2D-Link DWA-142 Quick Install Guide

• A computer or laptop with an available USB 2.0 port

• Windows®2000 (SP4) or XP (SP2)

• 300MHz processor and at least 32MB of RAM

• Properly installed and working USB Controller

• A draft 802.11n or 802.11b/g access point (for Infrastructure mode),

or another draft 802.11n wireless adapter (for Ad-Hoc networking

mode).

Package Contents

D-Link DWA-142

Wireless USB Adapter

System Requirements

If any of the above items are missing, please contact your reseller.

Manual, Software, and

Warranty on CD

NOTE: This product is based on IEEE draft 802.11n specifications and is not

guaranteed to be forward compatible with future versions of IEEE 802.11n

speciﬁcations. Compatibility with draft 802.11n devices from other manufacturers is

not guaranteed.

3 D-Link DWA-142 Quick Install Guide

Adapter Installation

Warning: Do NOT install the DWA-142 USB Adapter into your

computer before installing the driver software from the D-Link CD.

Turn on the computer and Insert the D-Link DWA-142 Driver CD in the

CD-ROM drive. The step-by-step instructions that follow are shown in

Windows XP.The steps and screens are similar for the other Windows

operating systems.

If the CD Autorun function does not automatically start on your

computer, go to Start > Run. In the run box type “D:\DWA142.exe”

(where D: represents the drive letter of your CD-ROM drive).

When the autorun screen appears, click Install Drivers.

4D-Link DWA-142 Quick Install Guide

The InstallShield Wizard window

will appear.

By default setup will install to

the default location: C:\Program

Files\D-Link\DWA-142, where C:

represents the drive letter of your

hard drive. To install to a different

location click Browse and specify

the location.

Select the Program Files folder

location.

Click Next

5 D-Link DWA-142 Quick Install Guide

The D-Link Conﬁguration Wizard

will now appear.

If you are using Windows®XP

(SP2), you will have the option to

use either the D-Link utility or the

built-in Windows®Wireless utility.

Insert the adapter into an available

USB port on your computer.

If the Found New Hardware Wizard

appears, click Cancel.

Enter the network name (SSID)

manually. If you enter the SSID

incorrectly, you will automatically

be brought to the site survey page.

Click Scan to display the site

survey page.

Click Next

6D-Link DWA-142 Quick Install Guide

Click on the network name (SSID)

and click Next.

Click Finish to continue. If you are

prompted to reboot your computer,

select Yes, I want to restart my

computer now.

Click Next

Click Finish

7 D-Link DWA-142 Quick Install Guide

Windows®XP users may use the built-in wireless utility.The following

instructions are for Service Pack 2 users.

If you are using Windows®2000, you must use the D-Link utility.

(Please refer to page 9).

If you receive the Wireless Networks Detected bubble, click on the

center of the bubble to access the utility.

Connect to a Wireless Network

You may also right-click on the wireless computer icon in your system

tray (lower-right corner next to the time). Select View Available

Wireless Networks.

Windows®XP Conﬁguration Utility

8D-Link DWA-142 Quick Install Guide

The Wireless Connection Manager will display any available wireless

networks in your area. Click on a network and click the Connect

button.

Refer to the Wireless Security section in the manual for information

on connecting to a secure network.

9 D-Link DWA-142 Quick Install Guide

The DWA-142 uses the D-Link Wireless Connection Manager

as the management software. The manager provides the user

an easy interface to change any settings related to the wireless

adapter. Clicking on the D-Link icon on your desktop will start the

Conﬁguration.

To disable the Windows®XP wireless utility, and use the D-Link

Wireless Connection Manager, follow the steps below:

Right-click on the wireless computer icon in your system tray (lower-right

corner next to the time). Select View Available Wireless Networks.

In the Choose aWireless Network window click Change Advanced

Settings on the left side below Related Tasks.

Connect to a Wireless Network

Wireless Connection Manager

10D-Link DWA-142 Quick Install Guide

In the Wireless Network Connection Properties window, uncheck

Use Windows®to conﬁgure my wireless network settings and

then click OK.

Double-click the Wlreless Connection Manager icon on your desktop

to start the Conﬁguration.

This window will allow you to see available wireless networks in your

area. Simply click the network (SSID) you want to connect to and

click the Connect button.
