PORTABLE DVD

Before connecting, operating or adjusting this product,

please read this user's manual carefully and completely.

USER'S MANUAL

MT-758 MPEG4

Table of Contents

Contents

Safety Precautions

P3-P4

Before Use(Continued)

Table of Contents

P5-P8

Identification of Controls

Main Unit

Battery Pack

Remote control unit

DVD Introduction

Getting Started P8-P10

Insert the battery

P16-P23

SETUP Menu Setting

P9-P10

P16

General Operation

P9-P10

P16-P18

General Setup Page

P9-P10P9-P10P9-P10

P24-P25

Parameters and specifications

P9-P10

P26

Troubleshooting tips

P9-P10P9-P10

P27

Definition of terms

Audio Setup Page

P18

P9-P10

Dolby Digital Setup

P19-P20

P9-P10

Preference Page

P21-P23

P11

Playing an Audio CD or MP3/WMA

Basic operation P11-P15

P12

Audio CD and MP3/WMA Disc Features

P12-P13

Playing a JPEG Disc

P9-P10

Playing a DVD or Video CD(Operation)

P13

Playing a DIVX Movie Disc

P14

Program playback(not for Picture CD/MP3)

DIGITAL CARD and USB Play operation

P15

Speaker Setup Page

P19

P9-P10

Video Setup Page

P21

P9-P10

Password Setup Page

P23

Warning:To reduce therisk of electricshock,do not remove

the cover orback of this product.There are nouser-serviceable

parts inside. Referservicing to qualified service personnel.

Warning: To reduce therisk of fire or electric shock,do not

expose this productto dripping or splashing water,rain,or

moisture. Do notplace objects filled with water suchas vases,

on the Product.

Warning: Thisdigital video disc player employs alaser system.

Use of controls,adjustments,or the performance of procedures

other than thosespecified herein may result in hazardous

radiation Exposure.

Warning: To prevent directexposure to laser beam,do not open

the enclosure.Visible laserradiation when open.

Warning: Never stare directly intothe laser beam.

Caution: Do notinstall this product in a confinedspace such

as a bookcase or similar unit.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NNotes on Copyrights:

It is forbiddenby law to copy, broadcast,show,broadcast via

cable, play inpublic, or rent copyrighted material without

permission.

This product featuresthe copy protection function developed by

Macrovision.Copy protection signalsare recorded on some discs.

When recording andplaying the pictures of these discspicture

noise will appear.This product incorporates copyright protection

technology that isprotected by method claims of certainU.S.

Patents and otherintellectual property rights owned by Macrovision

Corporation and otherrights owners.Use of this copyright protection

technology must beauthorized by Macrovision Corporation, and is

intended for homeand other limited viewing uses only unless

otherwise authorized bymacrovision Corporation. Reverse

engineering or disassemblyis prohibited.

SERIAL NUMBER:

You can find the serial number on the back of the unit.This number

is unique to this unit and not available to others.You should record

requested information here and retain this guide as a permanent

record of your purchase.

Model No. ______________________________

Serial No. ______________________________

Date of Purchase_________________________

Safety Precautions

CAUTION

Before using the player, please ensure that the local AC voltage is suitable for this unit.

The above items are true of not only this unit but also most of the household electronic products.

Before Use(Continued)

To ensure proper use of this product, please read this owner's manual

carefully and retain for future reference.

This manual provides information on the operation and maintenance of

your DVD player. Should the unit require service, contact an authorized

service location.

Symbol Used in this Manual

The lightning flash symbol alerts you to the presence of dangerous

voltage within the product enclosure that may constitute a risk of

electric shock.

The exclamation point alerts you to the presence of important

operating and maintenance / servicing instructions.

Indicates hazards likely to cause harm to the unit itself or other

material damage.

Note:

Indicates special notes and operating features.

Introduction

Tip:

Indicates tips and hints for making the task easier.A section whose title

has one of the following symbols is applicable only to the disc

represented by the symbol.

Video CDs

Audio CDs

MP3 Discs

WMA Discs

JPEG Discs

Divx Discs

DVD

VCD

MP3

WMA

JPEG

DIVX

About the Symbol Display

¡° ¡±may appear on your TV display during operation and indicates

that the function explained in this owner's manual is not available on

that specific DVD video disc.

Storing Discs

After playing,store thedisc in its case.Do not exposethe disc to direct

sunlight or sourceof heat and never leave itin a parked car exposed

to direct sunlight.

