DoorKing 1601-235 Bedienungsanleitung

Test hub UP and DOWN position

before installing bracket.

Arm and Reverse Edge Note:

Arm (sold separately) has already been assembled when

using 2-piece arm. See page 5 for more information.

Reverse edge with/without LEDs (sold separately) has already

been installed on arm. See page 6 for more information.

Install Bracket

OCTAGON ARM REVERSE/LED EDGE INSTALLATION

Installation

DoorKing Part Number

1601-235

Octagon Arm Hardware Kit

DoorKing Part Number

1601-242

Arm Hardware Kit

This kit is designed for a 1601 barrier gate operator WITHOUT convenience open OR 1603 auto-spikes barrier operator.It CANNOT

be used with a 1602 operator. The kit provides a reversing edge with OR /without Red/Green LEDs for a octagon arm. When the arm

is raised, LEDs turn GREEN, and turns RED when lowered and remains RED in the down position. Arm will reverse if lowering and a

obstruction is encountered.

Note: DO NOT operate arm with a malfunctioning reverse edge.

Allow arm to protrude

about 1” past the end

of arm bracket. Make

sure arm cover fits

over arm.

When installing a octagon

arm ONLY.

Arm Bracket

Hub

Arm

Reverse Edge

Drawings NOT to scale

Octagon Arm

120 S. Glasgow Avenue

Inglewood, California 90301 U.S.A.

Hub MUST already be installed on gate operator.

See 1601 Installation/Owner’s manual for correct hub installation.

1601-268-B-12-19

Run Wire Harness (1601-345)

Choose which side of the operator the arm is mounted on, remove knock-out and run wire harness accordingly as shown.

Wire

Guard

Knock-Out

Far Side

Option

Near Side

Option

Note for Older Operators:

A 5/8” hole will have to be

drilled in the operator

cabinet approximately

where Knock-Out is

shown. Make sure 5/8”

hole is clear of all internal

components.

Note for Older Covers:

See page 4.

Use bottom hole on arm bracket to secure wire guard.

Plug in reverse edge.

Arm Cover

Wire Harness Secured

to Top of Cabinet for

FAR side option

Included Adhesive

Zip Ties

IMPORTANT: Allow a loop in the

wire harness for rotating arm.

IMPORTANT: Allow a loop in the

wire harness for rotating arm.

Install Arm Cover

IMPORTANT: Wire harness MUST

remain clear of the rotating arm and

the arm cover to avoid wire chaffing.

DO NOT operate arm with a

malfunctioning reverse edge.

Use supplied adhesive

zip tie to secure harness

to bottom of bracket.

Wiring:

See page 3.

1601-268-B-12-19

REVERSE

SENSITIVITY

TIME

DELAY

POWER

2 3 4 5 6 7 81

2 3 4 5 6 7 8

NC NO

LOOP

DOWN

LOOP

12345678910 11 12 13 14

SW 1

SW 2

OFF

AC POWER

AUTO

DOWN

NONCC

Wiring

Power

Transformer

Terminal 14 -

Yellow Reverse Edge

Red+

Black-

(1601-345)

Transformer Plug

C - Common - WHITE Wire

NC - Close - ORANGE Wire (Red LED)

NO - Open - GREEN Wire (Green LED)

Keep wire

harness

clear of

all moving

parts.

MAKE SURE ALL POWER IS TURNED OFF TO OPERATOR!

Arm Relay

Contacts

Terminal 9 - Yellow Reverse Edge

1601 operators WITH

convenience open

CANNOT be USED.

1601-268-B-12-19

Older Arm Cover

Older arm cover will need to have the reverse edge

cut out of the existing cover. Only one side of the

cover will need to be cut out depending on which

side of the operator the arm is mounted on. Use

this template as a guide to remove material from

the cover.

1601-268-B-12-19

14 FT 2-PIECE OCTAGON ARM ASSEMBLY

Assemble Arm

DoorKing Part Number

1601-567

14 Ft 2-Piece Octagon Arm Kit

This kit is designed for use on a 1601 or 1603 barrier gate operators ONLY. It has 2-7 ft arm sections

that assemble into a 14 ft arm.

7 Ft Arm Section 7 Ft Arm Section

Coupler

Drawing NOT to scale

Slide one section of the arm on coupler to the center line and secure

with screws before inserting other arm section and securing.

Note: Holes are pre-drilled in the arm sections, but not in the coupler.

Pre-drilled Hole

CenterLine

Install End Cap

Push a screwdriver through the hole in cap to

release spring while pushing cap on. Keep pushing

cap on until a “CLICK” is heard, locking it in place.

120 S. Glasgow Avenue

Inglewood, California 90301 U.S.A.

Self-tapping screws

through pre-drilled

holes in arm sections.

1601-268-B-12-19

Remove End Cap

REVERSE EDGE / RED GREEN LED INSTALLATION

Installation

DoorKing Part Numbers

8080-080

Reverse Edge

8080-096

Reverse Edge + Red/Greed LED

This kit is designed to install on a 14 ft aluminum octagon arm for a 1601 barrier gate operator or

a 1603 auto spikes operator. It CANNOT be used with a 1602 operator.

Note: DO NOT operate arm with a malfunctioning reverse edge.

Push a screwdriver through hole

in bottom of end cap to release

spring while pulling cap off.

Push a screwdriver through the hole in cap to release

spring while pushing cap on. Keep pushing cap on

until a “CLICK” is heard which locks it in place.

120 S. Glasgow Avenue

Inglewood, California 90301 U.S.A.

Tip: Liquid soap will help

reverse edge slide on easier.

Reinstall End Cap

Slide on Edge

Octagon Arm

Reverse/LED Edge

1601-268-B-12-19
