedienungsanleitung

CYP

CYP CPLUS-V3H1H-TB Bedienungsanleitung

CYP

CYP CSC-6030CVE Bedienungsanleitung

CYP

CYP CPRO-U4H1HFS Bedienungsanleitung

CYP

CYP EL-41X Bedienungsanleitung

CYP

CYP PU-444HBTE Bedienungsanleitung

CYP

CYP EL-41SY Bedienungsanleitung

CYP

CYP CLUX-4S2 Bedienungsanleitung

CYP

CYP CLUX-41AT Bedienungsanleitung

CYP

CYP CSDI-44 Bedienungsanleitung

CYP

CYP CPLUS-31PS Bedienungsanleitung

CYP

CYP CPRO-41W Bedienungsanleitung

CYP

CYP EL-7500V Bedienungsanleitung

CYP

CYP DCT-17 Bedienungsanleitung

CYP

CYP EL-31SY Bedienungsanleitung

CYP

CYP CLUX-31N Bedienungsanleitung

CYP

CYP CED-S11 Bedienungsanleitung

CYP

CYP CVSD-41ARN Installationshandbuch

CYP

CYP CFSW-51MHL Bedienungsanleitung

CYP

CYP AU-D21 Bedienungsanleitung

CYP

CYP PU-1H2HBTE Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
