Danby DBC434A1SDB Montageanleitung

Model • Modèle • Modelo

V1.04.12.DM

• Owner’s Use and Care Guide

• Guide d’utilisation et soin de Propriètaire

• Manual de Instructions Pare el Uso y el

Cuidado de su Unidad

DBC434A1SDB

Danby Products Limited, Ontario, Canada N1H 6Z9

Danby Products Inc., Findlay, Ohio, USA 45840

• FREE STANDING BEVERAGE CENTER

• CENTRE DE BREUVAGES AUTONOME

• CENTRO DE BEBIDAS AUTÓNOMO

FREE STANDING BEVERAGE CENTER

Owner’s Use and Care Guide

• Safety Instructions

• Operating Instructions

• Door Reversal Instructions

• Care and Maintenance

• Troubleshooting

• Warranty

CENTRE DE BREUVAGES AUTONOME

Guide d’utiliser et soin de propriètaire

• Consignes de Sécurité Important

• Consignes d’utilisation

• Inversion de Porte

• Soins et entretien

• Dépannage

• Garantie

Contents

1-10

11-20

CENTRO DE BEBIDAS AUTÓNOMO

Guide d’utiliser et soin de propriètaire

• Instrucciones de Seguridad Importantes

• Operación

• Inversión de la Puerta

• Limpieza y Mantenimiento

• Solución Sugerida

• Garantia

21-30

CAUTION:

PRECAUTION:

PRECAUCION:

Read and follow all safety rules and

operating instructions before first use of this

product.

Veuillez lire attentivement les consignes de

sécurité et les instructions d’utilisation avant

l’utilisation initiale de ce produit.

Lea y observe todas las reglas de seguridad

y las instrucciones de operación antes de

usar este producto por primera vez.

Model • Modèle • Modelo DBC434A1SDB

Welcome

Welcome to the Danby family. We’re proud of our quality products, and we believe in dependable service; like you will

find in this owner’s use and care guide, and like you will receive from our friendly customer service department. Best of

all, you will experience these values each and every time you use your Danby Appliance. That’s important, because your

new appliance will be a part of your family for a long time.

For easy reference, may we suggest that you attach a copy of your sales receipt to this page, and note the information

below; you will need this information to obtain service under warranty.

Model No:

Serial No:

Date Purchased:

Before you call for service, there are a few things you can do to help us

serve you better.

Read this Owner’s Use and Care Guide:

It contains instructions to help you use and maintain your appliance

properly.

If you received a damaged appliance:

Immediately contact the builder (or dealer) that sold you the Beverage

Center.

Save time and money:

Check the Trouble shooting section before calling. This section helps you

solve common problems that may occur.

If you do need service, you can relax knowing help is only a phone call

away.

Need Help?

Tel: 1-800-26-

(1-800-263-2629)

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

ELECTRICAL

REQUIREMENTS

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of

electrical shock by providing an escape wire for the electrical current.

This appliance is equipped with a cord having a grounding wire with a

grounding plug. The plug must be plugged into an outlet that is properly

installed and grounded.

An empty beverage center is a very dangerous attraction to chil-

dren. Remove the door from unused appliances, or take some

other action that will guarantee it harmless.

IMPORTANT WARNING

WARNING

Improper use of the grounding plug can result in a risk of electric

shock. Consult a qualified electrician or serviceman if the ground-

ing instructions are not completely understood, or if doubt exists

as to whether the appliance is properly grounded.

DANGER: Risk off child entrapment. Before you throw away your old

beverage center:

• Take off the doors.

• Leave the shelves in place so that children may not easily climb in.

DON’T WAIT DO IT NOW!

DO NOT USE AN EXTENSION CORD

Use an exclusive wall outlet. Do not connect your beverage center to

extension cords or together with any other appliance in the same wall

outlet.

SAFETY

PRECAUTIONS

•This appliance must be grounded.

Connect only to a properly

grounded outlet. See “Grounding

Instructions” section on page 3.

•Do not operate this appliance

if it has a damaged power cord or

plug, if it is not working properly,

or if the appliance has been

damaged or dropped.

•Do not splice the power cord that

is equipped with this appliance.

•Keep power cord away from

heated surfaces.

•Do not immerse power cord,

plug or the appliance itself in

water.

•Do not use this product near

water-for example, in a wet

basement, near a swimming

pool or near a sink.

•Do not use corrosive

chemicals or vapors in this

appliance.

•Use this appliance only for

it’s intended use, asdescribed

in this manual.

•Do not store perishable food

items such as (but not limited

to) meats and dairy products

in your beverage centre.

•Store beverages in sealed

.. bottles only.

•See door surface cleaning

instructions in the Care and

Cleaning section(s) of this

manual.

•Do not cover or block any

openings on the appliance.

