Diamond View 1995SL Bedienungsanleitung

DIAMOND VIEW

1995SL

Colour Monitor

19” (48cm) CRT Size

18” (45.7cm) Viewable Area

User’s Manual

G/MO1995SL/0102/2

Table of Contents

1Important Safety Instructions...........................................1

2Features .............................................................................2

3Unpacking the Monitor......................................................3

4Installation .........................................................................3

Drivers for Windows 95, 98, 2000 and Millennium Edition.............4

5Adjusting the Monitor .......................................................5

Selecting Functions and Making Adjustments...............................6

Contrast Hotkey............................................................................6

Brightness Hotkey.........................................................................6

The Main Menu ................................................................................6

Make adjustments.........................................................................7

Timing and Refresh Rate Setting..................................................11

Factory Preset Timings.................................................................12

6Troubleshooting..............................................................13

7Specifications..................................................................15

8Service Contacts .............................................................17

Australian Service Contacts .........................................................17

New Zealand Service Contacts.....................................................18

part of this publication may be reproduced, transmitted, transcribed, stored in

a retrieval system or translated into any language or computer language, in

any form or by any means, electronic, mechanical, magnetic, optical,

chemical, manual or otherwise, without the prior written permission.

Disclaimer

Mitsubishi Electric Australia Pty. Ltd. makes no representations or

warranties, either expressed or implied, with respect to the contents hereof

and specifically disclaims any warranties, merchantability or fitness for any

particular purpose. Further, Mitsubishi Electric Australia reserves the right to

revise this publication and to make changes from time to time in the contents

hereof without obligation to notify any person of such revision or changes.

Diamond View is a registered trademark of Mitsubishi Electric Australia Pty. Ltd.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

All other trademarks remain the property of their respective owners.

Reference Information

For future reference, write the following information about your

monitor in the space below. The serial number is on the back of

the product or on the bottom of its stand.

Monitor Information

Product Name: Diamond View 1995SL

Serial Number:

Date of Purchase:

Dealer Information

Dealer:

Telephone

Number:

Address:

1Important Safety Instructions

Please read the following safety instructions before installing or cleaning your

Diamond View monitor:

1. This monitor must be operated from the type of power source indicated

on the rating label. If you are not sure of the type of power available in

your area, consult your dealer or local electricity supply company.

2. This monitor must be operated with a 3 wire electrical cable that has a

plug with a third (grounding) pin. The plug must only be connected to a

grounded power outlet. This is a safety feature. If you are unable to

insert the plug into the outlet, contact your electrician to make the

necessary outlet changes. Australian and New Zealand customers

should use the power cable supplied with the monitor.

3. Make sure that the power outlet that you plug the monitor into is easily

accessible.

4. Unplug the monitor’s power cable from the wall outlet before cleaning.

Do not use liquid or aerosol cleaners. Use a soft cloth to clean the

monitor housing and screen.

5. Slots and openings on the back or top of the cabinet are provided for

ventilation. They must not be blocked or covered. This product should

never be placed near or over a radiator or other heat source, or in a

built-in installation unless proper ventilation is provided.

6. Never push objects of any kind, or spill liquid of any kind into the

monitor.

7. Do not attempt to service the monitor yourself as opening or removing

covers may expose you to dangerous voltages or other risks. Removing

the cover of the monitor may void warranty.

8. If any abnormal operation or an accident (such as dropping the unit)

occurs, disconnect the monitor from the wall power outlet and contact

qualified service personnel.

2Features

Your Diamond View 1995SL Monitor has the following features:

♦Plug’n Play Compatibility

With DDC1and DDC2B, the 1995SL is compatible with Plug and

Play feature of MicrosoftWindows95, 98, 2000 and Millennium

Edition.

♦Flicker-free Image

The monitor supports VESA standard graphics signals with flicker-free

refresh rates at resolutions up to 1280 x 1024 pixels at 85Hz.

♦Larger Viewable Size

With its 45.7 cm (18”) viewable size, the 1995SL offers a larger

viewable screen area than many other 19”monitors.

♦Easy to Use On Screen Display

The On-Screen Display (OSD) allows you to adjust all settings simply

with on-screen menus.

♦Power Saving Function

The power management complies with VESA DPMS standard. When

the system is idle (off mode), the monitor automatically cuts its power

consumption up to 95%.

♦Green Commitment

No CFCs are used in the manufacturing process of your monitor. It

complies with the US government’s Energy Star standards and the

rigorous standards of Scandinavian countries.

3Unpacking the Monitor

Please check that the following items are included with your monitor. If they

are missing or damaged, please contact your place of purchase immediately.

♦Monitor with attached signal cable

♦Power cord

♦User’s manual

Locate the model name and the serial number label on the back of your

monitor and write the details of the monitor and your place of purchase in the

space on page (ii) of this manual for future reference.

4Installation

Your monitor is equipped with an automatic power supply with a voltage

range from 100 to 240 Volts AC at a frequency of 50 to 60 Hz.

To install your Diamond View 1995SL monitor:

1. Make sure that the computer

system’s power is turned off.

2. Connect the power cord to the

monitor and attach it to a power

socket.

3. Connect the computer end of the D-

SUB cable to the 15-pin output

connector on the video board of your

computer.

4. Turn the monitor and the computer

on.

If you wish to connect the monitor to an older-type Apple Macintosh, you

need to use a Macintosh cable adapter to connect the video signal cable of

your monitor to the video port of the computer. Your computer dealer should

be able to supply you with a suitable adaptor.

Drivers for Windows 95, 98, 2000 and Millennium Edition

Windows will detect the Diamond View 1995SL monitor the first time you turn

the computer on after installing it. The Add New Hardware wizard will prompt

for drivers. Install the standard Windows Plug & Play Monitor driver. This

driver will work correctly and allow you to use the monitor with its optimal

resolutions and refresh rates.

A specific driver that includes the Windows ICC/ICM colour profile for the

Diamond View 1995SL is available from Mitsubishi Electric Australia’s web

site at

http://www.mitsubishi-electric.com.au

Follow the link to the File Downloads/Monitors section of the site to download

the drivers. Installation instructions are also available from at the monitor

driver page.

5Adjusting the Monitor

nter

Exit

2 3 4 5

You can adjust the monitor using its On-Screen Display (OSD) menu system.

There are 5 buttons that control the monitor:

1. Exit Returns to the last menu page, saves changes or

quits the menu system.

2. and Move to another menu item or decrease the selected

parameter. Hotkey for contrast adjustment.

3. and Move to another menu item or increase the selected

parameter. Hotkey for brightness adjustment.

4. Enter Open a sub-menu or selects a menu item.

5. Power Switch Turn the monitor on or off.

Selecting Functions and Making Adjustments

Contrast Hotkey

1. Press to open the contrast adjustment display.

2. Press

or to adjust the contrast level.

3. Press the Exit button to save your changes.

Brightness Hotkey

1. Press to open the brightness adjustment display.

2. Press

or to adjust the contrast level.

1. Press the Exit button to save your changes.

The Main Menu

The Diamond View 1995SL’s OSD has a in Main Menu organised into 6

groups of functions: Luminance, Geometry, Colour Adjustment, Recall,

Degaussing and Miscellaneous. The remainder of this chapter describes the

use of each function and the way that you can make adjustments to the

image displayed on the monitor’s screen.
