Dancover AC153200 Bedienungsanleitung

18-04-2023

Manual

for

Fitting Set Wall

for

Pergola San Pablo

3x3m, 3x4m and 4x4m

Manual Instruction

Fitting Set Wall for

Pergola Gazebo San Pablo

3x3m, 3x4m and 4x4m

Corner connector

闵

G G



。

MBX40

）

K7 Gasket

霍叭

M10x80

Hex Head Wood

Screw + Ribbed

Plastic Anchor

（志忘

｀

K10 M10 screw cover

Spare parts list

Label

No. Part description Drawing Qty

Wall bracket

叭

14x70

叭

Hex Socket Flat

Head Screw with

the gasket M8x40

Gasket

『一一一一一一一一一一一一一一一一一一一一一一一一］

勹

3780 (4*3 / 4*4)

2788 (3*3 / 3*4)

了

令驾芒戛忑长8)0l~

(互＊驾芝买会＾8)买买

K10

;

K10

3780 (4*3 / 4*4)

2788 (3*3 / 3*4 )

三

QTY:2PCS K8

甘亡

M10x80

¢14x70 QTY: 6SET S

霍

QTY:6PCS

¢10

K10

M10

QTY:6PCS

。

1.Drill holes for the wall brackets

and install these brackets Q.

Step 1: Use a hand electric drill to drill hole No.1,

install the wall bracket Q with wood screw and

ribbed plastic anchor, adjust the height and lever of

the wall bracket, then tighten the wood screw; Then

drill holes No.2 and No.3, install plastic anchors and

tighten the wood screws.

ole

Depth

100

needs

holes.

Step 2: Install another wall bracket

same way, then put on M10

screw and covers K10.

． -

K1 K1

的 严

。）



霍QTY: 2PCS







2. Install the corner connector P onto two ends of front and rear beam C.

Step 1. Install the corner

connector P onto two ends

of front and rear beam C.

Step 2. Connect the front and rear

beam with screw K1 and screw K2

with gasket K3; then connect the

wall bracket Q and corner connector

P with screws K6 and gasket K7.

Tips: Keep screw K6 loose and

tighten it after the left and right

beams B1/B2 have been connected.

K2K2

K3K3

3.Following and next installation steps please refer to original pergola manual.

For more information please visit: www.dancovershop.com
