OWNER’S MANUAL

CAUTION:

Read and Follow All Safety Rules

and Operating Instructions Before

First Use of This Product.

SAVE THESE INSTRUCTIONS!

Table of Contents . . . . . . . . . . . . . . . . . . . . 1

Danby Products Limited, Guelph, Ontario Canada N1H 6Z9

Danby Products Inc., Findlay,Ohio USA 45840

Version 1.08.06

DBC128BLS

Important Safety Information

Safety Precautions 3

Grounding Instructions 4

Location 4

Operating Instructions

Features of Your Beverage Center 5

The Controls of Your Beverage Center 6

Setting the Temperature 6

Can Storage 7

Shelf Instructions 7

Installation Instructions

Door Swing Reversal 8

Care and Cleaning

Helpful Hints 9

How to Clean the Inside 9

How to Clean the Outside 9

Trouble Shooting

Before Your Call For Service 10

TABLE OF CONTENTS

WELCOME

NEED HELP?

Welcome to the

Danby family. We’re

proud of our quality

products and we

believe in dependable

service.

You’ll see it in this

easy-to-use manual

and you’ll hear it in the

friendly voices of our

consumer service

department.

Tel:1-800-26-

Best of all, you’ll

experience these

values each time you

use your Beverage

Center. That’s impor-

tant, because your

new appliance will be

part of your family for

along time.

Before you call for service,

there are a few things you

can do to help us serve

you better...

Read this manual

It contains instructions to

help you use and maintain

your Beverage Center

properly.

If you received a

damaged appliance

Immediately contact the

dealer (or builder) that sold

you the appliance.

Save time and money

Check the Trouble Shooting

section before calling. This

section helps you solve

common problems that may

occur.

If you do need service, you

can relax knowing help is

only a phone call away.

Tel: 1-800-26-

Write down the model and serial

numbers here. They are on a label

located on the back of the appli-

ance.

Model number DBC128BLS

Serial number ______________

Date purchased ____________

Staple your receipt to the inside

back cover of this manual. You will

need it to obtain service under

warranty.

Start Here!…Before using your Beverage Center

READ ALL SAFETY INFORMATION BEFORE USING

IMPORTANT SAFETY INFORMATION

WARNING

SAFETY

PRECAUTIONS

•This appliance must be

grounded. Connect only to a

properly grounded outlet.

See “Grounding Instructions”

section on page 4.

•Do not operate this appliance

if it has a damaged power cord

or plug, if it is not working

properly, or if the appliance has

been damaged or dropped.

•Do not splice the power cord

that is equipped with this appli-

ance.

•Keep power cord away from

heated surfaces.

•Do not immerse power cord,

plug or the appliance itself in

water.

•Do not use this product near

water-for example, in a wet

basement, near a swimming

pool or near a sink.

•Do not use corrosive

chemicals or vapors in this

appliance.

•Use this appliance only for

it’sintended use, as described

in this manual.

•Do not store perishable food

items such as (but not limited

to) meats and dairy products

in your Beverage Center.

•See door surface cleaning

instructions in the Care and

Cleaning section(s) of this

manual.

•Do not cover or block any

openings on the appliance.

•This appliance should be

serviced only by qualified serv-

ice personnel. Contact the

nearest authorized service

facility for examination, repair

or adjustment.

SAVE THESE INSTRUCTIONS

DANGER, RISK OF CHILD ENTRAPMENT!

An empty refrigerator is a very dangerous attraction to children. Remove either the gasket,

latches, lids, lock and/or doors from unused or discarded appliances, or take some other action

to guarantee it harmless.

DON’T WAIT, DO IT NOW!

Toreduce the risk of fire, burns, electric shock, or injury to persons when using your appliance,

follow basic precautions, including the following sections;

This appliance must be

grounded. In the event of an

electrical short circuit, ground-

ing reduces the risk of electric

shock by providing an escape

wire for the electric current.

This appliance is equipped

with a power cord having a

grounding wire with a ground-

ing plug. The plug must be

plugged into an outlet that is

properly installed and ground-

ed.

Consult a qualified electrician

or service technician if the

grounding instructions are not

completely understood, or if

doubt exists as to whether the

appliance is properly ground-

ed.

If the outlet is a standard 2-

prong wall outlet, it is your per-

sonal responsibility and obliga-

tion to have it replaced with a

properly grounded 3-prong

wall outlet.

For best operation, plug this

appliance into its own electri-

cal outlet to prevent flickering

of lights, blowing of fuse or

tripping of circuit breaker.

