Quick-Start Guide

Denon DJ Prime 4

Setup

Installation and Setup

The Denon DJ Prime 4 is a “Serato DJ Pro hardware unlocked” device, meaning it works with Serato DJ Pro out of

the box. The Denon DJ Prime 4 also does not require drivers for macOS or Windows operating systems and is class

compliant and WDM compatible.

Please ensure you have the latest version of Serato DJ Pro installed:

Click here to download Serato DJ Pro

Serato DJ Pro requires the latest rmware be installed, which you can nd on Denon DJ’s download page.

Once you have the latest Serato DJ Pro build installed, and the latest rmware installed on the Prime 4, connect it to

your comptuer via the USB ports, and then tap the ‘computer’ icon that appears on the Prime 4 display:

4 5 6 7 8 9 10 11 12 13 14321

Overview

# PRIME 4 CONTROL FUNCTION

1 POWER BUTTON Turn device on

2 AC IN AC Power input

3 USB INSERT Connect USB storage device

4 USB INPUT Connect USB cable from PC to input

5 LINK Connect to other Denon DJ devices

6 ZONE OUTPUT XLR Zone Output

7 BOOTH OUTPUT XLR Booth Output

8 MASTER OUTPUT Balanced XLR & Unbalanced RCA Master Ouput

9 STEREO / MONO SWITCH Toggle STEREO/MONO for MASTER OUTPUT

10 LINE 4 LINE/PHONO SWITCH Toggle LINE/PHONO for Channel 4

11 LINE 1/2/3/4 INPUT RCA Line input for channels 1/2/3/4

12 LINE 3 LINE/PHONO SWITCH Toggle LINE/PHONO for Channel 3

13 MICROPHONE 1/2 INPUT XLR & 1/4” TRS input

14 GROUNDING POST Connect grounding wires for turntables

Overview

# PRIME 4 CONTROL FUNCTION SHIFT FUNCTION

1 MIC SECTION SEE MIC SECTION FOR MORE INFORMATION

2 FX 1 SECTION SEE FX SECTION FOR MORE INFORMATION

3 CHANNEL FX SELECT Select which FX bank you wish to use on channel

4 DISPLAY Touchscreen display

5 VIEW Cycle View mode Cycle through library panels

6 LIBRARY SCROLL /

LIBRARY CONTROLS

Rotate to scroll through library view in focus, press to select menu item.

