Dimplex DCTF94A Bedienungsanleitung

For domestic household use only.

INSTRUCTION MANUAL

94cm & 119cm Tower Fan

Model: DCTF94A & DCTF119A

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY

AND RETAINED FOR FUTURE REFERENCE.

Note also the information presented on the appliance

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY

CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE

YOUR WARRANTY

Please read the operating instructions carefully before using your

fan for the first time and keep them in a safe place.

WARNING – This appliance must not be used in a bathroom.

WARNING – Do not use this appliance in the immediate

surroundings of a bath, a shower or a swimming pool.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance

by a person responsible for their safety.

• Children should be supervised to ensure they do not play with

the appliance.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in

order to avoid a hazard.

• Never immerse the appliance in water or other liquids.

• Operate this unit only on a firm, flat surface.

• Do not place on soft, unstable or non-horizontal/angled

surfaces.

• Never operate the appliance if a cable or connector has been

damaged, after appliance malfunction or if the appliance was

dropped or is otherwise damaged.

• If the mains lead is damaged it must only be replaced by the

manufacturers service agent or a similarly qualified person in

order to avoid a hazard.

• Please ask a professional service agent to repair the product.

Improper repair may cause danger to users.

• Disconnect the appliance from mains power whenever it is not

in use, before relocating it, and before cleaning.

• Operate the appliance only at the voltage specified on the

rating label.

• Only connect the unit to a properly installed and easily accessible

socket so that you can quickly disconnect the plug if necessary.

• Do not connect this product to the mains using an extension

lead.

• ThisfanisonlyintendedforINDOOR RESIDENTIALapplications.

This fan should not be used for commercial or industrial or

leisure applications or in small enclosed spaces.

• Never use the mains lead as a carrying strap or pulling lead.

• To avoid a fire or electrocution hazard, NEVER put the cord

near heat registers, radiator, stoves or heaters.

• DO NOT cover cord with carpeting, throw rugs, runners, or

similar coverings.

• DO NOT route cord under furniture or appliances. Take care to

position the cord away from traffic areas and where it will not

be a tripping hazard.

• DO NOT use the unit near windows or where water collects.

Rain and water collection may lead to a risk of fire or electric

shock.

• Only operate this appliance with a minimum of 50cm clearance

all around i.e. away from walls, furniture and overhanging

objects such as curtains or a shelf.

• To prevent spillage, empty the water tank before lifting or

relocating the appliance.

• WARNING: To avoid danger of suffocation please remove all

packaging materials particularly plastic and EPS and keep

these away from vulnerable people, children and babies.

• NEVER drop or insert any object or fingers into any openings.

• Do not use the appliance in locations where paint, petrol or

other flammable liquids are used or stored.

• Do not use bug sprays or other flammable cleansers/vapour

sprays on or around the unit.

• Always switch off the unit and take the plug out of the socket:

•

If you are not using the unit

•

Before you clean or carry out maintenance on the unit

•

If a fault occurs

•

In the event of an electrical storm.

• Avoid electromagnetic interference. Keep the unit at least 1

metre away from electrical appliances such as televisions &

radios.

• DO NOT use this appliance with an extension lead or power

board.

WARNING - KEEP BATTERIES OUT OF REACH OF CHILDREN

• Swallowing may lead to serious injury in as little as 2 hours or

death, due to chemical burns and potential perforation of the

oesophagus.

• If you suspect your child has swallowed or inserted a button

battery immediately call the 24-hour Poisons Information Centre

on 13 11 26 (in Australia) or 0800 764 766 (in New Zealand) for

fast, expert advice.

• Examine devices and make sure the battery compartment

is correctly secured, e.g. that the screw or other mechanical

fastener is tightened. Do not use if the compartment is not

secure.

• Dispose of used button batteries immediately and safely. Flat

batteries can still be dangerous.

Exposed to the

weather outdoors

Near water If the power cable

wires are frayed or cut

Where small children

may be left unattended

No extension

leads or power

boards

Where there is risk

of fire or close to

a naked flame

Where the power

cable may be

damaged

On a slope or

uneven surface

Where it may be

damaged by

chemicals

If there is a risk

of water falling on

the unit

Where there is a risk

of interference by

foreign objects

This product is not

made for DIY repair

Model no. DCTF94A DCTF119A

Colour

White

Power supply

220-240V~, 50Hz

Rated power

50W

Speed settings

Modes 3

Timer 0-8hrs

Air speed 6.17m/s 6.40m/s

Oscillating 90°

Controls Touch Panel or Remote

Noise level

48.70db(A) 51.20db(A)

Weight (net) 3.57kg 4.54kg

Dimensions (w x d x h) 315 x 315 x 932mm 315 x 315 x 1167mm

Specification

• For greater precision, please always refer to the rating label placed on the product.

Assembly

1. Loosen and remove the plastic fixing

nut from the main unit.

2. Slot the two base plates together.

3. Gently thread the power cable from

the main unit through the hole in the

middle of the base.

4. Gently slot the main unit through the

center of the base and secure with the

plastic fixing nut.

5. Tidy the power cable into the slots.

Operation

Control Panel

Place the fan on a stable and flat surface. Plug the cord set into a 220-240V A.C.

electrical outlet.

Turn the fan on by pressing the 'POWER' button. Turn the fan off by pressing the

'POWER' button again.

You can adjust the fan speed to the desired level between 1-3 by pressing the 'SPEED'

button. The speed setting is displayed on the LED panel.

4. You can adjust the fan mode by pressing the 'MODE' button. The three modes are

'natural', 'normal' and 'sleep.'

5. To set the fans timer, press the 'TIMER' button. This allows you to set the fans length

of operation between 1-8 hours.

6. To make the fan oscillate, press the 'OSC' button. This allows the fan to oscillate up

to 90°.

This tower fan can be operated by the control panel or remote control. Please refer to

the below diagrams and descriptions.

Remote Control

1. Install x1 CR2025 button cell battery into the remote.

2. All remote control buttons are labled as below and function work identically to the

manual controls.

POWER

SPEED

TIMER MODE

OSC

Cleaning

Over time, dust can accumulate on the fan grille, which can affect the fans

performance. It is recommended to clean the fan at least once a month.

1. Turn the unit OFF and disconnect the appliance from the power supply.

2. Remove any dust build up with a soft brush.

3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can be used

for any stubborn marks.

Do not use abrasive sponges, scouring pads, or a stiff brush to clean the unit.

IMPORTANT

The control panel and other parts must not come into contact with water or any

other liquids.

Storage

If not using the unit for an extended period of time. After cleaning please:

• Turn the unit off, unplug and take care of the mains lead & plug.

•

Cover the unit and store it upright in a location where it will not receive direct

sunlight. NB- Prolonged exposure to direct sunlight will discolour the enclosure.

If the unit fails to operate efficiently, is broken or other problems arise, unplug and

do not operate. Ask for advice by calling your local after sales service agent or the

Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).

Maintenance

Recycling: Do not dispose of electrical appliances as unsorted

municipal waste. Use separate collection facilities. Contact your

local government for information regarding the collection systems

available. If electrical appliances are disposed of in landfills or dumps,

hazardous substances can leak into the ground water, polluting the

food chain and damaging health and well-being.

Warranty

Please refer to the warranty card in the box for warranty information. For any

troubleshooting advice, please contact the relative Customer Care Centre below.

Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd

8 Lakeview Drive, 38 Harris Road, East Tamaki,

Scoresby 3179, Victoria Auckland 2013

Australia New Zealand

Ph: 1300 556 816 Ph: 0800 666 2824
