Digital Watchdog DWC-V8553TIR Bedienungsanleitung

Universal HD over Coax®

5MP Vandal Dome Camera

DWC-V8553TIR/ DWC-V8563TIR

User’s Manual Ver. 11/18

Before installing and using the camera, please read this manual carefully.

Be sure to keep it handy for future reference.

DWC-V8553TIR, DWC-V8563TIR

Table of Contents

1 FEATURES............................................................3

2 DIMENSIONS........................................................4

2.1 DWC-V8553TIR.............................................4

2.2 DWC-V8553TIR.............................................5

3 PRODUCT ACCESSORIES.....................................6

4 INSTALLATION......................................................7

5 CHANGING THE CAMERA’S SIGNAL.....................8

6 CONNECTING TO DVR/ENCODER.........................9

7 ADJUSTING THE CAMERA ANGLES ....................10

8 OSD MENU TREE................................................11

8.1 LENS ..........................................................11

8.2 EXPOSURE.................................................11

8.3 WHITE BALANCE ........................................12

8.4 DAY&NIGHT................................................12

8.5 ADJUST......................................................13

8.6 AUTO-FOCUS .............................................14

9 TROUBLESHOOTING..........................................15

10 SPECIFICATIONS................................................16

10.1 DWC-V8553TIR...........................................16

10.2 DWC-V8563TIR...........................................17

11 LIMITS & EXCLUSIONS........................................18

12 WARRANTY INFORMATION.................................19

Universal HD over Coax®5MP Camera

1 FEATURES

§ Universal HD over Coax®Technology supports HD-Analog, HD-TVI, HD-CVI

and all analog to 960H signals

§ 5MP 1/2.7" image sensor at 20fps / 4MP at real-time 30fps

§ 2.8mm fixed lens (DWC-V8553TIR model)

§ 2.8~12mm varifocal lens with motorized zoom and focus (DWC-V8563TIR

model)

§ Digital Wide Dynamic Range (D-WDR)

§ OSD control via Coaxial (UTC)

§ 100' range IR

§ 3D digital noise reduction

§ True day/night with mechanical IR cut filter

§ Auto gain control (AGC)

§ Backlight compensation (BLC)

§ Auto white balance (AWB)

§ IP66 certified weather and tamper resistant

§ IK-10 impact resistant

§ 5 year warranty

DWC-V8553TIR, DWC-V8563TIR

2 DIMENSIONS

2.1 DWC-V8553TIR

Universal HD over Coax®5MP Camera

2.2 DWC-V8553TIR

DWC-V8553TIR, DWC-V8563TIR

3 PRODUCT ACCESSORIES

Please check if all of the camera parts and accessories are included in the package

before proceeding.

Universal HD over Coax®5MP Camera

4 INSTALLATION

1. The mounting surface must withstand three times the weight of your camera.

2. Do not let the cables get caught in improper places for the electric line cover

can be damaged. This may cause a short or fire.

3. For the installation process, remove the camera’s dome cover by loosening the

screws at the base of the dome.

4. Using the mounting template, sheet or the camera itself, mark and drill the

necessary holes in the wall or ceiling.

5. Do not remove the protective film until the installation I completed.

6. Pass wires through the mounting bracket and make all necessary connections.

Connect the BNC and power cables to the camera. Connect the camera to a

DVR or encoder.

7. The cameras support three analog signals: HD-Analog, HD-TVI and HD-CVI.

See section 5 for more information on how to change the signal.

8. Secure the camera to the mounting surface with

the provided screws.

9. Adjust the camera to obtain an optimum angle by

using the camera’s three axis gimbal. See section

7 for more information.

10. If your camera supports a varifocal lens (DWC-

V8563TIR models), adjust the zoom and focus as

needed (see section 7).

11. Attach the camera’s dome cover back to the

camera base, and remove the protection file softly

to finish the installation.

DWC-V8553TIR, DWC-V8563TIR

5 CHANGING THE CAMERA’S SIGNAL

The camera supports three analog signals: HD-Analog, HD-TVI, HD-CVI and analog signal

up to 960H.

In order to switch the camera’s signal between the available options, locate the button

switch on the signal cable. The video outputs will recycle by holding and pressing the

button in the video switch cable for 5 seconds.

NOTE: The camera’s factory default resolution is 4MP at 30fps. However, the camera

can display video up to 5MP resolution at 20fps. In order to change the camera’s

resolution, go to the camera’s OSD menu > ADJUST > OUTPUT MODE.

Universal HD over Coax®5MP Camera

6 CONNECTING TO DVR/ENCODER

Use the diagram below to connect to a Universal DVR or CRT Monitor properly.

Use the diagram below to connect the camera to a proper power supply.

Power requirements: DC12V

Power consumption: IR LEDs on: < 4W

IR LEDs off: < 1W

CAUTION! The camera supports DC power supply only

DWC-V8553TIR, DWC-V8563TIR

7 ADJUSTING THE CAMERA ANGLES

Adjust the camera to obtain an optimum angle by using the camera’s bracket. The

camera’s max angles are:

§ Pan: 0°~ 355°

§ Tilt: 0°~ 67°

§ Rotation: 0°~ 355°

If your camera supports a varifocal lens (DWC-V8563TIR models only), you can adjust the

camera’s zoom and focus from the camera’s OSD menu via UTC. See section 8.6

Auto Focus for more information.
