USER’S MANUAL

iV3377WD / iV3377WTIR 1 / 60

iV3377WD, iV3377WTIR

Vandal Proof IP Dom e Camera

USER’S MANUAL

Network Camera

User’s Guide

iV3377WD /

iV3377WTIR

20101209

Before installing and using the camera, please read this

manual carefully.

Be sure to keep it handy for future reference.

USER’S MANUAL

iV3377WD / iV3377WTIR 2 / 60

 1/3‖ Sony Super HAD II CCD

 560 TV Line

 OMNI-Focus 2.9~8.5mm, 3X Motorized Zoom, Auto Iris

 Easy Icon Driven OSD Menu with Built-in Joystick

 Power over Ethernet [PoE] IEEE802.3af

 70ft Range IR with Intelligent Camera Sync iV3377WTIR Only

 3D-DNR (3D Digital Noise Reduction)

 EWDR (Electronic Wide Dynamic Range)

 Star-Light (Super Low Light Technology)

 Electronic Day and Night iV3377WD Only

 TDN (True Day and Night / IR Cut Filter) iV3377WTIR Only

 HME (Highlight Masking Exposure)

 Produces Negative Image

 Secondary Video-BNC Output for Easy Installation

 Auto Sensing 12VDC / 24VAC with Line Lock

 Zoom and OSD Control by IR Remote Controller

 3X Digital Zoom

 AGC (Auto Gain Control)

 BLC (Back Light Compensation)

 AWB (Auto White Balance)

 Mirror Image Control

 Programmable Privacy Zone (6) & Motion Detection

 Sharpness Control

FEATURES

USER’S MANUAL

iV3377WD / iV3377WTIR 3 / 60

 H.264 Video Compression Based Linux Embedded

 Up to 30fps (D1, 4CIF, VGA, CIF, QVGA)

 Interactive 2-Way Audio Communication

 Variable Bandwidth Control

 Web-Server Built-in / Free DDNS / No Additional Software Required

 SW Functions Remotely Upgradable

 Auto IP and UPnP Support

 Static and Dynamic IP (ADSL, DHCP, and DDNS) Support

 Event Notification by Email on Sensor and Motion Detection Trigger

 Multiple Levels of Password Protection

 PDA: WinCE & WinCE.NET Mobile Manager

 Integrated to DW-Hybrid DVR, NV5200, DW 9000VMS, DW-NEXUS

FEATURES OF NETWORK

USER’S MANUAL

iV3377WD / iV3377WTIR 4 / 60

 Do not open or modify.

Do not open the case except during maintenance and installation, as it may be dangerous and

cause damages.

 Do not put objects inside the unit.

Make sure that no metal objects or flammable substances get inside the camera. It could cause

fire, short-circuits or damages.

 Be careful when handling the unit.

To prevent damage, do not drop the camera or subject it to strong shock or vibration.

 Install away from electric or magnetic fields.

 Protect from humidity and dust.

 Protect from high temperature.

Be careful when installing close to the ceiling or in a kitchen or boiler room, as the temperature

may rise to high levels.

 Cleaning

Dirt can be removed from the case only by wiping it with a soft cloth moistened with a soft

detergent solution.

 Mounting Surface

The mounting surface material must be strong enough to support the camera.

PRECAUTIONS

USER’S MANUAL

iV3377WD / iV3377WTIR 5 / 60

Before sending the camera out for repair, check the items below.

If the problem persists after checking these items, contact your service center.

▲If no image appears

 Is the LAN cable attached securely?

 Are the power and voltage normal?

 Has the iris of the lens inside the camera been adjusted correctly with the level volume?

 Is there adequate illumination?

▲If the image is unclear

 Is the lens in focus?

 Is the lens dirty?

 Dirt or fingerprints on the lens can adversely affect the images.

Gently wipe any dirt or fingerprints off the lens with a soft cloth or lens cleaning paper and

cleaning fluid (commercially available).

 Is the monitor adjusted correctly?

TROUBLESHOOTING

WARNING:

TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

USER’S MANUAL

iV3377WD / iV3377WTIR 6 / 60

DIMENSION (mm)

USER’S MANUAL

iV3377WD / iV3377WTIR 7 / 60

INSTALLATION

1. Use the supplied L-wrench to remove the four

fixing screws (B) of dome cover (A).

2. Align the camera unit with the surface of the

ceiling; make marks on the ceiling in the places

where the screw holes are to be drilled; and

then drill the four holes.

3. Cut a hole (diameter 2.9in/0.73mm) in the

ceiling for routing the cables.

4. Pass the power cable (E) and LEN cable (F)

from the camera unit through the cable hole in

the ceiling.

5. Align the four screw holes in the camera unit

(D) with the screw holes in the ceiling, and then

secure the camera in place by tightening the

four or more screws (C) through the washers.

6. Carry out the settings and adjustments for the

camera.

7. Secure the dome cover (A) by tightening the

screws (B).

USER’S MANUAL

iV3377WD / iV3377WTIR 8 / 60

▲CONNECTION (Ⅰ)

▲CONNECTION (Ⅱ)

CONNECTION

DC12V / AC24V

LAN (RJ45)

Second VIDEO

CAUTION:

Check for polarity when using a DC voltage.

LAN (PoE)

Second VIDEO

CAUTION:

Check for polarity when using a POE (Power of Ethernet) power supply.

Power Requirement:

12VDC @ 2A

24VAC @ 1A

PoE Switch (IEEE802.3af)

USER’S MANUAL

iV3377WD / iV3377WTIR 9 / 60

▲ETHERNET CONNECTION

Connect Ethernet Cable to the network.

USER’S MANUAL

iV3377WD / iV3377WTIR 10 / 60

▲LENS ADJUSTMENT & GIMBAL ADJUSTMENT

1. Adjust the panning (360˚) and tilt (90˚) position. (DV LENS TYPE)

Adjust the panning (360˚) and tilt (70˚) position. (DV LENS & IR LED TYPE)

2. Set the zoom lever as desired position by moving Zoom lever.

3. Set the Focus lever as the image is focused by moving Focus lever.

CAMERA SETTING
