The emergency release switch provides power directly to the door release
actuator. The switch bypasses the remote system, so it will operate when the system is
disabled by the ignition being on.
On vehicles with suicide doors, we recommend using a mechanical sliding dead
bolt lock to ensure that there is no way for the doors to open while the vehicle is going
down the road.
BATTERY REPLACEMENT
Should the transmitter function become weak or erratic, the battery in the key chain transmitter may be weak. An indication of a weak battery is
that the red indicator may have a dim glow to it when either button is pressed. If this occurs, first check the system by using the second transmitter
provided. If the second transmitter function properly, replace the battery in the defective transmitter by the following method:
A. Remove the small screw on the back of the transmitter case.
B. Carefully separate the two case halves.
C. Remove the battery noting the (+) and (-) position.
D. Replace the battery with a new 12 volt type GP23A battery which is available at most electronic stores (Radio Shack, etc.).
E. Carefully replace the top cover and refasten the screw.
F. Check transmitter function. Should the transmitter still fail to function, it is possible the transmitter frequency is out of adjustment. To correct
this problem, refer to "Transmitter Adjustment".
TRANSMITTER ADJUSTMENT
Should one of your transmitters fail to operate properly while the second works correctly and battery replacement has not corrected the problem,
the transmitter frequency may be out of adjustment. To correct this, perform the following:
A. Open the defective key chain transmitter as explained in battery replacement.
B. Locate the small blue frequency fine-tune adjustment trimmer on the circuit board inside the transmitter.
C. Using a small non-metallic adjustment tool, turn the adjusting screw inside the blue trimmer a 1/8 turn clockwise.
A. D. Depress black button and check if the driver's door releases. If not, turn the adjustment screw an additional 1/8 turn clockwise
and recheck. After turning the screw a total 1/2 turn clockwise, return to its starting position and repeat the adjustment by turning it counter-
clockwise in the same manner.
B. E. Once the system releases the door, stop and re-close the case. If the adjustment fails to correct the problem, return the defective
transmitter for servicing.
CMD-3000 REMOTE CONTROL DOOR OPENER SYSTEM
LIMITED LIFETIME WARRANTY
DAKOTA DIGITAL, INC. (the Company) warrants to the ORIGINAL PURCHASER of this remote control product that should any included control
relay(s), electronic module, or transmitters under normal use and condition, be proven defective in material or workmanship DURING THE LIFETIME
OF THE CAR IN WHICH IT WAS ORIGINALLY INSTALLED, such defect(s) will be repaired or replaced (at the Company's option) without charge for
parts or labor directly related to repairs of the defect(s).
To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty coverage (e.g. dated bill of
sale), specification of defect(s), transportation prepaid, to the factory. This Warranty is valid for the original purchaser only and may not be
transferred.
This Warranty does not cover batteries, nor extend to damage to vehicle electrical system. This Warranty does not apply to any product or part
thereof which in the opinion of the Company has been damaged through alteration, improper installation, mishandling, misuse, neglect, or accident.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY
WARRANTY HEREUNDER INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 30
MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESSED OR IMPLIED, WHATSOEVER. No person or
representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.
The Company does not warrant that this product cannot be compromised or circumvented. THE EXTENT OF THE COMPANY'S LIABILITY
UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S
LIABILITY EXCEED THE PURCHASE PRICE PAID BY THE PURCHASER FOR THE PRODUCT.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation if incidental or consequential damage so
the above limitations or exclusion may not apply to you. This Warranty gives you specific legal rights and you may also have other rights which vary
from state to state.