BACK/FWD to cycle back/forward through panel

7 PHONES MIX / LEVEL / SPLIT ON/OFF Adjust headphone level / mix

8 CHANNEL TRIM / EQ Channel Trim / EQ controls

9 LOOP CONTROLS SEE LOOP CONTROLS SECTION FOR MORE INFORMATION

10 FX 2 SECTION SEE FX SECTION FOR MORE INFORMATION

11 MASTER / ZONE / BOOTH OUTPUT Adjust Master / Zone / Booth output level / EQ

12 SLIP Toggle Slip mode on selected deck

13 CENSOR Censors playing track Reverses playing track

14 KEY LOCK Toggle Key lock / Key sync (longpress) Reset Key

15 VINYL Toggle Vinyl mode

16 SD Connect SD card storage device

17 USB 1 Connect USB storage device

18 USB 2 Connect USB storage device

19 EJECT Edject media device

2121110 13 14 15 18 1916 17

202122232427282930313233343536373839 26 25

1 3 4 5 6 7 8 9

# PRIME 4 CONTROL FUNCTION SHIFT FUNCTION

20 TEMPO SLIDER Adjust playback speed Ignore tempo slider

21 PITCH BEND Pitch Bend Up/Down Pitch Range Up/Down - toggle be-

tween +/- 8, +/-16 and +/-50

22 PERFORMANCE PADS SEE PERFORMANCE PADS SECTION FOR MORE

23 BEAT JUMP Beat Jump forward / backward Change beat jump range

24 TRACK SKIP Skip forward / backward through tracks Search through track

25 DECK 2 / 4 Switch the deck to be operated between deck 2 / 4

26 SWEEP FX AMOUNT Use to control Sweep FX on each channel

27 CROSSFADER Crossfade audio between channel A-B

28 SWEEP FX SELECT Select Filter/Echo/Wash/Noise FX

29 CROSSFADER ASSIGN Assign crossfader to channel A / THRU / B

30 CHANNEL CUE Press to cue channel for monitoring in headphones

31 CHANNEL FADER Adjust channel volume Channel fader start

32 BEAT GRID CONTROLS SEE BEAT GRID CONTROLS SECTION FOR MORE

33 PARAMETER CONTROLS Adjust parameters in pad modes

34 SHIFT Used with other controls that have SHIFT modier function

35 JOG WEEL Adjuyst playing track / waveform

36 DECK 1 /3 Switch the deck to be operated between deck 1 / 3

37 PLAY / PAUSE Plays or pauses song loaded to deck Stutter play

38 CUE Cues from temp cue point/Set temp cue point

39 SYNC Sync ON Sync OFF

Overview

Mic Section

FX Section

Loop Controls

Beat Grid Controls

The Denon DJ Prime 4 has two microphone inputs on the back panel of the controller. Both XLR and 1/4”

TRS cables can be connected to these inputs.

Each MIC input has an ON/OFF switch, Level & EQ controls and an ECHO eect ON/OFF switch. Engage

the microphone talkover function using the TALKOVER button.

The Denon DJ Prime 4 has two FX sections above the left and right decks on the controller.

Here you can adjust FX type, FX parameter(s), FX frequency and FX wet/dry amount or timing.

The Denon DJ Prime 4 has a dedicated loop section for each deck.

Trigger an auto loop by pressing the scroll knob. Lengthen an auto loop by turning the scroll knob

clockwise, shorten an auto loop by turning the scroll knob anti-clockwise.

Trigger a manual loop using the IN and OUT buttons. You can shift a loop by using the SHIFT modier + the

scroll knob.

The Denon DJ Prime 4 has dedicated Beat Grid controls for each deck.

Enter beat grid editing mode for a track loaded to deck using the EDIT GRID button. Adjust the beat grid

to the left or right using the designated buttons, using the SHIFT modier for smaller adjustments. Hold the

SHIFT modier + EDIT GRID to reset the loaded track’s beat grid. Once you are done, press the EDIT GRID

button to save and exit Beat Grid editing mode.

The Denon DJ Prime 4 has 8 performance pads on each deck which can be used in 10 dierent modes.

HOT CUE mode: In this mode, pads 1-8 add or trigger existing Serato DJ Pro Cue Points. Holding shift and pressing

pads 1-8 will delete the Cue Points. If no Cue point is present on that slot/pad, pressing that pad will set a Cue point.

Holding SHIFT while pressing a pad will clear the Cue point from that pad/slot.

CUE LOOP mode: Press the HOT CUE button twice to enable Cue Loop mode. Triggering a Cue in this mode will also

activate a loop. Loop size can be changed with the left and right PARAMETER buttons. Press SHIFT while triggerring a

Cue allows you to reloop.

SAVED FLIP mode: Hold SHIFT while pressing HOT CUE button mode to enable Saved Flip Mode. Press pads 1-8 to

trigger a saved ip.

SAVED LOOP mode: In this mode, pads 1-8 select and trigger the respective Saved Loop slots or save a new

Loop (if slot is empty). Holding SHIFT while pressing pads 1-8 will retrigger the Saved Loop. Press the left and right

PARAMETER buttons to increase/decrease Saved Loop size.

AUTOLOOP mode: Press the LOOP button twice to enable Autoloop mode. In this mode pads 1-8 trigger an

Autoloop of varying sizes. Press the pad for a second time to exit an Auto Loop. Use the left and right PARAMETER

pads to halve or double loop size. Hold SHIFT + left/right PARAMETER buttons to shift the loop in either direction.

ROLL mode: Holding pads 1-8 will activate a Loop Roll of dierent sizes. Release the pad to disengage the Loop Roll.

Press the LEFT and RIGHT pads to halve or double the loop roll size.

SAMPLER mode: Press the ROLL button twice to enable Sampler mode. Pads 1-8 to trigger samples loaded into

the Serato DJ Pro Sampler. Hold SHIFT while pressing a pad to stop the sample playback once triggered, or load

a sample to the respective Sampler slot if no sample is loaded. Use the left and right PARAMETER pads to move

between sample banks, and SHIFT + left/right to cycle forward and backwards through the Sampler Output options.