Cleaning Discs

Fingerprints and duston the disc can cause poorpicture quality and

sound distortion. Beforeplaying,clean the disc with a cleancloth.

Wipe the discfrom the center out.

Notes on Discs

Handling Discs

Do not touchthe playback side of the disc.Hold the disc by the edges

so that fingerprintsdo not get on the surface.Never stick paper or tape

on the disc.

Do not usestrong solvents such as alcohol,benzine,thinner,

commercially available cleaners,or anti-static spray intended for older

vinyl records.

DVD and finalized DVD+R/RW

Before Use (Continued)

Notes:

Dirty disc may cause bad picture.

This indicates aproduct feature that is

capable of playingDVD-RW discs

recorded with VideoRecording format.

1.Depending on theconditions of the recording equipment orthe

CD-R/RW (or DVD-R, DVD +R,DVD -RW, DVD+RW) disc itself,

someCD-R/RW (or DVD-R, DVD +R, DVD -RW,DVD +RW) discs

cannot be playedon the unit.

2.Do not attachany seal or label to eitherside (the labeled side or

the recorded side)of a disc.

3.Do not useirregularly shaped CDs (e.g., Heartshaped or

octagonal)since they mayresult in malfunctions.

4.Some playback operationsof DVDs and Video CDs maybe

intentionally programmed bysoftware manufacturers. Thisunit

plays DVDS andVideo CDs according to disc content designed

by the softwaremanufacturer, therefore some playback features

may not beavailable or other functions may beadded.

Manufactured under licensefrom Dolby Laboratories."Dolby",

"Pro Logic", andthe double-D symbol are trademarks of

Dolby Laboratories.

Region code

This DVD playeris designed and manufactured for

playback of region"2"encoded DVD software.

This unit canplay only DVD discs labeled "2"or "ALL".

Notes on RegionCodes

Most DVD discshave a globe with one ormore numbers in it clearly

visible on thecover. This number must matchyour DVD player's

region code orthe disc cannot play. Ifyou try to play a DVDwith

a different regioncode from your player,the message"Check

region Code" appearson the TV screen.

_________________________________________

Video CD (VCD)

(8 cm / 12 cm disc)

DVD

(8 cm / 12 cm disc)

Types of Playable Discs

Audio CD

(8 cm / 12 cm disc)

In addition, this unit plays , DVD -R, DVD +R,DVD -RW,DVD +RW,

Kodak Picture CDs, SVCD, and CD-R / CD-RW that contains audio

titles,MP3, WMA,JPEG and DivX files.

C0MPATIBLE

Weak batteries can leak and severely damage the remote control unit.

Identification of Controls

Main Unit

1.TFT screen

2.Speakers

3. MODE

Could enter video setup page, adjust brightness, contrast, hue, etc.

4.SOURCE

Select input source, DVD/AV in/card,usb.

5. SETUP

6. MENU

7. STOP

8. PLAY/PAUSE

9. (Left/right/up/down)

Select an item in the menu.Enter confirms menu selection.

Could adjust TV channel in TV Mode.

10.NEXT

11.PREVIOUS

12.Open

13.USB

14.SD/MMC/MS

15.Power ON/OFF switch

16.Volume control

17.Headphone out jacks

18.Digital Audio out(coaxial)

19.AV IN

20.AV OUT

21.DC IN 9V

1010

1111

2121

1212

1313 1414 1515 1616 1818 1919 2020 2121

1717

Identification of Controls

Battery Pack

RELEASE

Detaching the batterypack to separate the battery pack,pull

the switch whichis locate beside the battery packthen slide

down the battery pack at thesame time.

Charge the batterypack before using it for thefirst time.

Attaching the batterypack

1.Match the hooksof the battery pack into theholes on the

bottom of theplayer.

2.Combine the batterypack to push up until youcan

hear the clicksound.

1.Power charge indicatorduring recharging , indicator is red.If

recharging is complete,charge indicator changes to green.

2.Remote sensor.

3.Battery pack.

Warning:

For production safety, This DVDplayer was designed current protection.

When you chargingbattery,and when DVD player ispower on ,the charging

mode is SLOW , when DVD player is power off, thecharging mode is FAST .

The indicator turnsto green when charging completed.

Note: In SLOW charging mode ,charge time is approximate twenty hours.

In FAST charging mode, charge time is approximate four hours.

"" ""

Turn off the power and keep AC cord pulled out from the outlet when connecting the systerm.

