Dancover PRO EventZone 9m Series Bedienungsanleitung

6m Series

Party PRO EventZone

22-08-2014

Safety Advice

Attention

In some countries approval is needed to set up a marquee/tent larger than 75 m2. It is

your responsibility to comply with local rules and regulations and to ensure that the

marquee/tent is assembled correctly.

In case of bad weather conditions, it is your responsibility to ensure the marquee/tent is

safely secured and that the marquee/tent does not cause damage to others.

close to the tent.

The marquee/tent must be safely secured. We recommend you secure your marquee/tent

with straps and pegs as soon as it is assembled.

Make sure to check if the marquee/tent is covered by your home contents

insurance.

Marquees/tents must be evacuated under extreme weather conditions.

In the event of snow always remove snow from the roof of the marquee/tent regularly to

prevent snow from building on the roof as heavy snow can cause the marquee/tent to

collapse.

In the event of rain there is a risk of rain puddles building up on top of the roof of the

marquee/tent. Heavy rain puddles can cause the roof to collapse. It is your responsibility

to ensure rain puddles do not build up. As a precaution, make sure the roof of the

marquee/tent is stretched out properly and adequately over the side frames of the

marquee/tent and remove rain water regularly.

Do not unpack or repack your marquee/tent in freezing temperatures. In case of

temperatures below zero always unpack and repack your marquee/tent indoors to avoid

the risk of cracking parts.

The marquee/tent must be totally dry before you repack and store it to avoid mildew.

Warranty Information

Please visit dancovershop.com for information on warranty.

Note: Marquees are intended for events and other arrangements and are as such only

meant for short term temporary assembly and the following disassembly. Dancover

warranty applies only to the normal use of the Product, normal wear and tear excepted,

in accordance with written use instructions or manual. The warranty does not apply to

Please always check our website for the latest safety advice and manuall.

____________________________________________________________________________________

Page 2 of 12

Contents

1. General

2. Frames Assembling Guide

3. ‘Cover and Sidewalls’Assembling Guide

Part list

Fundamental

____________________________________________________________________________________

Page 3 of 12

Before assembling, workers should acquaint themselves with the safety precautions, necessary

implements and materials.

Safety Precautions:

A. The supervisor needs at least 6 assistants to set up the tent.

B. Before starting to work, the supervisor has to make his assistants familiar with the

sequence of operations and safety precautions.

C. He has to check that his assistants are qualified for this job and he is the responsible

leader on the site.

D. Everybody on the site should wear solid shoes and helmets.

E. The site should be insulated. The people except the workers are not allowed to enter into

the site.

F. If the foundation soil is of an inferior quality, it is necessary to obviate foundation breaking

danger by sufficient additional soil compression for expansion of the bearing surface.

G. Pay attention that the site is free of circuit and that there are no cables or pipes under the

ground.

H. In case any cables or other electric equipment is installed in the tents, electrical operation

rules should be strictly executed.

I. Local safety precautions are applicable.

J. Make sure the site is safe for the third party part. If the setup works is lasting for sections,

safety measures should be taken in the nights.

K. Tents fixing methods: In case of concrete ground and its heights exceeds 15cm, please

use Swell Screws or weight bags. In case of grass ground, bitumen ground (any other soft

grounds), please use steel Ground-Anchors.

L. Please make sure the height difference of the site don’t exceed 5cm, otherwise, it will

affect the safety of the tent.

1. General

____________________________________________________________________________________

Page 4 of 12

M. During or after the setup, if there is bad weather, especially when hailstone is reported by

weather forecast, please dismantle the tent. If the snow depth is equal to or thicker than

3cm, please clean the snow on the roof. If the wind speed is equal to or faster than 80

Km/h, the tent has to be closed completely (all Roof-Cover, Gable-Cover, Sidewall &

Gable Wall).

N. Any local regulations for temporary building are applicable.

O. In case of fire, please unfasten the Rope/Zipper on the wall or open the door to escape.

P. In case of any other special case, please contact the manufacturer for consultation.

Necessary Implements:

Ladders, Spanners, Setup-ropes, Forks, Hammer, Pliers, Drills, a Protecting Foil or Carpet,

Helmets, Solid shoes, Go-Cart, Pull-Up Peg Machine (if use the Ground-Anchors for tents

fixing)

Necessary Materials:

Please kindly find technical data in the packing list in the delivery.

2. Frames Assembling Guide

Measure the site and mark the tent position

Please arrange the face line of one longitudinal side or the face line of the gable side

Then mark and stake the Base-Plates on the right position (please kindly find the

Base-Plates position drawing in the shipping documents).

Check the material list and put all of them on the right position for setup (Please find

the packing list in the delivery - Techniques of the Tent)

____________________________________________________________________________________

Page 5 of 12

Use the bolt to connect the Foot-Plates, Upright-Supports, Roof-Beams,

Eave-Connections and Top Connections. And then, erect the first frame of the tent.

Erect the first section:

A. Erect the second frame

B. Fix the X-Cross bars by bolts

C. Put the Eave-Purlin, Intermediate-Purlin and Roof-Purlin on the Roof-Beams

____________________________________________________________________________________

Page 6 of 12

Erect

like shown below opposite each other and on different sections.

all frames and put the purlins on the roof as the first section. Place the portal beams

Portal beam

Page 7 of 12

Page 8 of 12

Page 9 of 12
