CMIR-44

4 by 4 Infrared Matrix

Operation Manual

CMIR-44

Disclaimers

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes

no commitment to update or to keep current the information

contained in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer ﬁle, in any form or by any means

- electronic, mechanical, magnetic, optical, chemical, manual,

or otherwise - without express written permission and consent from

Cypress Technology.

Version 1.0 February 2010

Trademark Acknowledgments

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

Safety Precautions

Please read all instructions before attempting to unpack or install or

operate this equipment, and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

 Always follow basic safety precautions to reduce the risk of

ﬁre, electrical shock and injury to persons.

 To prevent ﬁre or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

 Never spill liquid of any kind on or into this product.

 Never push an object of any kind into this product through

module openings or empty slots, as you may damage parts.

 Do not attach the power supply cabling to building surfaces.

 Do not allow anything to rest on the power cabling or allow it to

be abused by persons walking on it.

 To protect the equipment from overheating, do not block the

slots and openings in the module housing that provide

ventilation.

Revision History

Version No Date Summary of Change

V1 20100201 Preliminary Release

VR2 20101207 Adding IR Cable Distance

VR3 20120924 IR Frequency & Remote Control

Table of Contents

1. Introduction…………………………………………………........……….

2. Applications……………………..…………………………................….

3. Package Contents…………………………......…………….............…

4. System Requirements……...…………………..….…………........…….

5. Features…………………………………………….......……........………

6. Specications..………………………………………...........………...….

7. Hardware Description………………...……........….....................……

7.1 Front Panel ...............................................................................

7.2 Rear Panel …………………………………………..........…….…

8. IR Cable Pin Denitions………………...…….......….....................……

8.1 IR Receiver................................................................................

8.2 IR Blaster………………....…………………………..........…….…

8.3 IR Functioning Chart………………………………………………...

9. Remote Control …….………...................…………..........…..…..…...

10. Connection and Installation..................…………..........…..…..…...

11. Acronyms …….………...................…………..........…..…...........…...

1. Introduction

The Infrared 4 by 4 Matrix is designed to control your source devices from be-

side your display/receiver. Using the original remote, you can control DVD/

Blu-ray players, satellite and set-top-boxes and with a cross matrix design this

device gives the ability to send infrared signals from place to place. When

used with an HDMI/converter matrix, this brilliant product will allow you to

freely manage your sources and displays. Simply place the IR receiver near

the display and put the IR blaster in a position so that all devices will be able

to function properly, even when they are hidden in a cabinet or placed far

away. So if your looking for a way to extend IR control over great distances,

you have but one choice: The Infrared 4 by 4 Matrix

2. Applications

• Control multiple sources

• System Control

• Showroom control

3. Package Contents

• 4 by 4 Infrared Matrix

• Remote Control CR81-06F09 with battery

• 5V DC power adaptor

• Operation Manual

• 5xIR Receiver cables

• 5xIR Blaster cables

4. System Requirements

Source equipment: Display/ TV/monitors and HDMI/video matrix box devices.

5. Features

• Supports independent IR receiver and IR blaster selection and control

• This device does not send audio/video signals, it only transmits and

receives infrared signals to control equipment that is far away, using IR

extender cables.

• Supports a frequency of 30KHz ~ 50KHz.

• Use your existing remote controls.

6. Specications

IR Frequency 30KHz to 50KHz

Input port 4 x independent IR Blasters; 1 x total IR blaster control

Output port 4 x independent IR Receiver; 1 x total IR receiver control

Power Supply 5VDC/1A (US/EU standards, CE/FCC/UL certiﬁed)

ESD Protection Human body model: ±8kV (air-gap discharge)

±4kV (contact discharge)

Dimensions (mm) 180(W) x 124(D) x 25(H)

Weight(g) 450

Chassis Material Aluminum

Silkscreen Color Silver

Power Consumption 0.86W

Operating Temperature 0˚C~40˚C / 32˚F ~ 104˚F

Storage temperature -20˚C~60˚C / -4˚F ~ 140˚F

Relative Humidity 20~90% RH (non-condensing)

7. Hardware Description

The following sections describe the hardware components of the unit.

7.1 Front Panel

1 2 3 4 5 6

qIR sensor: To control the system.

②POWER Button & LED: Press to turn the unit on or press it again to turn it to

standby mode. When the system is on the LED will be green, when in

STANDBY mode the LED will then be red.

③IR IN 1 & output LED: Press the button to select which output IR signal will

be sent, the LED will then illuminate according to the selection.

④IR IN 2 & output LED: Press the button to select which output IR signal will

be sent, the LED will then illuminate according to the selection.

⑤IR IN 3 & output LED: Press the button to select which output IR signal will

be sent, the LED will then illuminate according to the selection.

⑥IR IN 4 & output LED: Press the button to select which output IR signal will

be sent, the LED will then illuminate according to the selection.

7.2 Rear panel

1 2 3 4 5

qIR OUT ALL: This slot is where you connect the IR blaster cable included in

the package. Place the IR blaster in direct line-of-sight of the equipment

to be controlled for it will blaster out all signal received from IR IN 1~4.

②IR OUT A~D: These slots are where you connect the IR blaster

cables included in the package. Place the IR blaster in direct line-of-sight

of the equipment to be controlled for it will blaster out the signal choosen

by IR IN 1~4.

③IR IN ALL: This slot is where you connect the IR receiver cable included in

this package for IR signal reception. Ensure that remote being used is

within the direct line-of-sight of the IR receiver for it will send out the signal

to IR out A~D.

④IR IN 1~4: These slots are where you connect the IR receiver cables

included in the package remote control. Ensure that remote being used is

within the direct line-of-sight of the IR receiver for it will send out the signal

to the selected IR out from A~D and IR OUT ALL.

⑤DC 5V: Plug the 5V DC power supply into the unit and connect the

adaptor to an AC outlet.

8. IRCablePinDenitions

8.1 IR Receiver 8.2 IR Blaster

IR Receiver

① IR signal

② Power 5V

③ Grounding

① ② ③

IR Blaster

① ②

① Power 5V

② IR Blaster Signal

③ NC

③

Note: Both the IR Receiver & Blaster can support a frequency of

30~50KHz.

8.3 IR Functioning Chart

IR OUT A IR OUT B IR OUT C IR OUT D IR OUT E

IR IN 1 ◎◎◎◎ ▲

IR IN 2 ◎◎◎◎ ▲

IR IN 3 ◎◎◎◎ ▲

IR IN 4 ◎◎◎◎ ▲

IR IN 5 △ △ △ △ △ ▲

IR Sensor X

◎: IR in can select IR out

✕: Only accepts an IR signal from the remote control included in this

products package.

△: You do not have to select IR input as this device can receive IR signals

from all IR remote controls with a frequency between 30KHz~50 KHz

▲: You do not have to select input IR as this device can send IR signals to

all sources With a frequency between 30KHz~50 KHz

9. Remote Control

1. Power: Press the button to turn on/

standby the unit.

2. IR input 1: Select for IR OUT A~D:

Press A, B, C or D to select the

desired IR out for sending a signal.

3. IR input 2: Select for IR OUT A~D:

Press A, B, C or D to select the

desired IR out for sending a signal.

4. IR input 3: Select for IR OUT A~D:

Press A, B, C or D to select the

desired IR out for sending a signal.

5. IR input 4: Select for IR OUT A~D:

Press A, B, C or D to select the

desired IR out for sending a signal.

POWER

CR-81-06F9

ABCD

INPUT

ABCD

INPUT

ABCD

INPUT

ABCD

INPUT
