DIVERSITECH ClearVue Benutzerhandbuch

PUMP™

ClearVue Pump

System Installation

Contents

Introduction

3 Variable Speed and Li

5 Floatless Sensor™

7 Other Features

System Installation

9 Unpacking, Pump Location and Mounting

10 Electrical and High Level Alarm Connection

11 Inlet and Outlet Tubing Connections

12 Electrical Installation Requirements and Safety Switch Connections

Operation

12 Power, Pump Test, and Normal Operation

13 Variable Li, Cleaning, and Homeowner Instruction

Reference and Troubleshooting

14 Button Reference Chart

15 LED Indicator Reference Chart

Technical Information

16 Troubleshooting Guide

18 General Data and Safety Information

PUMP

™

Introducing…..ClearVue

Thank you for the purchase of the ClearVue™ condensate pump.

ClearVue™ automatically removes condensate water just like a standard

condensate pump but with many customer inspired improvements.

Variable Speed and Li - See page 3 and 4.

Floatless Sensor™ - See page 5.

With DiversiTech’s Floatless Sensor™ technology, ClearVue™ eliminates

the oat switch - one of the most common problems with conventional

condensate pumps.

ClearVue™

uses patent pending water

sensing technology to detect condensate so that there are no more

stuck oats!

ClearVue™

also features a see-through tank to give the

service tech and homeowner a clear view of water, blockage, and

buildup in the tank. This clear tank allows for quick troubleshooting due

to normal buildup caused by daily condensate generation.

™

Variable Speed and Li

ClearVue pump’s ﬂoatless sensor technology senses how fast water is ﬁlling the tank

and determines how hard the ClearVue needs to pump in a given installation, then

pumps only to that height. If there is a partial clog in the drain line, ClearVue ﬁgures

that out, and pumps a little harder. If the clog doesn’t clear, ClearVue goes into a

cleaning cycle and pulses the discharge water to try to dislodge the clog.

The variable lift in ClearVue assures that the pump impeller is spinning only as fast as

is needed to lift the condensate water to the height needed. A slower spinning impeller

means signiﬁcantly less noise than conventional condensate pumps. Variable speed is a

proven, quieting feature in furnace blower motors. This electronically controlled

technology is now available in a condensate pump - ClearVue by DiversiTech.

™

CHECK FOR

SHIPMENT

DAMAGE
