D-Link PersonalAir DBT-320 Bedienungsanleitung
PersonalAir™Bluetooth USB
Printer Adapter
DBT-320
This product works with
Bluetooth enabled PC’s with the
following operating systems:
Windows98SE,Me,2000,andXP.
BeforeYouBegin
Youmusthaveatleastthefollowing:
•BluetoothEnabledPCSupportingHCRPandSPPBluetoothProfiles
forPrinting,BluetoothEnabledMobilePhone,orBluetoothenabledPDA.
•USBPrinter*withOneAvailableTypeBUSBPort.
(*PCL3 Printer is required for Printing from Cell Phone or PDA)
DBT-320 Bluetooth USB PrinterAdapter
Wall Mount Cradle
©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their
respective holders. Software and specifications subject to change without notice. DBT-320. 03052004
CheckYour Package Contents
These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.
Using a power supply
with a different voltage
rating will damage this
productandvoidthewarranty.
AC Power Adapter
2
Installing the DBT-320
Plug the DBT-320 Type B
USBconnectorintotheType
B USB port located on the
back of your printer.
Using the included power
adapter, connect the yellow
coded plug to the yellow
powerconnectorportonthe
DBT-320 and the other end
ofthepowerconnectortoan
available power strip or
outlet.
The DBT-320 Bluetooth USB Printer Adapter set up is now complete!
You will now be able to enjoy wireless printing from your cell phone, PDA,
laptop, or computer with the DBT-320 Bluetooth USB PrinterAdapter.
3
DBT-320LEDIndicators
Power
Indicator
Bluetooth
Link
Indicator
The DBT-320 features two LED indicators, the Ready LED and the BT LED.
• The Ready LED indicator will light solid green when the DBT-320 is
powered on with the external power adapter. When the printer is powered
on,ablinkinggreenReadyLEDindicatesasuccessfulprinterconnection.
• TheBTIndicatorwillblinkgreenwhenafileisbeingsenttotheprinterfroma
laptop,computer,PDA,orcellphone.
Printing from your Laptop/PC using
the DBT-320
Your Bluetooth enabled laptop or computer will have Bluetooth software
thatwillenableyoutoconnecttotheDBT-320printeradapter.Theinstructions
onthefollowingpagearebasedonaD-LinkDBT-120USBBluetoothadapter
used with a PC running Windows XP with Widcomm Bluetooth Software
v1.4.2.10. DependingontheBluetoothsetuponyoursystem,theinstallation
proceduremayvaryslightly.
4
Click Search for
devices in range
Ifdetected, the D-LinkDBT-
320 printer icon will be
displayed. If the DBT-320 is
not detected, press F5 on
your keyboard or right click
on the mouse and select
refresh to search again.
Double Click to
installprinterdrivers
Double-click the Bluetooth icon
on your desktop or in the systray
to access My Bluetooth Places
My Bluetooth Places is also accessible from the Start Menu:
Go to Start > Programs > My Bluetooth Places
Printing from your Laptop/PC using
the DBT-320(continued)
*Note:If the printeris beingused by another Bluetooth user, you will not
be able to detect the DBT-320.
5
Click Have Disk
SelecttheManufacturer
of your printer and your
printermodel.
Click Browse
Click Browse to search
foryourprinterdrivers.
Printing from your Laptop/PC using
the DBT-320(continued)
Highlighttheprinteryou
areusinginthePrinters
list.
Click OK
Click OK
6
Printing from your Mobile Phone
Toprintfromyourmobilephone,besurethat youhaveatleastthefollowing:
•Bluetoothenabledmobilephone supportingtheBluetoothObjectPush
Profile.Thisenables theprintingofbusiness cardsfromyour mobile
phone.
•PCL3 printer
TheBluetoothprintingprocedurewillvarydependingonthemanufacturer
of your mobile phone. Please check your mobile phone manual or with
yourmanufacturerforspecificdirections on howtoprint.
Click Print Test Page
The printer properties window will be
displayedonceyourprinterisinstalled.
YoucanclickonPrint TestPage totest
yourconnectiontotheDBT-320.
Printing from your Laptop/PC using
the DBT-320(continued)
7
ToprintfromyourPDA, be surethatyouhaveatleastthe following:
•BluetoothenabledPDA
•BluetoothSoftwaresupportingthe Object Push Profile
•Printing software (i.e. PrintPocket CE for PDAs running Pocket PC
2002or2000,BTPrintforPalmsrunningPalmOS4.xorOS5.x,iPAQs
runningPocket PC2003)
•PCL3 printer
TheBluetoothprintingprocedurewillvarydependingonthemanufacturer
of your PDA and software that you are using. Please check your PDA
manualorwithyourmanufacturer for specific directionsonhowtoprint.
PrintingfromyourPDA
TroubleshootingTips
If youarehavingtroubleprintingwiththeDBT-320check the following:
•Makesureyour printeristurned on andtheReady LEDonthe DBT-
320isgreen.IftheReadyLEDisnotgreen,checkyourUSBconnection
totheprinter.
•MakesuretheBluetoothiconon the screen ofyourlaptop,computer,
mobile phone, or PDA is white. This means that the Bluetooth
application is ready. If the Bluetooth icon is not white, try rebooting
yourBluetoothmobiledeviceand/orreinstallingyourBluetoothsoftware.
Check that your Bluetooth software supports the HCRP, and SPP
Bluetoothprofilesforprinting.
•IftheBluetooth icon isred,theDBT-320 isnotproperlyconnected.
Check the DBT-320 connection to your printer and your printer
connection.
•Whenprinting,theBluetoothiconwillblinkGreen. IftheBluetoothLED
isnotflashingon,checkyourDBT-320connectionto the printer.Your
printer may also not be configured correctly. Check your printer
configuration.
8
Technical Support
You can find software updates and user documentation on the D-Link website.
D-Linkprovides free technical support forcustomers within the United States and
withinCanada for the durationof the warranty period onthis product.
U.S. and Canadian customers can contact D-LinkTechnical Support through our
website,or by phone.
Tech Support for customers within the United States:
D-Link Technical Support over the Telephone:
(877)453-5465
24 hours a day, seven days a week.
D-Link Technical Support over the Internet:
http://support.dlink.com
email:[email protected]
Tech Support for customers within Canada:
D-Link Technical Support over the Telephone:
(800)361-5265
Monday to Friday 8:30am to 9:00pm EST
D-Link Technical Support over the Internet:
http://support.dlink.ca
email:[email protected]
TechnicalSupport
You can find software updates and user documentation on the D-Link website.
D-Link provides free technical support for customers within the United States and
within Canada for the duration of the warranty period on this product.
U.S. and Canadian customers can contact D-Link Technical Support through our
website, or by phone.
Tech Support for customers within the United States:
D-Link Technical Support over the Telephone:
(877) 453-5465
24 hours a day, seven days a week.
D-Link Technical Support over the Internet:
http://support.dlink.com
email:[email protected]
Tech Support for customers within Canada:
D-Link Technical Support over the Telephone:
(800) 361-5265
Monday to Friday 8:30am to 9:00pm EST
D-Link Technical Support over the Internet:
http://support.dlink.ca
email:[email protected]