•This appliance is intended for

household use only. Do not

attempt to operate or store this

appliance outdoors.

•This appliance should be

serviced only by qualified service

personnel. Contact the nearest

authorized service facility for

examination, repair or adjustment.

SAVE THESE INSTRUCTIONS

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

This appliance must be grounded.

In the event of an electrical short

circuit, grounding reduces the risk

of electric shock by providing an

escape wire for the electric cur-

rent.

This appliance is equipped with a

power cord having a grounding

wire with a grounding plug. The

plug must be plugged into an out-

let that is properly installed and

grounded.

Consult a qualified electrician or

service technician if the grounding

instructions are not completely

understood, or if doubt exists as

to whether the appliance is prop-

erly grounded.

If the outlet is a standard 2-prong

wall outlet, it is your personal

responsibility and obligation to

have it replaced with a properly

grounded 3-prong wall outlet.

For best operation, plug this appli-

ance into its own electrical outlet

to prevent flickering of lights,

blowing of fuse or tripping of

circuit breaker.

Do not under any circumstances

cut or remove the third (ground)

prong from the power cord.

Do not use an adapter plug with

this appliance.

Do not use an extension cord

with this appliance. If the power

cord is too short, have a qualified

electrician or service technician

install an outlet near the appli-

ance.

GROUNDING

INSTRUCTIONS

WARNING!

Improper use of the ground-

ing plug can result in a risk of

electrical shock.

LOCATION

REQUIREMENTS

DO...

• Select a location with a

strong, level floor.

• Allow 5 inches of space

between the back of the

appliance and any adjacent

wall.

• Avoid direct sunlight and

heat. Direct sunlight may

affect the acrylic coating,

heat sources nearby will

cause higher electricity

consumption.

DO NOT...

• Use this appliance

outdoors: This appliance is

intended for household use

only. Do not attempt to

operate or store this

appliance outdoors.

• Build this appliance

into an enclosure: This

appliance is designed for a

free-standing application

only and is not intended to

be “built-in”.

Allow 13 1/4” (33.7 cm) of

space between the (hinge)

side of the door and any

adjacent wall to

accommodate door swing.

13.25

in.

5 in.

FEATURES OF YOUR

BEVERAGE CENTRE

1. Electronic Display and Controls: For

viewing and regulating the temperature of

the Beverage Center.

2. Handle

3. Tempered Glass Door: Tinted for UV

protection while still allowing for easy

interior viewing.

4. Stainless Steel Color Trim Shelves

5. Leveling Legs

6. Magnetic Door Gaskets: Tight fitting

seals retain all the cooling power and

humidity levels.

Specifications

Width 19.41 in. / 493 mm Temperature Range

(Minimum ~Maximum) 39 ~ 64°F / 4~18°C

Height 33.11 in. / 841 mm Net Weight 84 lbs / 38 kg

Depth 24.92 in. / 633 mm

Operating Instructions

CONTROLS OF YOUR

BEVERAGE CENTER

SETTING THE

TEMPERATURE

•To switch the display between the Fahrenheit (°F) and Celsius (°C)

scale, depress the and control buttons

simultanously for approximately five (5) seconds

•The temperature range can be set as low as 39°F (4°C) or as high

as 64°F (18°C) to suit your specific storage requirements. Each

depression of the or button will allow you to adjust

the temperature in 1° degree increments within the aforementioned

range.

IMPORTANT!

In the event of a power fail-

ure, wait 3 to 5 minutes

before restarting.

23456

1. Indicator light illuminates to signify the

cooling mode is currently in operation.

2. Set Temperature Display: Display screen

shows the temperature setting (see ‘Setting

the temperature’ below)

3. Cabinet Temperature Display:

Display screen shows the current cabinet

temperature.

4. °C/°F : Adjacent indicator light denotes which

scale of temperature is displayed.

5. ‘ ’ Button: Used to raise the temperature

(warmer) in 1° degree increments.

‘ ’ Button: Used to decrease the

temperature (cooler) in 1° degree increments.

6. ‘|’ Switch: Continuous illumination.

‘O’ Switch: Illumination only when the door is open.

Operating Instructions

To remove a shelf from its

locked position, tilt the shelf as

shown in Fig. A and pull out-

ward.

To re-install, ensure the shelf is

resting securely on the support

brackets and push the shelf

inward until it locks into place.

Fig. A

Top Shelf: Holds 18

cans laying on their

sides.

2nd and 3rd Middle

Shelves: Each holds 35

cans (70 total) standing

vertically.

Base:

Holds up to 9 wine

bottles.

Alternate base: Holds

36 cans, when the cans

are stacked laying on

their sides.

SHELF

INSTRUCTIONS

BEVERAGE STORAGE

IMPORTANT!

Do not cover shelves with

aluminum foil or any other

material that will prevent

adequate air circulation

within the cabinet.

