DELTA ELECTRONICS, INC.
eceiver- RA1010-SAODT-IL
R
*Concentrator Standard Test Conditions: 25 °C, AM 1.5D, 900mW/m2
IEC62108 Qualification
Performance Test
10.1 Visual inspection Pass
10.11 Bypass diode thermal test Pass
Safety Test 10.4 Electrical insulation test
Reliability Test 10.6 Thermal cycling test In Progress
Pass
I-V Curve
0
2
4
6
8
10
12
14
16
0123
Voltage (V)
Current (mA)
Characteristics
Cell Material III-V
Cell Size (mm) 10X10
Cell Void Ratio <5%
Open Circuit Voltage (Voc)2.5V
Short Circuit Current (Isc) 12.8mA
Maximum Power Rating (Pmax) 28.2mW
Thermal Resistance <0.22oC/W
Resistance (Positive to Negative Contact) <2.9mΩ