Remote control unit

1. PLAY/PAUSE ( )

Starts playback orpause playback.

2. STOP ( )

Stops playback.

3. Reverse Skip( )

Go to previouschapter / track or to the

beginning.

4. Forward Skip( )

Go to thenext chapter / track.

5.ZOOM

Enlarges video image.

6.REPEAT

Repeat chapter,track, title all.

7.A B

Repeat sequence.

8. PROGRAM

Place a trackon the program list.

10.TITLE

11.POWER

Switches DVD Playerstandby mode.

12.0-9 NUMBER BUTTON

Selects numbered itemsin a menu.

13.ENTER

Confirms menu selection.

.SOURCE

DVD,AV IN,card.

Return to DVDtitle menu.

14. MENU

Accesses menu ona DVD disc.

(Left/right/up/down)

15.DISPLAY

Accesses On-Screen display.

16.AUDIO

Selects an audiolanguage (DVD).

17.SUBTITLE

Selects a subtitlelanguage.

18.ANGLE

Selects a DVDcamera angle if available

19.SETUP

Accesses or removessetup menu.

20.10+ BUTTON

Add 10+ whileyour selection is more than10.

21.STEP

Step the motionin DVD mode.

22. BUTTON

Fast backward.

23. BUTTON

Fast forward.

24. PBC

PBC on/off switch.

25.SLOW

Slow playback

26.SEARCH

Goto time point, title or chapter you want in

DVD Mode

27. MUTE

Disable Audio output.

SOURCE

SLOW

STEP

1111 99

1616

1818

1414

2121

2222

2323

1212

2020

1919

1313

2424

1515

1717

1010

2525

2626 2727

Identification of Controls

Insert the battery DVD Introduction

Getting Started

Refer to thedrawing, take the back cover ofthe remote control off

and remove theempty battery receptacle.

Prior to shipping,a separating film was applied to the battery.

Remove this film.

Insert the batteryinto the receptacle and insert thereceptacle into

the remote.

For the bestresults,aim the remote towards at theplayer's receiving

window. Staywithin 15 feet and angles of60 degrees or less.

Under normal usethe battery will last for oneyear.

Remove battery duringstorage or when you are not using the DVD

player for along time.

1.Open the batterydoor. 2.Insert twoAAA size batteries.

DVD+R/RW

DVD -R andDVD +R are two different standardsfor recordable DVD

drives and discs.This format allows information to berecorded onto

the DVD disconly once. DVD +RW and DVD-RW are twostandards

for re-writable media,meaning the DVD content can beerased and

re-recorded. Single-sided discscan hold 4.38 gigabytes and

double-sided discs holdtwice as much.There are no duallayer

single sided recordablediscs.

VCD (Video CD)

A VCDholds up to 74 minutes (650MB disc) or 80 minutes (700MB

disc) of MPEG-1full-motion video along with quality stereosound.

MPEG

MPEG is aninternational standard for video and audiocompression.

MPEG-1 is usedin encoding video for VCD andprovides for

multichannel surround soundcoding such as PCM, Dolby Digital,

and MPEG audio.

MP3

MP3 is apopular compression format used for digitalaudio files that

yields very highnear-CD quality.

WMA

Windows media audiofile. Atype of coding / decoding developedby

Microsoft Corp.

JPEG

Joint Pictures ExpertGroup. JPEG is a compressed fileformat that

allows you tosave images with no limit onthe number of colors.

DIVX

Divx is thename of a revolutionary new videocodec.which is based

On the newMPEG-4 compression standard for video.You will be

able to playDivx movies using this DVD player.

Title (DVD videodiscs only)

A titleis generally a distinct section ofa DVD disc. For example the

main feature couldbe title 1, a documentary describinghow the film

was made couldbe title 2, and cast interviewscould be title 3. Each

title is assigneda reference number enabling you tolocate it easily.

Getting Started

Playback Setup

1. turn onthe power switch at the leftside of theproduct.

2. Press OPENto open the disc tray and insert your chosen

disc in thetray, with the playback sidedown.

3. Close thetray. Playback will start automatically.

Use the buttonsto select the title/chapter you want to

view, thenpress ENTER to start.Press MENU to return to the

menu screen.

Use the numberbuttons to select the track you want to viewand

press MENU toreturn to the menu screen. Menusettings and

operating procedures maydiffer.Follow theinstructions on the

each menu screen.

Notes:

1.If parental controlis set andthe disc isn't fit for the rating

setting you mustinput the password.(See "parental" on page 22).