SLICER mode: In this mode a specied range (or domain) is divided into eight equal sections, and these eight sliced

sections are assigned to the respective performance pads (1-8), and can be triggered by pressing them. The domain

shifts as the track duration elapses. Use the SHIFT + left/right PARAMETER buttons to decrease or increase the

domain size.

SLICER LOOP mode: Press the SLICER button twice to enter Slicer Loop mode. This is a xed Slicer Domain or

‘loop’. Pads 1-8 will trigger the slices. Use the SHIFT + left/right PARAMETER buttons to decrease or increase the

domain size.

PITCH PLAY mode: Hold SHIFT while pressing Hot Cue mode to enable Pitch Play mode. Press pads 1-8 to play Cue

points over variable pitch ranges. See the ‘Pitch Play’ section for more information.

Performance Pads

Holding SHIFT and pressing the SLICER performance pad mode button on the Denon DJ Prime 4 will enable

Pitch Play mode. In this mode you can play Cue Points over variable pitch ranges.

There are 3 key ranges to choose from. The following tables show pitched key ranges (in Semitones) while

using the 8 performance pads in Pitch Play mode. To toggle beteen key ranges press the Parameter left &

right buttons.

The root key pad (0) is always lit white, which will play the cue point at it’s regular pitch.

Pressing Parameter left & right while holding SHIFT will shift up or down a single semitone. In Pitch Play

mode, pressing a pad will pitch the currently selected cue point up or down the following ranges:

Up Range: (Up 7 Semitones)

+4 +5 +6 +7

0 +1 +2 +3

Middle Range: (Up 3/Down 4 Semitones

0 +1 +2 +3

-4 -3 -2 -1

Down Range: (Down 7 Semitones)

-3 -2 -1 0

-7 -6 -5 -4

When Pitch Play mode is rst enabled, the middle range is selected. If a new track is loaded, key mode will

default to middle range.

PITCH PLAY can only pitch one Cue point at a time. To change the selected Cue, hold the SHIFT button

and press a performance pad where the cue point you want to select would be (as shown in the CUES

performance pad mode). While holding SHIFT, press the corosponding performance pad for:

Cue 1 Cue 2 Cue 3 Cue 4

Cue 5 Cue 6 Cue 7 Cue 8

The selected cue point defaults to Cue Point 1 on track load, even if instant doubled. If a pad with no cue

point is selected, then a new cue point will be created. Deleting a cue point however, is not possible in

PITCH PLAY mode. Range is remembered if you choose another pad mode, then go back. If a new track is

loaded, the mode will default to middle range.

NOTE: Pitch Play mode is available once the Pitch ‘n Time DJ Expansion Pack has been activated

in the MY SERATO window. Make sure “Enable Pitch ‘n Time DJ” is checked in the Expansion Pack

tab of the SETUP screen.

Pitch Play

Beat Jump

To activate Beat Jump, open the Setup screen and under the DJ preferences tab turn on “Show Beat Jump

Controls”.

When you close the Setup screen you will see Beat Jump controls underneath the existing Auto Loop values on

each deck. Checking this box will turn on Beat Jump features in the deck area and let you control Beat Jump

from on your supported Serato DJ Pro hardware.

When the Beat Jump option is enabled, the LOOP ROLL perfomance pad mode will use the bottom row of 4

pads (pads 5-8) as Beat Jump controls. This is designed to mirror the change in deck Auto Loop area (from 8

Auto Loop sizes to 4 Auto Loop sizes + Beat Jump controls).

MIDI

The MIDI feature in Serato DJ Pro provides the ability to remap Serato DJ Pro software functions to your

primary Serato controller, interface or mixer. You can also assign controls to a secondary MIDI controller to

further enhance your performance.

For more information on MIDI mapping with Serato DJ Pro click here

To remap your supported Serato device, open the SETUP screen and click the MIDI tab. If your Serato

device supports hardware remapping, it will show up in the MIDI Devices list at the top.

Select your connected device from the MIDI Devices list and make sure the “Allow Serato Hardware

Remapping” option is checked.

Once checked, the MIDI assign button at the top of the screen will become available for you to start

remapping.

You can save, edit or delete MIDI presets in the MIDI tab of the SETUP screen. Clicking ‘Restore Defaults’

will erase any custom mappings for all connected devices and revert their functions back to default.

