DekPro EFFEX Bedienungsanleitung
Lighng Overview:
**See illustraon above as reference. Dashed lines are a representaon of approximate wire locaons, each installaon will vary.**
• Run wire from your transformer to the locaon of your rst post.
Note: Do not plug in transformer unl all wires are run.
• Wiring will go up the post to your rst lighng xture. Drill a minimum 1/2” hole through the deck board to allow passage
of the wiring through the board and into the post.
Tip: Laying post on its side prior to aaching to deck will allow for easier installaon of wire. Use a sh tape or equivalent
to pull wire to the top of the post. Tape wire to the top of post.
• Once wire is installed into rst post, stand the post upright and secure into place. (Plumb as necessary)
• From the rst lighng xture, run a 9’ Quick Connect Cable into the post and through the top rail to the next light.
Connue this method unl all lights are connected. (Brackets and posts need to be drilled to run wire)
Note: Wiring cannot be run through the top rail of stairs. For stairs, wiring should be run up the posts.
• Once lights are all connected, plug transformer into GFI protected 115V outlet and check to ensure all lights are illuminated,
if any lights have not illuminated unplug transformer and check connecons. Once all lights are working properly securely
aach caps to the post.
Components List:
A. Power Supply B. Wiring C. Post Cap
Deck Wiring Overview
DekPro™ EFFEX Low Voltage Lighng System
Installaon Guide
DekPro Manufacturing Inc. • P.O. Box 18566 • Minneapolis, MN 55418 • 1-855-433-5776
←
←
Quick
Connect
D
Post Cap
Wiring
Power Supply
Recessed Lights
Post Light
E
B
C
A
ꜜ
ꜜ
ꜜ
ꜜ
ꜜ
D. Post Light E. Stair Light
Outdoor
GFI Outlet
Timer / Photocell
Transformer
Dimmer
Output Wire
Output Wire
If not using Dimmer
connect Output Wire
directly to Transformer
LED DIMMER
+
_
+
_
Mode
(Includes Remote)
9’ Lead Wire
Post Cap
(Lighitng Fixture)
9’ Lead Wire
Post Cap
(Lighitng Fixture)
Connect to next
light fixture
Connect to next
light fixture
Lighng Components
DekPro™ EFFEX Low Voltage Lighng System
Installaon Guide
For full warranty coverage details visit www.dekpromfg.com
DekPro Manufacturing Inc. • P.O. Box 18566 • Minneapolis, MN 55418 • 1-855-433-5776
Wiring Post Cap
Run cable from the transformer up the rst post to
the post cap (left) and connect via Quick Connect
connections. From there, use a 9’ Quick Connect cable
to run through the top rail to the next post. Continue this
process until all post caps are connected. (Brackets and
posts will need to be drilled to accommodate cable)
Power Supply Diagram
←
←
←
←
←
←
←
←
←
. . . . . . . . . . . . . . . . . . . . . . . . . OR . . . . . . . . . . . . . . . . . . . . . . . . . . . .
←
←
←
*When using dimmer, ensure
all components are connected
before powering transformer*
Step 1
Ensure that all cable has
been properly installed
and test the lights before
mounting post cap to post.
Step 2
Fasten post cap to
the post using 2 each
screws included or use
silicone adhesive.
This guide represents the most common installaon method
for DekPro™ EFFEX lighng. More informaon can be found at our website
www.dekpromfg.com in regards to alternave wiring methods.
Quick
Connect
←
←