2.DVDs may havea region code.Your player does not play

discs that havea region code different from yourplayer.

3.Unless stated otherwise,all operations described usethe

remote control.Some featuresmay also beavailable on the

setup menu.

Playing a DVD or Video CD(Operation)

VCD

DVD

Most of the functions can be controlled by remote control unit.Most of the functions can be controlled by remote control unit.

9Specifications and design are subject to change without prior notice.

Most of the functions can be controlled by remote control unit.Most of the functions can be controlled by remote control unit.

DVD VCD

Moving to anotherCHAPTER/TRACK

When a titleon a disc has more thanone chapter or a disc has

more than onetrack, you can move to another chapter/track as

follows:

1.Press SKIP or briefly during playbackto select the next

(or previous)chapter/track orto return to the beginning ofthe current

chapter/track.

2.Press SKIP twicebriefly to step back to theprevious

chapter/track.

3.Togo directly to any chapter duringDVD playback, input the

chapter/track number .

Changing the Audio Channel

Press AUDIOrepeatedly during playback to hear adifferent audio

channel (Stereo, Left,or Right).

Repeat A-B

Torepeat a sequence.

1. PressA-B at your chosen starting point" A". Appears

briefly on theTV screen.

2. PressA-B again at your chosen endpoint." AB"appears

briefly on theTV screen and the repeat sequencebegins.

3. PressA-B again to cancel.

Repeat

You can play atitle/chapter/all/track on a disc repeatedly.

Press REPEATduring playback toselect a desired repeat mode.

VCD

DVD VCD

Inhaltsverzeichnis

Andere Denver Tragbarer DVD-Player Handbücher

Denver

Denver MT-979DVBT Bedienungsanleitung

Denver

Denver MT-703 Bedienungsanleitung

Denver

Denver MT-779DVBT Bedienungsanleitung

Denver

Denver MT-772DVBT Bedienungsanleitung

Denver

Denver MT-1002DVBT Bedienungsanleitung

Denver

Denver MTW-751 TWIN Bedienungsanleitung

Denver

Denver MTW-735 TWIN Bedienungsanleitung

Denver

Denver MT-772 DVBT Bedienungsanleitung

Denver

Denver MT-783NB Bedienungsanleitung

Denver

Denver MT-1084NB Bedienungsanleitung

Denver

Denver MT-784NB Bedienungsanleitung

Denver

Denver MT-1002 BLACK Bedienungsanleitung

Denver

Denver MT-980T2H Bedienungsanleitung

Denver

Denver MTW-728 TWIN Bedienungsanleitung

Denver

Denver MT-1063 Bedienungsanleitung

Denver

Denver MT-983NB Bedienungsanleitung

Denver

Denver X-VIEW PDVD-193D Bedienungsanleitung

Denver

Denver MT-1097 Bedienungsanleitung

Denver

Denver MT-908 Bedienungsanleitung

Denver

Denver MT-1083NB Bedienungsanleitung

Denver

Denver MT-752C Bedienungsanleitung

Denver

Denver MT-768 Bedienungsanleitung

Denver

Denver MT-774 Bedienungsanleitung

Denver

Denver MT-779 Bedienungsanleitung

Beliebte Tragbarer DVD-Player Handbücher anderer Marken

Philips

Philips PET718/77 Bedienungsanleitung

Impecca

Impecca DVP775 Bedienungsanleitung

NextBase

NextBase MULTI-VISION SET PRO Bedienungsanleitung

Impecca

Impecca DVP-1017 Bedienungsanleitung

Akura

Akura APDVD6008 Bedienungsanleitung

TV Star

TV Star TD3 LCD COMBO Bedienungsanleitung

LENCO

LENCO MES-202 Bedienungsanleitung

Philips

Philips PET940/98 Bedienungsanleitung

Philips

Philips PET702P Bedienungsanleitung

Philips

Philips PD7016 Bedienungsanleitung

Logik

Logik L7SPDVD11 Bedienungsanleitung

LG DP650 Bedienungsanleitung

Mustek

Mustek MVP850B Bedienungsanleitung

Insignia

Insignia NS-MDDVD10 Bedienungsanleitung

Philips

Philips PD9000/12 Bedienungsanleitung

LENCO

LENCO DVP-1027 Bedienungsanleitung

Philips

Philips PD7010/05 Bedienungsanleitung

Technika

Technika PDVDTWINSS10 Benutzerhandbuch
