DK METER
COMPACT AUDIO LOUDNESS METER
Quick Start Guide
www.dk-technologies.com
DENMARK (HEAD OFFICE)
DK-Technologies A/S,
Marielundvej 37D,
DK-2730 Herlev.
Tel: +45 44 85 02 55
Fax: +45 44 85 02 50
Email: info@dk-technologies.com
GERMANY
DK-Technologies Germany GmbH,
Tibarg 32c,
D-22459 Hamburg.
Tel: +49 (0) 40 70 10 37 07
Fax: +49 (0) 40 70 10 37 05
Email: cr@dk-technologies.com
UK
DK-Technologies (UK) Ltd,
ColesYard Barn, North Lane, Claneld,
Hampshire PO8 0RN, England.
Tel: +44 (0) 23 92 59 61 00
Fax: +44 (0) 23 92 59 61 20
Email: info.uk@dk-technologies.com
USA
DK-Technologies America,
2100 B2 Walsh Ave,
Santa Clara, CA 95050-2590, USA.
Tel: 0800 421 0888
Fax: +45 44 85 02 50
Email: info@dk-technologies.com
Worldwide Offices
Made in Denmark
interstage
Phistersvej 31, 2900 Hellerup, Danmark
Telefon 3946 0000, fax 3946 0040
www.interstage.dk
-pro audio with a smile
•1 x DK Meter
•1 x Interface Cable including USB Power
•1 x Universal USB Power Supply
including US, Euro & UK compatibility
•1 x Meter Mount
•1 x Panel Mount Template
•1 x Quick Start Guide
When the contents have been checked please
proceed as set out below:
1. Connect the interface cable to the multi-pin
connector in the back of the meter.
2. Fit the mounting system if required (make sure
the meter is the right way up, control buttons to
the bottom).
3. Connect the AES3 BNC connector to the audio
source.
4. Fit the correct power adaptor to the USB power
supply.
5. Connect the USB connector to the USB power
supply.
6. Connect the USB power supply adaptor into a
mains outlet and turn on.
7. The meter display will immediately illuminate
and the menu keys become visible.
8. The full user guide is available at
www.dk-technologies.com/dkmeter
Quick Start Guide...In the box...
BNC
Connector
USB
Connector
Multi-Pin
Connector
Desktop Mount Meter Assembly
•1 x DK Meter
•1 x Interface Cable including USB Power
•1 x Universal USB Power Supply
including US, Euro & UK compatibility
•1 x Meter Mount
•1 x Panel Mount Template
•1 x Quick Start Guide
When the contents have been checked please
proceed as set out below:
1. Connect the interface cable to the multi-pin
connector in the back of the meter.
2. Fit the mounting system if required (make sure
the meter is the right way up, control buttons to
the bottom).
3. Connect the AES3 BNC connector to the audio
source.
4. Fit the correct power adaptor to the USB power
supply.
5. Connect the USB connector to the USB power
supply.
6. Connect the USB power supply adaptor into a
mains outlet and turn on.
7. The meter display will immediately illuminate
and the menu keys become visible.
8. The full user guide is available at
www.dk-technologies.com/dkmeter
Quick Start Guide...In the box...
BNC
Connector
USB
Connector
Multi-Pin
Connector
Desktop Mount Meter Assembly
