D-Link AirPlus G DWL-G122 Bedienungsanleitung

AirPlusGTM

HighSpeed802.11g

USBWireless Adapter

DWL-G122

If anyofthe aboveitemsaremissing,pleasecontactyourreseller.

Thisproductworkswiththefollowingoperating

systemsoftware:WindowsXP,Windows

2000,WindowsMe,Windows98SE

BeforeYou Begin

You musthaveatleastthe following:

•You will need acomputerwithan availableUSB porttoconnectthe

DWL-G122 Wireless USB adapter.

•Atleasta500 MHzprocessorand 62 MBofmemory

•An802.11b or802.11gAccess Point(forInfrastructureMode)oranother802.

11b or802.11g wireless adapter(forAd-Hoc;Peer-to-Peernetworking mode.)

•Properlyinstalled and working USB Controller.

DWL-G122 Wireless USBAdapter

CheckYourPackageContents

Thesearethe itemsincluded withyourDWL-G122 purchase:

Cradle

CD-ROM(containing Drivers,Manualand Warranty)

@2004D-LinkSystems,Inc.Allrightsreserved.Trademarksorregisteredtrademarksarethepropertyoftheirrespectiveholders.Softwareand

specificationssubjecttochangewithoutnotice.

USBConnector

ConnectstoYours

desktop orlaptop

computerl.

DWL-G122 Overview

The Install Screen will appear.

Turnon thecomputerand

InserttheD-LinkAirPulsGTMDWL-

G122DriverCD intheCD-ROMdrive.

The step-by-stepinstructionsthatfolloware

showninWindowsXP.The stepsand screens

aresimilarfortheotherWindowsoperating

systems

InserttheD-LinkCD-ROMIntoYour

Computer

DoNOTinstall

theDWL-G122

USBAdapterintoyour

computerbefore

installing thedriver

softwareon theD-Link

CD!

Click Install Drivers

Link/PowerLED

Link-IndicatesthattheDWL-G122

isproperlyinstalled inthe computer.

Power-blinks when dataisbeing

transmitted through the wireless

connection.

Antenna

Used towirelessly

connectto802.11b

or802.11g

networks.

Click Next

If the CDAutorun function doesnot

automaticallystarton yourcomputer,

type “D:\Driver\Setup.exe”If itdoes

start, proceed tothe nextscreen.

Theletter“D”

representsthe

letteroftheCD-ROM

drive.YourCD-ROM

drive may beadifferent

drive letter.

Click Next

ClickFinish

Click No,Iwill restart

mycomputerlater

Shutdownyourcomputer

Click ContinueAnyway

InstallingtheDWL-G122 Wireless USB

AdaptertoYourLaptop Computer

A.Make suretoturnoff yourcomputer.

B.Insert one end of the USBAdapter into the provided

USB cable and plug the other end into your computer’s

USB Port.

ClickFinish

RestartYourComputer

When you restartyourcomputer

thisFound NewHardware

Wizard(WindowsXP)screen

will appear:

SelectInstall thesoftware

automatically(Recommended)

Click Next

WindowsXP will automatically

loadthe driverfiles.

Click ContinueAnyway

ForWindows2000,this

DigitalSignatureNot

Found screen mayappear

during the installation.

Click Yes tocontinue

the installation

YourInstallationisComplete!

Afteryou’vecontinued inWindowsXP (orafterthe computerrestartsinthe

otherWindowsoperating systems),theD-LinkAirPlusDWL-G122 Con-

figuration Utilitywill automaticallystartand the utilityicon will appearin

the bottomrighthand cornerofthe desktop screen (systray).Ifthisicon

appearsGREEN,thenyou have successfullyinstalledtheDWL-G122,

areconnectedtoawireless networkand arereadytocommunicate!

Double-click theutilityicon touse

theconfiguration utility.

ForWindowsMeand 98,this

screenmay appear.

Click Yes tofinalizethe

installation

Appendix

UsingtheConfigurationUtility

A.Status:Displays the

MACAddress ofthe

Access Pointthatis

associated withthe

DWL-G122.

B.SSID:The ServiceSetIdentifier

isthe nameassigned tothe

wireless network.The factory

SSIDsetting issettodefault.

C.Frequency:

Displays the current

frequency used by

the adapter.

D.Wireless Mode:The factorysetting issettoInfrastructure.Ad-Hocmode isused for

peer-to-peernetworking.

F. ConnectionInfo:

Displays connected or

authenticated

information.

I. Signal

Strength/Link

Quality:Repre-

sentsthe

wireless signal

qualityand

strengthbetween

the access point

and the DWL-

G122.The

percentage

coincideswith

the graphicalbar.

H.Channel:Displays

the channel

information.By

default, the channel

issetto6.Please

notethatthe DWL-

G122 will automati-

callyadjustchannel

depending on the

Access Point.

E.Encryption:Displays the currentencryption statusofthe wireless connection.

G. TxRate:The

defaultsetting is

Auto;meaning,

TxRatesettings

areautomatically

determined by

the DWL-G122

depending on the

distancefromthe

access point.

J.PacketCount: Graphicallydisplays the statistics ofdata

transmitted and received.

Appendix

UsingtheConfigurationUtility(cont.)

L.Wireless Mode:

The factorysetting is

settoInfrastructure.

Ad-Hocmode isused

forpeer-to-peer

networking.

N.Authentication:You can specify

the authentication mode forthe

wireless network.The default

setting issettoOpenAuthentica-

tion.

O.Key Length:When encryption isenabled,

you will havethe option tospecifythe leveland

keyformatofthe encryption used.Selectthe

appropriateKeyIndex:1-4and enterACSII or

hexadecimaldigitsinthe appropriatefield.

K.SSID:The ServiceSet

Identifieristhe nameas-

signed tothe wireless

network.The factorySSID

setting issettodefault.Make

changesheretomatchthe

SSIDon existing Wireless

RouterorAccess Point.

M.DataEncryption:The

defaultsetting issetto

Disabled.The adapter

supportsWEP when

encryption isenabled.

P.IEEE 802.1x:When encryption isenabled,you will havethe option tospecifythe level

and keyformatofthe encryption used.Selectthe appropriateKeyIndex:1-4and enter

ACSII orhexadecimaldigitsinthe appropriatefield.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by

the party responsible for compliance could void the user's authority to

operate this equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for

an uncontrolled environment. End users must follow the specific operating

instructions for satisfying RF exposure compliance.

This transmitter must not be co-located or operating in conjunction with

any other antenna or transmitter.

"D-Link declare that DWL-G122 (802.11g/2.4GHz Wireless USB Adapter)

is limited in CH1~CH11 by specified firmware controlled in USA."

The equipment has been SAR-evaluated and authorized for use in laptops / notebook
