Dometic Mini Heki Style Bedienungsanleitung

400 mm

1 – 2 mm

12 mm

Ø 24 mm

1 – 2 mm

≤1,5 Nm

Mini Heki Style

mm 25 – 26 27 – 28 29 – 30 31 – 32 33 – 34 35 – 36 37 – 38 39 – 40 41 – 42

mm 0246810 12 14 16

mm 25 32

mm 43 – 44 45 – 46 47 – 48 49 – 50 51 – 52 53 – 54 55 – 56 57 – 58 59 – 60

mm 18 20 22 24 26 28 30 32 34

mm 40 52

Mini-Heki-Style--IO-16s.book Seite 1 Montag, 23. Januar 2017 5:21 17

III

110 mm

160 mm 160 mm

160 mm

160 mm 160 mm

160 mm

4445101881 L 08/2019 MO1133I02

Mini-Heki-Style--IO-16s.book Seite 2 Montag, 23. Januar 2017 5:21 17

YOUR LOCAL DEALER

dometic.com/dealer

A complete list of Dometic companies, which comprise the Dometic Group, can be found in the public filings of:

DOMETIC GROUP AB Hemvärnsgatan 15 SE-17154 Solna Sweden

YOUR LOCAL SUPPORT

dometic.com/contact

YOUR LOCAL SALES OFFICE

dometic.com/sales-offices

Mini Heki Style

Roof light

Installation and Operating Manual. . . . . . . . 3

Dachfenster

Montage- und Bedienungsanleitung . . . . . 11

Dôme de toit

Instructions de montage

et de service . . . . . . . . . . . . . . . . . . . . . . . . . 19

Claraboya

Instrucciones de montaje y de uso . . . . . . .27

Clarabóia

Instruções de montagem e manual de

instruções . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Oblò

Istruzioni di montaggio e d’uso . . . . . . . . .43

Dakraam

Montagehandleiding en

gebruiksaanwijzing . . . . . . . . . . . . . . . . . . . 51

Tagvindue

Monterings- og betjeningsvejledning. . . . 59

Takfönster

Monterings- och bruksanvisning . . . . . . . . 67

Takvindu

Monterings- og bruksanvisning. . . . . . . . . 75

Kattoikkuna

Asennus- ja käyttöohje . . . . . . . . . . . . . . . . 83

Окно для крыши

Инструкция по монтажу и эксплуатации . 91

Okno dachowe

Instrukcja montażu i obsługi. . . . . . . . . . . . 99

Strešné okno

Návod na montáž a uvedenie

do prevádzky. . . . . . . . . . . . . . . . . . . . . . . 107

Střešní okno

Návod k montáži a obsluze . . . . . . . . . . . 115

Tető abla k

Szerelési és használati útmutató . . . . . . . 123

WINDOWS & DOORS

WINDOWS

Mini-Heki-Style--IO-16s.book Seite 1 Montag, 23. Januar 2017 5:02 17

Mini-Heki-Style--IO-16s.book Seite 2 Montag, 23. Januar 2017 5:02 17

Mini Heki Style Explanation of symbols

Please read this instruction manual carefully before installation and first

use, and store it in a safe place. If you pass on the product to another

person, hand over this instruction manual along with it.

Table of contents

1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

2 Safety and installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

4 Optional extras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

6 Instructions before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

7 Installing Mini Heki Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

8 Using the Mini Heki Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

10 Maintaining and cleaning Mini Heki Style . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

11 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

12 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

1 Explanation of symbols

WARNING!

Safety instruction: Failure to observe this instruction can cause fatal or

serious injury.

NOTICE!

Failure to observe this instruction can cause material damage and impair

the function of the product.

NOTE

Supplementary information for operating the product.

Mini-Heki-Style--IO-16s.book Seite 3 Montag, 23. Januar 2017 5:02 17

Safety and installation instructions Mini Heki Style

2 Safety and installation instructions

Pleaseobserve theprescribed safetyinstructions and stipulations from the

vehicle manufacturer and service workshops.

The manufacturer accepts no liability for damage in the following cases:

•Damage to the product resulting from mechanical influences

•Alterations to the product without express permission from the manufacturer

•Use for purposes other than those described in the operating manual

Please note the following:

•If faults or disturbances occur, consult a specialist workshop immediately.

•Risk of breakage! Do not tread on the glass dome.

•Before starting your journey, check that the roof window is locked properly.

•Before starting your journey, check the roof window for damage (such as tension

cracks in the acrylic glass).

•Do not open the roof window while driving.

•Do not open the window in strong wind or rain.

•Close the roof window if it rains or snows.

•Do not leave the vehicle with the roof window open.

•Keep the roof window free of snow and ice.

WARNING! Beware of injury

Do not exceed the maximum allowable driving speed of 160 km/h,

because this can damage the roof light. Parts that come loose may injure

people in the vicinity.