Help

Show Tooltips

Click on the button in the upper right-hand corner of Serato DJ Pro, then to enable

tooltips. Tool tips provide a handy way to learn the various features of Serato DJ Pro.

Move the mouse over a section of the screen to bring up a context sensitive tool tip.

Watch Tutorials

Click on the button in the upper right-hand corner of Serato DJ Pro, then to launch

your default internet browser and watch tutorials, to help you get familiar with Serato DJ Pro.

Get Support

Click on the button in the upper right-hand corner of Serato DJ Pro, then to launch your

default internet browser and navigate to the Serato DJ Pro knowledge base, where you can nd helpful

articles and guides on Serato DJ Pro. Alternatively, type in the box, with keywords, to

search the Serato DJ Pro knowledge base for specic, related topics.

The Denon DJ Prime 4 is ‘paid upgrade to Serato DVS hardware’, meaning it requires activation of a Se-

rato DVS license to allow you to use turntables or CD players to control Serato DJ Pro using NoiseMap™

Control Tone records or CDs. Serato DVS can be activated using an included voucher, or by purchasing it

directly from store.serato.com. You can nd out more and purchase DVS, by visiting our website here.

DVS

Andere Handbücher für PRIME 4

Inhaltsverzeichnis

Andere Denon DJ-Equipment Handbücher

Denon

Denon PRIME GO Bedienungsanleitung

Denon

Denon SC5000 PRIME Bedienungsanleitung

Denon

Denon SC5000 PRIME Bedienungsanleitung

Denon

Denon DN-X1500 Bedienungsanleitung

Denon

Denon PRIME GO Bedienungsanleitung

Denon

Denon DS1 Bedienungsanleitung

Denon

Denon DN-HC5000 - Serato ITCH Hardware/Software... Bedienungsanleitung

Denon

Denon DN-MC6000 Bedienungsanleitung

Denon

Denon MCX8000 Bedienungsanleitung

Denon

Denon DN-S3000 Bedienungsanleitung

Denon

Denon PRIME 4 Bedienungsanleitung

Denon

Denon SC5000 PRIME Bedienungsanleitung

Denon

Denon DN-X1500 Bedienungsanleitung

Denon

Denon MC4000 Bedienungsanleitung

Denon

Denon SC6000 PRIME Bedienungsanleitung

Denon

Denon DN-X120 Bedienungsanleitung

Denon

Denon DN-MC6000 Bedienungsanleitung

Denon

Denon DN-X1500 Bedienungsanleitung

Denon

Denon SC5000M Prime Bedienungsanleitung

Denon

Denon engine dj SC LIVE 4 Bedienungsanleitung

Denon

Denon DN-X100 Bedienungsanleitung

Denon

Denon PRIME 4 Bedienungsanleitung

Denon

Denon DNHD2500 - Dual DJ MP3 Player Bedienungsanleitung

Denon

Denon MCX8000 Bedienungsanleitung

Beliebte DJ-Equipment Handbücher anderer Marken

ALPHA LITE

ALPHA LITE ALPHA 1500 Betriebsanleitung

Chauvet

Chauvet OVATION E-930VW Bedienungsanleitung

Zumtobel

Zumtobel APHRODITE Home Bedienungsanleitung

Snow Masters

Snow Masters Zig Oscillator Bedienungsanleitung

EuroLite

EuroLite 50530554 Bedienungsanleitung

Beamz

Beamz BUV243 Bedienungsanleitung

thomann

thomann Stairville DJ Lase 40-G MK-III Bedienungsanleitung

Eagletone

Eagletone 6 Eyes Flower Bedienungsanleitung

EuroLite

EuroLite FLD-1508 Bedienungsanleitung

Technical Pro

Technical Pro LG8xSEA Bedienungsanleitung

JB Systems

JB Systems Lounge Laser DMX Bedienungsanleitung

Lightmaxx

Lightmaxx Vega Halo 90 Bedienungsanleitung

Elation

Elation FUZE WASH Z350 Bedienungsanleitung

Maverick

Maverick MK3 WASH Bedienungsanleitung

Infinity

Infinity TF-260C7 Fresnel Bedienungsanleitung

Chauvet

Chauvet EVE E-50Z Bedienungsanleitung

Eliminator Lighting

Eliminator Lighting E 138 Bedienungsanleitung

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Bedienungsanleitung
