Dancover Storage Tent PRO Bedienungsanleitung

04-10-2019

for

Storage Tent PRO

8x12x5,2m PVC

Manual

Safety Advice

Attention

In some countries approval is needed to set up a tent larger than 75 m2. It is your responsibility

to comply with local rules and regulations and to ensure that the tent is assembled correctly.

In case of bad weather conditions, it is your responsibility to ensure the tent is safely secured

and that the tent does not cause damage to others.

Do not use open re, welding equipment or other sources which can ignite, inside or close to the

tent.

The tent must be safely secured. We recommend you secure your tent with straps and pegs as

soon as it is assembled.

Make sure to check if the tent is covered by your home contents insurance.

Tents must be evacuated under extreme weather conditions.

In the event of snow, always remove snow from the roof of the tent regularly to prevent snow

from building on the roof, as heavy snow can cause the tent to collapse.

In the event of rain, there is a risk of rain puddles building up on top of the roof of the tent.

Heavy rain puddles can cause the roof to collapse. It is your responsibility to ensure rain

puddles do not build up. As a precaution, make sure the roof of the tent is stretched out

properly and adequately over the side frames of the tent and remove rain water regularly.

Do not unpack or repack your tent in freezing temperatures. In case of temperatures below

zero, always unpack and repack your tent indoors to avoid the risk of cracking parts.

The tent must be totally dry before you repack and store it to avoid mildew.

Note: Dancover warranty applies only to the normal use of the Product, normal wear and tear

excepted, in accordance with written use instructions or manual. The warranty does not apply

to damage caused by accident, abuse, misuse, or modification of the Product.

Warranty Information

Please visit dancovershop.com for information on warranty.

Please always check our website for the latest safety advice and manual.

8x12

1Back leg 4

2 18

4Crossbar 16

6Ceiling rail 11

5Ceiling rail 11

3Extension pipe 22

7Corner arch 22

8Center arch 11

9Connecting

pipe 117

10 Connecting

pipe 13

11 Extension pipe 22

12 Extension pipe 4

13 Door pillar 4

16 Foot base 26

17 Connecting

component 4

15 Fasten bar 20

04-10-2019

Back leg

Instruction

18 Nail

10x350mm 16

19 Nail

6x180mm 60

20 Nail

7x300mm 52

Spiral nail

10x700mm 4

23 1.75" Screw 12

24 2.5" Screw 40

25 4" Screw 148

26 Wing nut 200

27 Floor Bracket

(set of 2 pcs) 8

28 Bungee ball 92

29 Spanner 2

30 Bolt with nut 34

31 Tie-down kit 4

32 Steel clip 40

33 Steel wire 12

34 Rope 4

35 Rope 4

22 Cross bar 8

04-10-2019

36 Roof 1

37 Endwall 2

Attention

Please use gloves when assembling the metal frame of this unit. The metal components of this product have been treated,

with a rust preventive coating. This coating is not dangerous, but you may grease your hands during assembly. We

recommend that you wipe metal parts clean with a mixture of warm water and dish detergent prior to assembly. Should your

hands become dirty, simply wash with soap and water.

After the frame is set up, it should look like the picture shown below.

8x12

Please assemble the frame in these steps. All sizes have similar assemble step.

Step 2,

Step 3,

gnisurehtohcaehtiwstnemelehcraehttcennocwoN

the connecting pipes (9 and 10). Note that only corner

arch 10 are used for the front segments. Use the 4” screw

and wing nut to tighten them.

Step 4,

Strengthen the frame with steel wire.

Step 1

When assembling the tent, make sure that all the wing

nuts are attached to the inside.

Connect one center arch pipe(8) with the extension

pipe(11). Attach the corner arch(7) to the ends of the

extension pipe(3). Now connect the ceiling rail(6 and 5)

with each other using the 1.75" screw and the wing nuts.

Connect extension pipe (3) and (11) together then attach

ceiling rail to extension pipe(3 and 11) through 17 using

the 2.5" screws and wing nuts.

Repeat step 1 for the next elements and place them on

the ground one after another, as illustrated.

Step 5,

Start setting up one side first. Connect the corner arch 7) with the legs (1 and 2). Secure the frame using the connecting

pipes (9 and 10). Attach the diagonal pipes (4) to the back legs (1). Please refer to the completed frame pictures to attach the

diagonal pipes.

Screw tighten the tent at the feet, using the 4” screws and wing nuts.

Use the floor bracket and the 10x350mm pegs to fasten the frame to the ground.

Step 6,

Unfold the tent cover and put it over the frame. Insert the fasten bar(15) into the loop at the lower end of roof and fasten it with

steel clips. Attach the end wall to the frame using the bungees. Tension the roof cover to the tent frame to the ground using

the 6x180mm pegs.

(

Step 7,

Assemble the pillar set like on the picture below.

Step 8,

Use the ropes to attach the door and cover to the frame. Find a proper way and strength to attach the cover to the frame

carefully. Please do not use too much strength to tear the eyelet out of fabric.

Contact information

Head office:

Dancover A/S

Nordre Strandvej 119 G

3150 Hellebæk

Denmark

For more information

please visit:

www.dancovershop.com

National contact

Denmark: 70 26 76 20

denmark@dancover.com

UK: 020 8099 7570

uk@dancover.com

Spain: 911 436 828

espana@dancover.com

Italy: 02 479 21 198

italia@dancover.com

Germany: 041 0266 7040

germany@dancover.com

Switzerland: 0840 000125

schweiz@dancover.com

France: 0975 181 800

france@dancover.com

Austria: 0662 626935

austria@dancover.com

Sweden: 040 233 262

sverige@dancover.com

Finland: 0 931 581 720

suomi@dancover.com

Nederland: 0 858 880 524

nederland@dancover.com

Poland: 22 300 8602

polska@dancover.com

Ireland: 0 151 33 003

ireland@dancover.com

Luxembourg: +49 041 0266 7040

luxembourg@dancover.com

Portugal: 308 800 899

portugal@dancover.com

Belgium: 0 28 08 08 09

belgique@dancover.com

Norway: 231 00 690

norge@dancover.com