NOTE

If you do not have sufficient technical knowledge for installing the

components in vehicles, you should have a specialist install the roof

window in your vehicle.

Mini-Heki-Style--IO-16s.book Seite 4 Montag, 23. Januar 2017 5:02 17

Mini Heki Style Scope of delivery

3Scopeofdelivery

4Optionalextras

5 Intended use

The Mini Heki Style roof light is suitable for installing in motorhomes or caravans:

•Roof thicknesses 25 – 42 mm, without forced ventilation: ref. no. 9104116242

•Roof thicknesses 25 – 42 mm, with forced ventilation: ref. no. 9104116244

•Roof thicknesses 43 – 60 mm, without forced ventilation: ref. no. 9104116243

•Roof thicknesses 43 – 60 mm, with forced ventilation: ref. no. 9104116245

The maximum permissible speed is 160 km/h, as noise or damage could occur

depending on the vehicle design or installation position. In case of excessive noise,

a spoiler (accessory) can be used.

No. in

fig. 1Quantity Designation

1 1 Outer frame with glass dome

2 1 Mounting frame

3 1 Inner frame

412

Long fastening screws

Short fastening screws

5 12 Fastening clip

Designation Ref. no.

Spoiler 9104100260

Mini-Heki-Style--IO-16s.book Seite 5 Montag, 23. Januar 2017 5:02 17

Instructions before installation Mini Heki Style

6 Instructions before installation

➤Before installation, check the roof thickness of your vehicle. Consult the vehicle

manufacturer if you have any questions.

➤When choosing the installation location, observe the following:

– Adjoining components (roof rack or attachment and reinforcing parts), cables

and cabinets in the vehicle interior must not be damaged when sawing the

hole.

– Sufficient space needs to be available for installing the inner and outer frames.

– Only fit the roof light on flat and parallel interior and exterior roof areas with a

maximum inclination of 15° to the horizontal.

– You may use an existing roof hole provided the roof light fits into it.

6.1 Pressing out the hole

See fig. 2

6.2 Using the reinforcing rails

Supplementary to fig. 3

➤Before installation, check whether the roof hole needs reinforcing.

➤Remove the foam according to the width of your reinforcing rail (not in scope of

delivery) (A).

➤Fit the reinforcing rails (B).

Mini-Heki-Style--IO-16s.book Seite 6 Montag, 23. Januar 2017 5:02 17

Mini Heki Style Installing Mini Heki Style

7 Installing Mini Heki Style

Supplementary to fig. 4

The scope of delivery contains a mounting frame, which is suitable for roof

thicknesses of 25 – 42 mm or 43 – 60 mm.

➤Measure your roof thickness W.

➤Shorten the sleeves to size H (see table).

➤Use the screws with appropriate lengths (see table).

Siehe fig. 5

➤Check that the roof light has sufficient space around (approx. 1 to 2 mm) it in the

roof opening.

See fig. 6

➤Clean the roof opening in the mounting area.

See fig. 7

➤Seal the mounting frame with a flexible non-hardening sealing compound (e.g.

SikaLastomer-710).

See fig. 8

➤Observe the direction of travel when installing.

➤Place the outer frame in the middle of the roof opening.

➤Press the outer frame in the roof slightly so that the packing compound spreads

out.

See fig. 9

➤Install the mounting frame.

➤Tighten the screws 10 minutes after installation.

See fig. 0

➤Install the fastening clips on the inner frame at the specified distances.

See fig. a

➤Fit the inner frame into the mounting frame.

NOTICE!

Observe the instructions of the sealant manufacturer.

Mini-Heki-Style--IO-16s.book Seite 7 Montag, 23. Januar 2017 5:02 17

Using the Mini Heki Style Mini Heki Style

See fig. b

➤Push the inner frame onto the mounting frame.

➤After installing, check the roof light works properly.

➤Remove the protective film from the acrylic glass.

➤If necessary, enter the new vehicle height and weight in the vehicle documents.

8 Using the Mini Heki Style

8.1 Opening and closing the Mini Heki Style (fig. c)

➤Press the release button (1) and open the roof hood with the bracket at the same

time (2).

Opening the roof light completely

➤Slide the bracket (2) into the Iposition.

Opening the roof light to the half-way position

➤Slide the bracket (2) into the II position.

You can push down the sliders (3) on the left and right to lock it.

Opening the roof light to the ventilation position

➤Slide the bracket (2) into the III position.

Closing the roof light

➤Slide the bracket (2) into the IV position.

➤Guide the bracket (2) with slight pressure to the left and right via the catches (4),

so that the roof hood is locked and the bracket (2) is on the release button (1).

NOTE

If the protective film is exposed to sunlight for too long, it cannot be

taken off without leaving a residue.
