Danby DAR033A1BBUD1 Montageanleitung

OWNER’S USE AND CARE GUIDE

GUIDE D’UTILISATION ET D'ENTRETIEN

GUÍA DE UTILIZACIÓN Y CUIDADO PARA EL PROPIETARIO

MODEL • MODÈLE • MODELO

DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9

DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840

ALL REFRIGERATOR

TOUT RÉFRIGÉRATEUR

TODA REFRIGERADORA

DAR033A1BBUD1

DAR033A1BBUD2

2016.01.14

DO NOT RETURN THIS UNIT TO THE RETAILER

WITHOUT FURTHER INSTRUCTIONS

Dear valued customer, we hope your Danby product purchase fulfills all

your requirements. Your satisfaction is our priority!

Please contact us at our toll free consumer service number for any inquiries

you may have about your new unit.

NE PAS RETOURNER CET APPAREIL CHEZ LE

DÉTAILLANT SANS CONSIGNES SUPPLÉMENTAIRES

Cher(ère) client(e) important(e), nous espérons que votre produit Danby

répond à tous vos besoins. Votre satisfaction est notre priorité!

Veuillez nous contacter au numéro gratuit de service après-vente, si

vous avez des questions quelconques à propos de votre nouvel appareil.

NO DEVUELVA ESTA UNIDAD A LA TIENDA SIN

INSTRUCCIONES ADICIONALES

Estimado cliente, esperamos que el producto Danby que ha comprado

satisfaga completamente sus necesidades. Su satisfacción

es nuestra prioridad!

Por favor, contáctenos gratuitamente a nuestro número de Servicio al

Cliente para cualquier pregunta que tenga sobre su nuevo electrodoméstico.

1-800-263-2629

(1-800-26-DANBY)

Danby 28.08.2014

CONTENTS

TABLE DES MATIÈRES

ALL REFRIGERADOR

Owner’s Use and Care Guide ........................................1-9

• Welcome

• Important Safety Information

• Features

• Installation Instructions

• Operation Instructions

• Care and Maintenance

• Troubleshooting

• Warranty

TOUT RÉFRIGÉRATEUR

Guide d’utilisation et d’entretien du propriétaire......10-18

• Bienvenue

• Consignes de sécurité importantes

• Caractéristiques

• Consignes d’installation

• Consignes d’utilisation

• Soins et entretien

• Dépannage

• Garantie

TODA REFRIGERADORA

Guía de utilización y cuidado para el propietario.....19-27

• Bienvenido

• Información importante sobre seguridad

• Características

• Instrucciones de instalación

• Instrucciones de funcionamiento

• Cuidado y mantenimiento

• Solución sugerida

• Garantía

Model • Modèle • Modelo

DAR033A1BBUD1 / DAR033A1BBUD2

CAUTION:

Read and follow all safety rules and operating

instructions before ﬁrst use of this product.

PRÉCAUTION :

Veuillez lire attentivement les consignes de

sécurité et les instructions d’utilisation avant

l’utilisation initiale de ce produit.

PRECAUCIÓN:

Lea y observe todas las reglas de seguridad y

las instrucciones de operación antes de usar

este producto por primera vez.

ÍNDICE

Thank you for choosing Danby

We know you’re excited. We are too! However, the more familiar you are with your new appliance, the better experience you will

have. We therefore strongly suggest that you read this Owner’s Manual before plugging in your new appliance. It contains

important operational information that will help you make full use of the technical features available in your Danby appliance. The

manual also contains information designed to enhance operating reliability and safety, as well as tips to maintaining your new

appliance so that it brings you happiness for years to come.

Please visit www.danby.com to access self-service tools, FAQs and more. Should you need additional assistance, please call

1-800-26-DANBY (1-800-263-2629).

Note: You will need the below information to obtain service under warranty.

To receive service, you must provide the original receipt.

Model Number:

Serial Number:

Date of Purchase:

NEED HELP?

Before you call for service, here are a few things you can do to help us serve you

better:

Read this Owner’s Manual:

It contains instructions to help you use and maintain your appliance properly.

If you received a damaged appliance:

Immediately contact the retailer (or builder) that sold you the appliance.

Save time and money:

Check the Troubleshooting section at the end of the guide before calling. This section

helps you solve common problems that may occur.

If you do need service, you can relax, knowing help is only a phone call away.

Tel:1-800-26-

(1-800-263-2629)

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of

electrical shock by providing an escape wire for the electrical current.

ELECTRICAL REQUIREMENTS

WARNING

ELECTRICAL RATING: The serial rating plate indicates the

voltage and frequency the unit is designed for.

Due to possible variations in line voltage (caused by overloading of circuits), it is advisable to install a separate fuse cir-

cuit from the meter panel. This will help to eliminate current ﬂuctuation which might cause motor trouble.

IMPORTANT WARNING

An empty refrigerator is a very dangerous attraction to children. Remove either the gasket or lid from

unused appliances, or take some other action that will guarantee it harmless.

DANGER: Risk of child entrapment. Before you throw away your old refrigerator:

• Take off doors.

• Leave the shelves in place so that children may not easily climb in.

DON’T WAIT! DO IT NOW!

WARNING! EXPLOSION HAZARD!

Risk of ﬁre or explosion due to puncturing of refrigerant tubing. Do not use sharp objects to aid in

defrost. Please handle with care. Keep ﬂammable materials and vapors such as gasoline away from

the refrigerator. Use nonﬂammable cleaner.

Disposal of this unit should be in accordance with federal and local regulations.

Please ensure that component parts shall be replaced with like components and that servicing shall be done by

factory authorized service personnel, so as to minimize the risk of possible ignition due to incorrect parts or

improper service.

GROUNDING INSTRUCTIONS

This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an

outlet that is properly installed and grounded.

WARNING - Improper use of the grounding plug can result in a risk of electric shock. Consult a qualiﬁed electrician or

service agent if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is

properly grounded.

DO NOT USE AN EXTENSION CORD

Use an exclusive 115V wall outlet. Do not connect your refrigerator to extension cords or together with another appliance

in the same wall outlet. Do not splice the cord.

SAVE THESE INSTRUCTIONS!

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

• Try not to open the door too often, especially when the weather is hot and humid. Once you open the door, close it as

soon as possible.

• Every now and then check if the appliance is sufﬁciently ventilated (adequate air circulation behind the appliance).

• Set the thermostat from cooler to warmer settings whenever possible (depending on how loaded the appliance is,

ambient temperatures etc.).

• Before loading the appliance with packages of hot food, make sure that they are cooled to ambient temperature.

• Ice and frost layers increase energy consumption, so clean the appliance as soon as the frost layer is 3-5 mm thick.

• If the gasket is damaged or the door seal is poor, energy consumption is substantially higher. To restore efﬁciency,

replace the gasket.

• Always consider instructions stated in this manual.

• This unit is not designed for outside installation, including installation anywhere that is not temperature controlled

(including garages, porches, carports, etc.).

ENERGY SAVING TIPS

The refrigerator system of the appliance is ﬁlled with refrigerant and insulating substances which should be separately

treated and processed. Call your nearest authorized service agent or specialized servicing centre. If you are unable to

locate one, contact your local authorities or your distributor. Be careful not to damage any tubes that may be on the rear

wall of the appliance.

DISPOSING OF YOUR OLD APPLIANCE

SAVE THESE INSTRUCTIONS!

Installation Instructions

1. Select a place with a strong, level ﬂoor.

2. Allow 5 inches (12.7 cm) of space between the back of the refrigerator and any adjacent wall.

3. Avoid direct sunlight and heat. Direct sunlight could damage the unit. Heat sources nearby will cause higher electrici-

ty consumption.

4. Avoid moist places. Too much moisture in the air will cause frost to form very quickly on the evaporator, and your

refrigerator will have to be defrosted more frequently.

LOCATION

Remove exterior and interior packaging, wipe the outside thoroughly with a soft dry cloth and the inside with a luke-

warm, wet cloth. Avoid placing the unit in a narrow recess or near any heat source, direct sunlight or moisture. Let air

circulate freely around the unit. Keep the rear of the refrigerator 5 inches (12.7 cm) away from the wall.

1. Adjustable Shelves: Shelf can be optionally placed on the guides inside the appliance. Perishable foods should be

stored towards the back/rear of the shelves.

2. Door Liner: The door liner consists of various shelves or holders used for storing effs, cheese, butter and yougurt as

well as other smaller packages, tubes, cans etc. The lower shelf is used for storing large bottles.

3. Defrost Water Outlet: The interior of the refrigerator is cooled with a cooling plate mounted in the rear wall. Under

the plate there is a channel and an outlet for defrost water. Regularly check the defrost water outlet and the drain

channel for blockage. They should always be kept free and clear of food particles. If the drain outlet does become

clogged, use a plastic straw or pipe-cleaner to clear it.

FEATURES

Place the appliance ﬁrmly on a solid base. Some appliances have adjustable feet on the front side; use them to level the

appliance (some models only).

NOTE: This appliance is intended for FREE-STANDING INSTALLATION ONLY, and is NOT intended to be built-in.

This appliance is approved for INDOOR USE ONLY and is NOT intended for outdoor operation.

INSTALLATION

Operating Instructions

TEMPERATURE SELECTION

DEFROSTING YOUR APPLIANCE

The temperature of the refrigerator is controlled by setting the thermostat knob (on

the ceiling of the cabinet) to a desired setting.

To start the refrigerator, turn the temperature control knob to the position correspond-

ing to the desired cooling setting (on the graduated blue dial, Fig. A).

The refrigerator temperature will vary depending on the quantity of food stored and

on the frequency with which the door is opened.

To turn the control to the “OFF” position, rotate the control knob to the “0” position. If

the refrigerator is not going to be used for long time periods, disconnect the plug and

leave the door partially open. This will help to prevent mold/mildew from accumulat-

ing inside the refrigerator cabinet.

Changes in ambient room temperature will affect internal refrigerator temperatures,

adjust the thermostat knob accordingly. In the OFF (0) position, the appliance does

not operate (cooling system is switched off,) yet the power supply is not interrupted

(the light is on when you open the refrigerator door.) Temperature in the refrigerator

is dependent on how often the door is opened.

There is no need to defrost the refrigerator, because ice deposits on the inner back wall are defrosted automatically.

Ice build-up on the inner back wall during the compressor operation will defrost automatically (when the compressor has

cycled off). Defrost water collects inside the drain passing through the drain outlet in the inner back wall into a drain pan

situated above the compressor from where it evaporates.

FOOD STORAGE SUGGESTIONS

Fresh Food Compartment

• Never cover food compartment shelves with aluminum foil or any other shelf covering material which may prevent air

circulation.

• Always remove porous store wrapping paper from meats, poultry and ﬁsh. Meats should be wrapped individually and

placed in a dish for storage. Wrap ﬁsh and poultry in foil or heavy waxed paper. Most ﬁsh should be used the same

day of purchase. Packaged meats such as ham, bacon, dried beef, or frankfurter, store best in their original packag-

es.

• Allow warm foods to cool to room temperature before placing them in the refrigerator.

• Always cover open dishes of food, especially leftovers. Use leftovers within 2 or 3 days.

Max

Min

DOOR REVERSAL INSTRUCTIONS

CAUTION

To avoid personal injury to yourself and/or property, we recom-

mend someone assist you during the door reversal process.

If you ﬁnd the direction of opening the door on your appliance inconvenient, you can change it by following the steps

shown in the diagrams.

Operating Instructions

Before replacing the light bulb, disconnect the appliance from the power supply. Using a phillips screwdriver, remove the

screw located on the light cover. Pull the light cover straight down. The replacement light bulb must be the same wattage

as the original bulb (15 watts only). Replace the cover in the opposite order of removal.

BULB REPLACEMENT

Care and Maintenance

SOME IMPORTANT RULES FOR THE CORRECT USE OF

THE REFRIGERATOR

• Never place hot foods in the refrigerator.

• Never place spoiled foods in the refrigerator.

• Don’t overload the refrigerator.

• Don’t open the door unless necessary.

• Should the refrigerator be stored without use for long

periods, it is suggested, after a careful cleaning, to leave

the door ajar to allow the air to circulate inside the unit in

order to avoid possible formations of condensation, mold or

odors.

• Turn the temperature control to the “OFF” or “0” position, unplug the unit and remove the food and interior accesso-

ries.

• Wash the inside with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking

soda to a quart of water.

• Wash the baskets and interior accessories with a mild detergent solution.

• The outside of the unit should be cleaned with mild detergent and warm water.

Caution: Failure to unplug the appliance could result in electrical shock or personal injury.

CLEANING THE APPLIANCE

Most power failures are corrected within a few hours and should not affect the temperature of your refrigerator and/or

freezer if you minimize the number of times the door is opened. If the power is going to be off for a longer period of time,

you need to take the proper steps to protect your food.

POWER FAILURE

Short vacations: Leave the unit operating during vacations of less than three weeks.

Long vacations: If the appliance will not be used for several months, remove all food and unplug the power cord. Clean

and dry the interior thoroughly. To prevent odor and mold growth, leave the door open slightly, blocking it open if neces-

sary.

VACATION TIME

Remove or securely fasten down all loose items inside the unit. To avoid damaging the leveling legs (some models), turn

them all the way into the base.

IF YOU MOVE

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Danby Kühlschrank Handbücher

Danby

Danby DFF180E1WDB Bedienungsanleitung

Danby

Danby DAG026A2BDB Bedienungsanleitung

Danby

Danby One PLUG 3.1SM6R Bedienungsanleitung

Danby

Danby Diplomat DAR0488BL Bedienungsanleitung

Danby

Danby DFF101E1WDB Bedienungsanleitung

Danby

Danby DFF092C1WDB Bedienungsanleitung

Danby

Danby Designer DAR1102W Bedienungsanleitung

Danby

Danby Designer DCR122BSLDD Montageanleitung

Danby

Danby DFF142E1WDB Bedienungsanleitung

Danby

Danby Designer DCR054BL Bedienungsanleitung

Danby

Danby DCR016C1WDB Bedienungsanleitung

Danby

Danby DAR017A3WDB Bedienungsanleitung

Danby

Danby DCR059WE Bedienungsanleitung

Danby

Danby DAR016A1BDB Bedienungsanleitung

Danby

Danby DFF116B1WDBL Bedienungsanleitung

Danby

Danby DCR016A3WDEDB Montageanleitung

Danby

Danby DCR055 Bedienungsanleitung

Danby

Danby CONTEMPORARY CLASSIC DAR110A2LDB Bedienungsanleitung

Danby

Danby DAR017A3BDB-6 Bedienungsanleitung

Danby

Danby DFF123C2WDD Montageanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Danby

Danby DCR34 Bedienungsanleitung

Danby

Danby DAR110A1WDD Montageanleitung

Danby

Danby DFF100C2WDD Montageanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung
