INSTALLATION GUIDE

Model 400 USB Flash Module

Description

The Model 400 USB Flash Module allows you to easily eld update

rmware for panels that would otherwise require the use of a computer

and a Model 399 Programming Harness.

The Model 400 is equipped with a standard USB 2.0 compatible Type

A female connector for interface to a USB Drive, a 4-pin connector

between the Model 400 and the compatible panel, and an LED to

indicate panel update status.

Compatibility

Compatible with XT30/XT50 Series panels, XTLC, XTLplus, and the

CellCom-LTE-V.

Caution: Do not connect a Model 400 to the CellComF-LTE-V if using 24 volt power.

Downloading the RU le to the USB Drive

To download a new rmware version RU le to the ash drive:

1. Connect a USB ash drive to your computer with a USB 2.0 compatible Type A female port.

2. Locate and download the panel’s rmware update RU le from DMP.com/Dealer_Direct and save it to the Root

directory of the ash drive.

3. When complete, disconnect the ash drive from your computer.

Note: The Model 400 only supports ash drives using a FAT32 le system. If multiple RU les are saved to the ash

drive, the le with the most recent Date Modied will be used by the Model 400.

Updating the Firmware

The Model 400 connects to the compatible panel via the panel’s programming PROG header. Updating rmware does

not change current panel programming. To update the panel with a new rmware version:

XT30/XT50

1. Remove the yellow and green wires from keypad bus terminals 8

and 9.

2. Connect the USB ash drive containing the RU le to the Model

400 and connect the assembly to the panel’s Programming PROG

header. The LED on the Model 400 will ash and then display

steady green.

3. Place a jumper across the Reset header.

4. Place a jumper across the Load header.

5. Remove the jumper from the Reset header.

6. Press and release the load button on the Model 400 to initiate

the rmware update. The LED on the Model 400 will ash slowly.

If the LED displays fast ashes it means the rmware update was

unsuccessful. The update will take approximately 4.5 minutes

and when complete the LED on the Model 400 will display steady

green.

7. Replace the jumper across the Reset header then remove the USB

ash drive and Model 400 assembly.

8. Remove the jumper from the Load header.

9. Remove the jumper from the Reset header.

10. Reconnect the yellow and green wires to terminals 8 and 9.

In the event the Model 400 USB Flash Module is inadvertently removed from the panel before

the update nishes, repeat steps 1 through 10.

Bottom

Top

4-Pin Connector USB Connector

Load Button

View LED

Figure 1: Model 400 USB Flash Module

Figure 2: Model 400 USB Flash Module and

Flash Drive to XT30/50

Phone

Line J1

Ethernet

J16

Reset

J7 RJ

Supervision

J24

Celllular

header

connection

J18

Load

RED

PROG

USB Flash Drive

4-Pin Connector

Model 400 USB Flash Module

Load Button on Underside

LED

800-641-4282

INTRUSION • FIRE • ACCESS • NETWORKS

www.dmp.com 2500 North Partnership Boulevard

Designed, Engineered and

Assembled in U.S.A. Springeld, Missouri 65803-8877

18252

Specications

Dimensions 3-3/8” L x 7/8” W x 1/2” H

Certications

FCC Part 15

CellCom-LTE-V, XTLplus, XTLC

1. Connect the USB ash drive containing the RU le to the Model

400 and connect the assembly to the panels Programming PROG

header. The LED on the Model 400 will ash then display steady

green.

2. Press and hold the Load switch on the panel. While holding the

Load switch, press and release the Reset switch, then release the

Load switch.

3. Press and release the load button on the Model 400 to initiate the

rmware update. The LED on the Model 400 will ash slowly. If

the LED displays fast ashes it means the rmware update was

unsuccessful. The update will take approximately 4.5 minutes

and when complete the LED on the Model 400 will display steady

green.

4. Press and release the Reset switch then remove the USB ash

drive and Model 400 assembly.

In the event the Model 400 USB Flash Module is inadvertently removed

from the panel before the update nishes, repeat steps 1 through 4.

Verify the Firmware

1. At a keypad, enter the Diagnostic code 2313 (DIAG), and press CMD.

2. Press CMD until Panel Settings displays. Press any select key.

3. Press CMD until Firmware Version displays. Verify the panel rmware version is correct.

4. Press CMD until Stop displays. Press any select key to exit the Diagnostic menu.

Figure 3: Model 400 USB Flash Module and

Flash Drive to XTLC

USB Flash Drive

4-Pin Connector

Model 400 USB Flash Module

Load Button on Underside

LED

RESET

LOAD

BAT

PROG

RED

PWR

TX RF RX