Do not under any circum-

stances cut or remove the

third (ground) prong from the

power cord.

Do not use an adapter plug

with this appliance.

Do not use an extension

cord with this appliance. If the

power cord is too short, have

aqualified electrician or serv-

ice technician install an outlet

near the appliance.

GROUNDING

INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

WARNING

Improper use of the

grounding plug can result

in a risk of electric shock.

LOCATION DO...

•Select a location with a

strong, level floor.

•Allow 5 inches of space

between the back of the

appliance and any

adjacent wall.

•Avoid direct sunlight and

heat. Direct sunlight may

affect the acrylic coating,

Heat sources nearby will

cause higher electricity

consumption.

DO NOT...

•Use this appliance out-

doors: This appliance is

intended for

household

use only

.Do not attempt

to operate or store this

appliance outdoors.

•Build this appliance

into an enclosure:.This

appliance is designed for

afree-standing application

only and is not intended to

be “built-in”.

Operating Instructions

Features of your

Beverage Center

1. Tempered Glass Door: Tinted for UV

protection while still allowing for easy interior

viewing.

2. Magnetic Door Gasket: Tight fitting

seals retain all the cooling power.

3. Plastic Coated Wire Shelves

4. Leveling Leg

5. Child Proof Lock with Key

6. Interior Light (

not shown

):Illuminates

the compartment when the door is opened.

Operating Instructions

The Controls of your

Beverage Center

To start the Beverage Center, turn the tempera-

ture control to the position corresponding to the

desired cooling. The Beverage Center tempera-

ture will vary depending on the quantity of cans

stored and on the frequency with which the door

is opened.

Setting The Temperature Control:

The temperature of the Beverage Center com-

partment is controlled by adjusting/setting the

thermostat control knob, located on the exterior

rear wall of the cabinet.

To start the Beverage Center and achieve maxi-

mum cooling quickly;

•Turn the temperature control knob clockwise to

the furthest (maximum) setting on the darker blue

(wide) section of the graduated control dial.

•Allow the unit to run at this setting for 3-4 hours.

•When maximum cooling is achieved, turn back

the temperature control knob setting to the 2

o’clock position on the graduated blue control

dial. See fig.15.

•To turn off the beverage center, (no cooling)

rotate the control knob to the “0” (off) position.

See fig.14

Turn the control to the “OFF” (0) position to tem-

porarily disconnect the cooling cycle. When the

beverage center is not to be used for a long peri-

od of time, disconnect the plug and leave the

door partially open.

NOTE: Wait 3 to 5 minutes before restarting if

operation has been interrupted.

Interior Light:

The operation of the interior light can be "manu-

ally" controlled as well as controlled with the

opening or closing of the door.

To manually operate the light; depress the inte-

rior light toggle switch situated on the left side of

the interior light housing located on the ceiling

of inner cabinet (

as shown in

Figure C)this will

allow the interior light to remain on, while the

door is closed.

Defrosting:

Your beverage center is designed with an “Auto-

Cycle” defrost system.

What is Auto Cycle

defrost?

The refrigerated surfaces of the fresh food com-

partment defrost automatically,during the “off”

cycle of the cold control. (thermostat) Defrost

water from the fresh food compartment is dis-

posed of automatically,by means of being chan-

neled onto a drip tray located on the compressor.

Heat transfer from the compressor causes the

defrost water to evaporate.

Fig. A Fig. B

Interior Light

Toggle Switch

Fig. C

Operating Instructions

Inorder to achieve the maxi-

mum storage capacity of 128

cans, it will be necessary to

position the cans in the fol-

lowing manner;

•Twenty-two (22) cans

upright on the top shelf sur-

rounding the interior light.

•Twenty-five (25) cans

upright on each of the center

3shelves.

•Thirty-two (32) cans laying

on the bottom of the cabinet

(as shown in Fig D).

This will allow for a total

storage capacity of one-hun-

dred and twenty-eight (128)

355 ml cans.

Can

Storage

The *

maximum

capacity of

the DBC128 is 128 (355ml)

cans.

When stocked as per

instructions.

Shelf Instructions To remove a shelf from it’s

locked position, tilt the rear

portion of the shelf up and pull

outward.

To re-install, ensure the shelf

is resting securely on the sup-

port brackets and push shelf

inward until it locks into place.