IMPORTANT!

The maximum* capacity of

the DBC434A1SDB is 124

(350ml) cans or 88 cans and

9 (750ml) wine bottles.

*When stocked as per

instructions.

Store beverages in sealed

bottles only.

Door Reversal Instructions

TOOLS REQUIRED

Phillips #2 screwdriver and an adjustable wrench.

WARNING

Excessive Weight hazard use two or more

people when moving the beverage center.

Rubber cover

Screws

Decorative cover

Screws

Top Hinge

Decorative nail

Screws

Lower hinge

Cabinet leg

Extrusion-board

of lamp switch

Screws

1. Close the door and take out rubber cover (1), unscrew two screws (2) and remove decorative cover

(3).(Fig.1).

2. Unscrew screws (4) and take out top hinge (5), then remove the door. (Fig.2)

3. Put the door aside safely and take out two screws (11) at the bottom, pull out extrusion-board of lamp switch

(10) and fix it at top of door. (Fig.5)

4. Pull out decorative nail (6) from left top of cabinet. (Fig.3)

5. Unscrew 3 screws (7) from right bottom of cabinet and remove lower hinge (8). (Fig.4)

6. Pull out cabinet leg (9) from left bottom of cabinet and fix it onto right bottom of cabinet. (Fig.4)

7. Fix the lower hinge (8) onto left bottom of cabinet with screws (7). (Fig.4)

8. The door revolves 180 degrees, put lower door axis to aim at lower hinge (8) and install the door onto lower

hinge (8), then close the door carefully. (Fig.5)

9. Fix top hinge (5) onto left top of cabinet with screws (4), adjust door and install decorative cover (3) and rubber

cover (1). (Fig.6)

10. Block 3 screw holes at right top of cabinet with spare decorative nail.

Care and Maintenance

HELPFUL HINTS Allow the door to remain open for a few minutes after manual cleaning

to air out and dry the inside of the cabinet.

HOW TO CLEAN

THE INSIDE

Walls, Floor, Inside Window, and Shelves

Water deposits and dust can be removed with a damp cloth.

HOW TO CLEAN

THE OUTSIDE

Outer Case

It’s important to keep the area

clean where the door seals

against the cabinet. Clean this

area with a sudsy cloth. Rinse

and then dry.

Door surface

Use only mild, non-abrasive

detergents applied with a clean

sponge or soft cloth. Rinse well.

Control Panel and Door

Wipe with a damp cloth and dry

thoroughly. Do not use cleaning

sprays, large amounts of soap

and water, abrasive or sharp

objects on the panel, they can

damage it. Some paper towels

may also scratch the control

panel and door glass.

IMPORTANT!

Never use any commercial or

abrasive cleaners or sharp

objects on any part of the bev-

erage center.

IMPORTANT!

Do not use cleaners contain-

ing ammonia or alcohol.

Ammonia or alcohol can dam-

age the appearance of the

appliance.

WARNING!

Be certain the power is off before cleaning any part of this appliance.

Inhaltsverzeichnis

Sprachen:

Andere Danby Kühlschrank Handbücher

Danby

Danby DCR412BLS Bedienungsanleitung

Danby

Danby DAR026XA2WDB Bedienungsanleitung

Danby

Danby Designer DAR1102WE Montageanleitung

Danby

Danby DCR044A4BBSL Bedienungsanleitung

Danby

Danby DIPLOMAT DCR032BL Bedienungsanleitung

Danby

Danby Silhouette DWBC14BLS Montageanleitung

Danby

Danby DCR032C4BDB Bedienungsanleitung

Danby

Danby DAR017A2BDD Bedienungsanleitung

Danby

Danby CONTEMPORARY CLASSIC DAR110A3LDB Bedienungsanleitung

Danby

Danby DFF116B1WDBL Bedienungsanleitung

Danby

Danby DAR044A6MDB-6 Bedienungsanleitung

Danby

Danby DPF074B1WDB Montageanleitung

Danby

Danby Designer DFF9100W Bedienungsanleitung

Danby

Danby DCR023C1WDB Bedienungsanleitung

Danby

Danby CONTEMPORARY CLASSIC DAR026A2WDB Bedienungsanleitung

Danby

Danby DCR054 Bedienungsanleitung

Danby

Danby DPF074V1WDB-6 Bedienungsanleitung

Danby

Danby DAR110A1WDD Montageanleitung

Danby

Danby DAR170A2WDD Bedienungsanleitung

Danby

Danby DAR016B1BM Bedienungsanleitung

Danby

Danby DFF070B1BSLDB-6 Bedienungsanleitung

Danby

Danby Diplomat DCR033W Bedienungsanleitung

Danby

Danby CONTEMPORARY CLASSIC DAR110A2LDB Bedienungsanleitung

Danby

Danby DAR044A1SSO-6 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung
