1 Quick Guide 2

1.1 Safety 2

1.1.1 Warnings 2

1.1.2 Safety Instructions 2

1.2 Introduction 3

1.2.1 Available Literature 3

1.2.2 Approvals 3

1.2.3 IT Mains 3

1.2.4 Avoid Unintended Start 3

1.2.5 Disposal Instruction 4

1.3 Installation 4

1.3.1 Before Starting Repair Work 4

1.3.2 Side-by-Side Installation 4

1.3.3 Dimensions 5

1.3.4 Electrical Installation in General 6

1.3.5 Connecting to Mains and Motor 8

1.3.6 Fuses 14

1.3.7 EMC-Correct Electrical Installation 16

1.3.8 Control Terminals 18

1.3.9 Electrical Overview 19

1.4 Programming 20

1.4.1 Programming with the Local Control Panel (LCP) 20

1.4.3 The Start-up Wizard for Open Loop Applications 21

1.5 Parameter Overview 28

1.6 Warnings and Alarms 33

1.7 General Specifications 35

1.7.1 Mains Supply 3 x 200-240 V AC 35

1.7.2 Mains Supply 3 x 380-480 V AC 36

1.7.3 Mains Supply 3 x 380-480 V AC 38

1.7.4 Mains Supply 3 x 525-600 V AC 40

1.7.5 EMC Test Results 41

1.8 Special Conditions 44

1.8.1 Derating for Ambient Temperature and Switching Frequency 44

1.8.2 Derating for Low Air Pressure 44

1.9 Options for VLT HVAC Basic Drive FC101 44

Contents VLT HVAC Basic Drive Quick Guide

MG18A302 - VLT®is a registered Danfoss trademark 1

1 Quick Guide

1.1 Safety

1.1.1 Warnings

WARNING

High Voltage Warning

The voltage of the frequency converter is dangerous

whenever it is connected to mains. Incorrect installation of

the motor or frequency converter may cause damage to

the equipment, serious injury or death. Consequently, it is

essential to comply with the instructions in this manual as

well as local and national rules and safety regulations.

WARNING

Electrical Hazard

Touching the electrical parts may be fatal - even after the

equipment has been disconnected from mains. Also make

sure that other voltage inputs have been disconnected

(linkage of DC intermediate circuit). Be aware that there

may be high voltage on the DC link even when the LEDs

are turned off. Before touching any potentially live parts of

the frequency converter, wait at least as stated in the table

below:

Voltage (V) Power range (kW) Min. waiting time

(minutes)

3 x 200 0.25 – 3.7 4

3 x 200 5.5 – 11 15

3 x 400 0.37 – 7.5 4

3 x 400 11 – 90 15

3 x 600 2.2 – 7.5 4

3 x 600 11 – 90 15

CAUTION

Leakage Current:

The earth leakage current from the frequency converter

exceeds 3.5 mA. According to IEC 61800-5-1 a reinforced

Protective Earth connection must be ensured by means of

a min. 10 mm² Cu or an additional PE wire - with the same

cable cross section as the Mains wiring - must be

terminated separately.

Residual Current Device:

This product can cause a DC current in the protective

conductor. Where a residual current device (RCD) is used

for extra protection, only an RCD of Type B (time delayed)

shall be used on the supply side of this product. See also

Danfoss Application Note on RCD, MN90GXYY.

Protective earthing of the frequency converter and the use

of RCDs must always follow national and local regulations.

Motor thermal protection:

Motor overload protection is possible by setting Parameter

1-90 Motor thermal protection to the value Electronic

Thermal Relay (ETR) trip.

WARNING

Installation at high altitudes

For altitudes above 2 km, please contact Danfoss regarding

PELV.

1.1.2 Safety Instructions

•Make sure the frequency converter is properly

connected to earth.

•Do not remove mains connections, motor

connections or other power connections while

the frequency converter is connected to power.

•Protect users against supply voltage.

•Protect the motor against overloading according

to national and local regulations.

•The earth leakage current exceeds 3.5 mA.

•The [OFF] key is not a safety switch. It does not

disconnect the frequency converter from mains.

Quick Guide VLT HVAC Basic Drive Quick Guide

2 MG18A302 - VLT®is a registered Danfoss trademark

1.2 Introduction

1.2.1 Available Literature

This quick guide contains the basic information necessary

for installing and running the frequency converter. If more

information is needed, literature can be found on the

enclosed cd or downloaded from:

http://www.danfoss.com/Products/Literature/Technical

+Documentation.htm

1.2.2 Approvals

1.2.3 IT Mains

CAUTION

IT Mains

Installation on isolated mains source, i.e. IT mains.

Max. supply voltage allowed when connected to mains:

440 V (3 x 380-480 V units).

On IP20 200-240 V 0.25-11 kW and 380-480 V IP20 0.37-22

kW, open the RFI switch by removing the screw on the

side of the frequency converter when at IT grid.

130BB612.10

Illustration 1.1 IP20 200-240 V 0.25-11 kW, IP20 0.37-22 kW

380-480 V.

1: EMC screw

130BC251.10

Illustration 1.2 IP54 400 V 0.75-18.5 kW

1: EMC screw

On all units, set par. 14-50 RFI filter to OFF when operating

in IT mains.

CAUTION

If reinserted, only use M3 x 12 screw.

1.2.4 Avoid Unintended Start

While the frequency converter is connected to mains, the

motor can be started/stopped using digital commands, bus

commands, references or via the LCP.

•Disconnect the frequency converter from mains

whenever personal safety considerations make it

necessary to avoid unintended start of any

motors.

•To avoid unintended start, always activate the

[OFF] key before changing parameters.

Quick Guide VLT HVAC Basic Drive Quick Guide

MG18A302 - VLT®is a registered Danfoss trademark 3

1.2.5 Disposal Instruction

Equipment containing electrical components

must not be disposed of together with domestic

waste.

It must be separately collected with electrical

and electronic waste according to local and

currently valid legislation.

1.3 Installation

1.3.1 Before Starting Repair Work

1. Disconnect FC101 from mains (and external DC

supply, if present.)

2. Wait as stated in the table below for discharge of

the DC-link:

Voltage (V) Power range (kW) Min. waiting time

(minutes)

3 x 200 0.25 – 3.7 4

3 x 200 5.5 – 45 15

3 x 400 0.37 – 7.5 4

3 x 400 11 – 90 15

3 x 600 2.2 – 7.5 4

3 x 600 11 – 90 15

3. Remove motor cable

1.3.2 Side-by-Side Installation

The frequency converter can be mounted side-by-side and requires the clearance above and below for cooling.

Power Clearance above/

below (mm/inch)

Frame IP class 3 x 200-240 V 3 x 380-480 V 3 x 525-600 V

H1 IP20 0.25-1.5 kW/0.33-2 Hp 0.37-1.5 kW/0.5-2 Hp 100/4

H2 IP20 2.2 kW/3 Hp 2.2-4 kW/3-5.4 Hp 100/4

H3 IP20 3.7 kW/5 Hp 5.5-7.5 kW/7.5-10 Hp 100/4

H4 IP20 5.5-7.5 kW/7.5-10 Hp 11-15 kW/15-20 Hp 100/4

H5 IP20 11 kW/15 Hp 18.5-22 kW/25-30 Hp 100/4

H6 IP20 15-18.5 Kw/20-25 Hp 30-45 kW/40-60 Hp 22-30 kW/30-40 Hp 200/7.9

H7 IP20 22-30 kW/30-40 Hp 55-75 kW/100-120 Hp 45-55ø W/60-100 Hp 200/7.9

H8 IP20 37-45 kW/50-60 Hp 90 kW/125 Hp 75-90 kW/120-125 Hp 225/8.9

H9 IP20 2.2-7.5 kW/3-10 Hp 100/4

H10 IP20 11-15 kW/15-20 Hp 200/7.9

NOTE

With IP21/Nema Type1 option kit mounted, a distance of 50 mm between the units is required.

Quick Guide VLT HVAC Basic Drive Quick Guide

4 MG18A302 - VLT®is a registered Danfoss trademark

1.3.3 Dimensions

D

130BB614.10

130BC205.10

130BC246.10

Enclosure Power [kW] Height [mm] Width [mm] Depth

[mm]

Mounting hole [mm] Max.W

eight

Frame IP Class 3 x

200-240 V

3 x

380-480 V

3 x

525-60

0 V

A "A incl

Decoupling

Plate"

a B b C d e f Kg

H1 IP20 0.25-1.5

0.37-1.5

195 273 183 75 56 168 9 4.5 5.3 2.1

H2 IP20 2.2 kW 2.2-4.0 kW 227 303 212 90 65 190 11 5.5 7.4 3.4

H3 IP20 3.7 kW 5.5-7.5 kW 255 329 240 100 74 206 11 5.5 8.1 4.5

H4 IP20 5.5-7.5 kW 11-15 kW 296 359 275 135 105 241 12.6 7 8.4 7.9

H5 IP20 11 kW 18.5-22

334 402 314 150 120 255 12.6 7 8.5 9.5

H6 IP20 15-18.5

30-45 kW 22-30

518 595/635(45

kW)

495 239 200 242 - 8.5 15 24.5

H7 IP20 22-30kW 55-75 kW 45-55

550 630/690(75

kW)

521 313 270 335 - 8.5 17 36

H8 IP20 37-45kW 90 kW 75-90

660 800 631 375 330 335 - 8.5 17 51

H9 IP20 2.2-7.5

269 374 257 130 110 205 11 5.5 9 6.6

H10 IP20 11-15

399 419 380 165 140 248 12 6.8 7.5 12

I2 IP54 0.75-4.0

332 - 318.5 115 74 225 11 5.5 9 5.3

I3 IP54 5.5-7.5 kW 368 - 354 135 89 237 12 6.5 9.5 7.2

I5 IP54 11-18.5

480 - 454 242 210 260 19 9 9 23

I6 IP54 22-37 kW 650 - 624 242 210 260 19 9 9 27

I7 IP54 45-55 kW 680 - 648 308 272 310 19 9 9.8 45

I8 IP54 75-90 kW 770 - 739 370 334 335 19 9 9.8 65

The dimensions are only for the physical units, but when installing in an application it is necessary to add space for free air

passage both above and below the units. The amount of space for free air passage is listed in Table 1.1:

Quick Guide VLT HVAC Basic Drive Quick Guide

MG18A302 - VLT®is a registered Danfoss trademark 5

Enclosure Clearance needed for free air passage [mm]

Frame IP class Above unit Below unit

H1 20 100 100

H2 20 100 100

H3 20 100 100

H4 20 100 100

H5 20 100 100

H6 20 200 200

H7 20 200 200

H8 20 225 225

H9 20 100 100

H10 20 200 200

I2 54 100 100

I3 54 100 100

I5 54 200 200

I6 54 200 200

I7 54 200 200

I8 54 225 225

Table 1.1 Clearance needed for free air passage [mm]

1.3.4 Electrical Installation in General

All cabling must comply with national and local regulations on cable cross-sections and ambient temperature. Copper

conductors required, (75°C) recommended.

Power (kW) Torque (Nm)

Frame IP class 3 x 200-240 V 3 x 380-480 V Line Motor DC

connection

Control

terminals

Earth Relay

H1 IP20 0.25-1.5 0.37-1.5 1.4 0.8 0.8 0.5 0.8 0.5

H2 IP20 2.2 2.2-4 1.4 0.8 0.8 0.5 0.8 0.5

H3 IP20 3.7 5.5-7.5 1.4 0.8 0.8 0.5 0.8 0.5

H4 IP20 5.5-7.5 11-15 1.2 1.2 1.2 0.5 0.8 0.5

H5 IP20 11 18.5-22 1.2 1.2 1.2 0.5 0.8 0.5

H6 IP20 15-18 30-45 4.5 4.5 - 0.5 3 0.5

H7 IP20 22-30 55 10 10 - 0.5 3 0.5

H7 IP20 - 75 14 14 - 0.5 3 0.5

H8 IP20 37-45 90 242242- 0.5 3 0.5

Power (kW) Torque (Nm)

Frame IP class 3 x 380-480 V Line Motor DC connection Control

terminals

Earth Relay

I2 IP54 0.75-4.0 1.4 0.8 0.8 0.5 0.8 0.5

I3 IP54 5.5-7.5 1.4 0.8 0.8 0.5 0.8 0.5

I5 IP54 11-18.5 1.8 1.8 - 0.5 3 0.6

I6 IP54 22-37 4.5 4.5 - 0.5 3 0.6

I7 IP54 45-55 10 10 - 0.5 3 0.6

I8 IP54 75-90 14/24114/241- 0.5 3 0.6

Quick Guide VLT HVAC Basic Drive Quick Guide

6 MG18A302 - VLT®is a registered Danfoss trademark

Power (kW) Torque (Nm)

Frame IP class 3 x 525-600 V Line Motor DC connection Control

terminals

Earth Relay

H9 IP20 2.2-7.5 1.8 1.8 not

recommended

0.5 3 0.6

H10 IP20 11-15 1.8 1.8 not

recommended

0.5 3 0.6

H6 IP20 22-30 4.5 4.5 - 0.5 3 0.5

H7 IP20 45-55 10 10 - 0.5 3 0.5

H8 IP20 75-90 14/24114/241- 0.5 3 0.5

Table 1.2 Details of Tightening Torques

1Cable dimensions

≤

95 mm2

2Cable dimensions > 95 mm2

Quick Guide VLT HVAC Basic Drive Quick Guide

MG18A302 - VLT®is a registered Danfoss trademark 7

1.3.5 Connecting to Mains and Motor

The frequency converter is designed to operate all

standard three-phased asynchronous motors. For

maximum cross-section on wires please see section

1.7 General Specifications.

•Use a shielded/armored motor cable to comply

with EMC emission specifications, and connect

this cable to both the decoupling plate and the

motor metal.

•Keep motor cable as short as possible to reduce

the noise level and leakage currents.

•For further details on mounting of the

decoupling plate, please see instruction

MI02QXYY

•Also see EMC-Correct Installation in the Design

Guide, MG18CXYY.

1. Mount the earth wires to earth terminal.

2. Connect motor to terminals U, V and W.

3. Mount mains supply to terminals L1, L2 and L3

and tighten.

H1-H5 Frame

IP20 200-240 V 0.25-11 kW and IP20 380-480 V 0.37-22 kW.

130BB634.10

Motor

UVW-DC+DC

MAINS

1 Line

2 Earth

3 Motor

4 Relays

Quick Guide VLT HVAC Basic Drive Quick Guide

8 MG18A302 - VLT®is a registered Danfoss trademark

H6 Frame

IP20 380-480 V 30-45 kW

IP20 200-240 V 15-18.5 kW

IP20 525-600 V 22-30 kW

L1 91 / L2 92 / L3 93

U 96 / V 97 / W 98

03 02 01

06 05 04

234

130BB762.10

1 Line

2 Motor

3 Earth

4 Relays

H7 Frame

IP20 380-480 V 55-75 kW

IP20 200-240 V 22- 30 kW

IP20 525-600 V 45-55 kW

130BB763.10

1 Line

2 Relays

3 Earth

4 Motor

Quick Guide VLT HVAC Basic Drive Quick Guide

MG18A302 - VLT®is a registered Danfoss trademark 9

Andere Handbücher für VLT HVAC

Inhaltsverzeichnis

Andere Danfoss Gleichstromantrieb Handbücher

Danfoss

Danfoss VLT Active Front End AFE 302 Bedienungsanleitung

Danfoss

Danfoss VLT AutomationDrive FC 300 Bedienungsanleitung

Danfoss

Danfoss VLT Micro Drive FC 51 Series Bedienungsanleitung

Danfoss

Danfoss VLT AutomationDrive FC 302 Betriebsanleitung

Danfoss

Danfoss VLT AQUA Drive FC 200 Bedienungsanleitung

Danfoss

Danfoss VLT OneGearDrive Bedienungsanleitung

Danfoss

Danfoss AME 10 Bedienungsanleitung

Danfoss

Danfoss VLT AutomationDrive FC 301 Bedienungsanleitung

Danfoss

Danfoss VLT HVAC Drive FC 100 Series Betriebsanleitung

Danfoss

Danfoss AME 23 Bedienungsanleitung

Danfoss

Danfoss VLT AutomationDrive EZ FC 321 Betriebsanleitung

Danfoss

Danfoss VLT CD 302 Bedienungsanleitung

Danfoss

Danfoss VLT AutomationDrive FC 361 Leitfaden

Danfoss

Danfoss VLT AutomationDrive FC 361 Betriebsanleitung

Danfoss

Danfoss VLT FC 103 Bedienungsanleitung

Danfoss

Danfoss VLT AutomationDrive FC 302 with Connectors Bedienungsanleitung

Danfoss

Danfoss vlt fcd 302 Bedienungsanleitung

Danfoss

Danfoss VLT FC Series Bedienungsanleitung

Danfoss

Danfoss VLT 28 Bedienungsanleitung

Danfoss

Danfoss VLT Micro Drive FC 51 Series Betriebsanleitung

Danfoss

Danfoss VLT AutomationDrive FC 300 Betriebsanleitung

Danfoss

Danfoss VLT FC51 Leitfaden

Danfoss

Danfoss VLT Betriebsanleitung

Danfoss

Danfoss VLT AutomationDrive FC 300 Betriebsanleitung

Beliebte Gleichstromantrieb Handbücher anderer Marken

Vincent Associates

Vincent Associates UNIBLITZ ED12DSS Bedienungsanleitung

EKSMA OPTICS

EKSMA OPTICS DQ-100-4 Stücklistenhandbuch

Chamberlain Garog

Chamberlain Garog D Series Bedienungsanleitung

Parker

Parker PDS Series Bedienungsanleitung

Festo

Festo DGC G Series Einrichtungshandbuch

Binks

Binks QS-5012-1-CE Bedienungsanleitung

ABB

ABB ACQ580-01 Series Installationshandbuch

YASKAWA

YASKAWA CANopen SI-S3 Bedienungsanleitung

GE D20A6 Bedienungsanleitung

Unex

Unex MC-D-250-1000-050W-TW Bedienungsanleitung

Geckodrive

Geckodrive G213V Bedienungsanleitung

ABB

ABB RSYC-01 Bedienungsanleitung

Rockwell Automation

Rockwell Automation PowerFlex 700S Betriebsanleitung

WEG

WEG DeviceNet CFW500 Bedienungsanleitung

Siemens

Siemens SINAMICS G Datenblatt

Siemens

Siemens SINAMICS SM150 6SL3815-7NP41-0AA1 Betriebsanleitung

SOMFY

SOMFY JR RU 30 Bedienungsanleitung

Beckhoff

Beckhoff AX8911 Bedienerhandbuch