Please Note: Each of the top

three staggered shelves have

acolor coded marker on the

rear rail. In order to stock the

beverage cans as per the

above “Can Storage” instruc-

tions, it will be necessary to

install the shelves as shown in

Figure E. The correct posi-

tioning of shelves should allow

you to easily place a standard

355 ml beverage can upright

between each shelf.

Fig E

IMPORTANT!

Do not cover shelves with

aluminum foil or any other

material that will prevent

adequate air circulation

within the cabinet.

Important! The bottom flat shelf in

the cabinet is not secured in place

(locked). Do not attempt to pull on

the shelf when it is stocked.

Fig D

Installation Instructions - Door Swing Reversal

1. Unplug the unit from the electrical outlet (if con-

nected) and lay it on it’s back.

2. Remove the screws from the lower hinge assembly as

shown in Figure F.

3. Pull the door downward to remove it from the

cabinet of the Beverage Center.

4. Remove the cap from the top left side of the

door (Fig G) and reinstall it on the top right side.

5. Remove the three (3) screws supporting the

top hinge (Fig H).

6. Remove the plastic caps from the left side of

the frame (Fig I)and reinstall them on the right

side of the frame (the previous hinge location).

9. Install the upper hinge assembly on the left

side of the frame.

10. Carefully reposition the door firstly into the

upper hinge assembly then onto the cabinet.

11. While the door remains closed install the

lower hinge assembly.

12. Close the door and return the unit into it’s

upright position (wait 60 mins before re-connect-

ing power to the beverage center), verify the

door alignment and proper seal against the cabi-

net.

FIG I Plastic Caps (2)

Upper Hinge

FIG G

Door Plug

Lower Hinge Assembly

and Door Support Bracket

FIG F

FIG H

Helpful Hints Allow the Beverage Center

door to remain open for a few

minutes after manual cleaning

to air out and dry the inside of

the beverage center cabinet

NOTE: Be certain the

power is off before

cleaning any part of

this appliance.

How to Clean

the Inside Walls, Floor, Inside

Window, and Shelves

Water deposits and dust can

should be removed with a

damp cloth.

Care and Cleaning

How to Clean

the Outside Outer Case

It’s important to keep the area

clean where the door seals

against the cabinet. Clean this

area with a sudsy cloth. Rinse

and then dry.

Door Trim

Use only mild, non-abrasive

detergents applied with a

clean sponge or soft cloth.

Rinse well.

Door Glass

Wipe the door with a damp

cloth and dry thoroughly. Do

not use abrasive or sharp

objects on the door glass, they

can damage it.

Do not use cleaners con-

taining ammonia or alcohol

on the Beverage Center.

Ammonia or alcohol can

damage the appearance of

the appliance.

Never use any commercial or

abrasive cleaners or sharp

objects on any part of this

appliance.

Andere Handbücher für DBC128BLS

Inhaltsverzeichnis

Andere Danby Kühlschrank Handbücher

Danby

Danby Designer DFF8802W Bedienungsanleitung

Danby

Danby Premiere DFF1145W Bedienungsanleitung

Danby

Danby D1052 Bedienungsanleitung

Danby

Danby DAR044A6BSLDBO Bedienungsanleitung

Danby

Danby CONTEMPORARY CLASSIC DAR110A2LDB Bedienungsanleitung

Danby

Danby DBC044C1SSDB-6 Bedienungsanleitung

Danby

Danby Designer DFF9102W Bedienungsanleitung

Danby

Danby DESIGNER DAR440BL Bedienungsanleitung

Danby

Danby DPF073C1BSLDD Bedienungsanleitung

Danby

Danby DCRM31BSLDD Montageanleitung

Danby

Danby Diplomat DFF8801W Bedienungsanleitung

Danby

Danby DFF110A1WDB1 Bedienungsanleitung

Danby

Danby DCR032C3 Bedienungsanleitung

Danby

Danby DCR038BL Bedienungsanleitung

Danby

Danby DPF074B2WDB-6 Bedienungsanleitung

Danby

Danby CONTEMPORARY CLASSIC DAR026A2BDB Bedienungsanleitung

Danby

Danby Designer DAR044A4WDD-6 Bedienungsanleitung

Danby

Danby Silhouette Select DAR154BLSST Montageanleitung

Danby

Danby DAR048W Bedienungsanleitung

Danby

Danby DAR452 Bedienungsanleitung

Danby

Danby Designer DAR195W Bedienungsanleitung

Danby

Danby DESIGNER DAR440BL Bedienungsanleitung

Danby

Danby DAR044A4BSLDD Bedienungsanleitung

Danby

Danby DAR044A4WDD Montageanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung
