D-Link AirPlus DWL-900AP+ Bedienungsanleitung

Before You Begin

It’s best to use a computer (with an Ethernet adapter) that is connected to a router for

configuring the DWL-900AP+. The default IP address for the DWL-900AP+ is

192.168.0.50 with a Subnet Mask of 255.255.255.0. You will need to assign your

computer a Static IP address within the same range as the DWL-900AP+’s IP address

for the purpose of configuration of the DWL-900AP+. See the Manual on the CD-ROM

if you need assistance in assigning a Static IP address for your network adapter.

Check Your Package Contents

These are the items included with your DWL-900AP+ purchase:

If any of the above items are missing, please contact your reseller.

holders. Software and specifications subject to change without notice. DWL-900AP+.10042002

This product can be set up using any

current web browser, i.e., Internet

Explorer 5x, Netscape Navigator 4x.

-900AP+

D-Link AirPlus™

Wireless Access Poin

• DWL-900AP+ Wireless Access Point

• CD-ROM (containing Manual and Warranty)

• Ethernet (CAT5 UTP/Straight Through) Cable

• 5V DC, 2A Power Adapter

Using a powe

supply with a

different voltage rating

will damage and void

the warranty for this

product.

When connecting

the DWL-900AP+

Wireless Access Point to

an Ethernet Adapter in a

computer, use a Cross-

Over Ethernet cable.

Connecting The DWL-900AP+ Wireless

Access Point To Your Network

A. First, connect the power adapter to the receptor at the back panel of

the DWL-900AP+ and then plug the other end of the power adapter to

a wall outlet or power strip. The Power LED will turn ON to indicate

proper operation.

B. Using a Straight-Through Ethernet

cable, insert one end of the cable to the

Ethernet port on the back panel of the

DWL-900AP+ and the other end of the

cable to an Ethernet Broadband

Router (i.e., D-Link DI-604) or Switch

(i.e., D-Link DSS-5+). Note: The router

or switch must be connected to the computer to be used to configure

the DWL-900AP+. The Link LED light will illuminate to indicate a

proper Ethernet connection.

C. Computers with 802.11b wireless adapters can connect to the DWL-

900AP+. The DWL-650+ AirPlus Wireless Cardbus Adapter and the

DWL-520+ AirPlus Wireless PCI Adapter will connect, out of the

box

, with the DWL-900AP+, using their default wireless settings.

A.Receptor

for Power

Adapter

Reset Button

Pressing this button

restores the DWL-

900AP+ to its original

factory default

settings.

C.Antenna

Used to wirelessly

connect to

802.11b adapters.

B.Ethernet Port

This is the connection for

the Ethernet Cable to the

Ethernet port on the

Ethernet Broadband

Router or Switch.

When you have completed

the steps in this Quick

Installation Guide, your

connected network should

look similar to this:

Using The Setup Wizard

Open your Web

browser and type

“http://192.168.0.50”

into the URL address

box. Then press the Enter

or Return key.

Type “admin” for the

username and leave the

password field blank.

Click OK

The logon pop-up

screen will appear.

Using The Setup Wizard (continued)

Click Run Wizard

Click Next

You will see the following

screens.

Once you have

logged in, the

Home screen

will appear.

Click Next

Step 1 - Set up your new

password. You have the

option to establish a

password.

Step 2 - Wireless Setup

The default wireless settings are:

SSID = default

Channel = 6

You can change these settings

to match an existing wireless

network.

Step 3 - Encryption

The DWL-900AP+ is capable

of three levels of wireless

encryption - 64-bit, 128-bit,

and 256-bit. By default the

encryption is disabled. You

can change the encryption

settings for more secure

wireless communication.

Your Setup is Complete!

You will be returned to the Home tab.

Click Restart

Click Close

For additional settings or information, refer to the Advanced, Tools, or Status tabs on

the web-management interface; or to the manual located on the CD-ROM.

Click Exit

For managing several DWL-900AP+s, please utilize the D-

Link AirPlus AP Manager. Please refer to the manual for

installing and configuring the AP Manager. For the latest

version of the firmware or AP manager please go to

http://support.dlink.com

Technical Suppor

You can find the most recent software and user

documentation on the D-Link website.

D-Link provides free technical support for customers

within the United States for the duration of the

warranty period on this product.

U.S. customers can contact D-Link technical support

through our web site or by phone.

D-Link Technical Support over the Telephone:

(877) 453-5465

24 hours a day, seven days a week

D-Link Technical Support over the Internet:

http://support.dlink.com

email: [email protected]
