Draytek Vigor2915 Series Bedienungsanleitung

Vigor2915 Series

Dual-WAN Security Router

Quick Start Guide

(For Wired Model)

Version:1.0

Firmware Version: V4.0.5

(For future update, please visit DrayTek web site)

Date: January 15, 2020

iii

Intellectual Property Rights (IPR) Information

by copyright. No part may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language without written permission

from the copyright holders.

Trademarks The following trademarks are used in this document:

Microsoft is a registered trademark of Microsoft Corp.

Windows, Windows 95, 98, Me, NT, 2000, XP, Vista, 7, 8 and

Explorer are trademarks of Microsoft Corp.

Apple and Mac OS are registered trademarks of Apple Inc.

Other products may be trademarks or registered trademarks of

their respective manufacturers.

Safety Instructions and Approval

Safety

Instructions

Read the installation guide thoroughly before you set up the router.

The router is a complicated electronic unit that may be repaired

only be authorized and qualified personnel. Do not try to open or

repair the router yourself.

Do not place the router in a damp or humid place, e.g. a bathroom.

Do not stack the routers.

The router should be used in a sheltered area, within a

temperature range of 0 to +40 Celsius.

Do not expose the router to direct sunlight or other heat sources.

The housing and electronic components may be damaged by direct

sunlight or heat sources.

Do not deploy the cable for LAN connection outdoor to prevent

electronic shock hazards.

Keep the package out of reach of children.

When you want to dispose of the router, please follow local

regulations on conservation of the environment.

Warranty

We warrant to the original end user (purchaser) that the router will be free

from any defects in workmanship or materials for a period of two (2) years

from the date of purchase from the dealer. Please keep your purchase receipt

in a safe place as it serves as proof of date of purchase. During the warranty

period, and upon proof of purchase, should the product have indications of

failure due to faulty workmanship and/or materials, we will, at our discretion,

repair or replace the defective products or components, without charge for

either parts or labor, to whatever extent we deem necessary tore-store the

product to proper operating condition. Any replacement will consist of a new

or re-manufactured functionally equivalent product of equal value, and will

be offered solely at our discretion. This warranty will not apply if the product

is modified, misused, tampered with, damaged by an act of God, or subjected

to abnormal working conditions. The warranty does not cover the bundled or

licensed software of other vendors. Defects which do not significantly affect

the usability of the product will not be covered by the warranty. We reserve

the right to revise the manual and online documentation and to make changes

from time to time in the contents hereof without obligation to notify any

person of such revision or changes.

EU Declaration of Conformity

We DrayTek Corp. , office at No.26, Fu Shing Road, HuKou County, Hsin-Chu Industry Park, Hsinchu

300, Taiwan , R.O.C., declare under our sole responsibility that the product

Product name: Dual-WAN Security Router

Model number: Vigor2915 Series

Manufacturer: DrayTek Corp.

Address: No.26, Fu Shing Road, HuKou County, Hsin-Chu Industry Park, Hsinchu

300, Taiwan , R.O.C.

is in conformity with the relevant Union harmonisation legislation:

EMC Directive 2014/30/EU , Low Voltage Directive 2014/35/EU , ErP 2009/125/EC and RoHS

2011/65/EU with reference to the following standards

Standard Version / Issue date

EN 55032 2012+AC:2013 class B

EN 61000-3-2 2014 Class A

EN 61000-3-3 2013

EN 55024 2010+A1:2015

EN 62368 2014+A11:2017

EC No. 1275/2008 2008

Hsinchu 22nd June, 2019 Calvin Ma / President .

(place) (date) (Legal Signature)

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) This device may accept any interference received, including interference that may cause

undesired operation.

Company name ABP International Inc.

Address 13988 Diplomat Drive Suite 180 Dallas TX 75234

ZIP Code 75234 E-mail rmesser@abptech.com

USA Local

Representative Contact Person Mr. Robert

Messer Tel. 19728311600

Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

More update, please visit www.draytek.com.

1. Introduction........................................................................................................... 1

2. Package Content .................................................................................................. 2

3. Panel Explanation................................................................................................. 3

3.1 Vigor2915................................................................................................................................... 3

3.2 Vigor2915F................................................................................................................................. 5

4. Hardware Installation ........................................................................................... 7

4.1 Network Connection................................................................................................................... 7

4.2 Wall-Mounted Installation........................................................................................................... 8

5. Software Configuration........................................................................................ 9

6. Customer Service............................................................................................... 19

Be a Registered Owner.................................................................................................................. 19

Firmware & Tools Updates............................................................................................................. 19

Vigor2915 series is a broadband router which integrates IP layer QoS, NAT

session/bandwidth management to help users control works well with large

bandwidth.

By adopting hardware-based VPN platform and hardware encryption of

AES/DES/3DES, and hardware key hash of SHA-1/MD5, the router increases the

performance of VPN greatly and offers several protocols (such as

IPSec/PPTP/L2TP) with VPN tunnels.

The object-based design used in SPI (Stateful Packet Inspection) firewall allows

users to set firewall policy with ease. CSM (Content Security Management)

provides users control and management in IM (Instant Messenger) and P2P (Peer

to Peer) more efficiency than before. In addition, DoS/DDoS prevention and

URL/Web content filter strengthen the security outside and control inside.

Vigor2915 series supports USB interface for connecting USB printer to share

printing function, 3G/4G USB modem for network connection, or connectivity for

network FTP service.

Take a look at the package content. If there is anything missed or damaged,

please contact DrayTek or dealer immediately.

Vigor router Quick Start Guide

RJ-45 Cat-5 Ethernet Cable

The type of the power adapter depends on the country that the router will be

installed. * The maximum power consumption is 12 Watts.

UK-type Power Adapter EU-type Power Adapter

USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter

LED Status Explanation

Blinking The router is powered on and running normally.ACT Off The router is powered off.

On Internet connection is ready.

Off Internet connection is not ready.

Internet

Blinking The data is transmitting.

On The WAN/LAN port is connected.

Off The WAN/LAN port is disconnected.

W2/P4

Blinking The data is transmitting.

On The LAN port is connected.

Off The LAN port is disconnected.

P3~P1

Blinking The data is transmitting.

On The WAN port is connected.

Off The WAN port is disconnected.

Blinking The data is transmitting.

On USB device is connected and ready for use.USB Blinking The data is transmitting.

Interface Description

PWR Connector for a power cord.

ON/OFF Power Switch.

USB Connector for a USB device (for 3G/4G USB Modem or printer or

Environmental Thermometer).

W1 Connecter for local network devices or modem for accessing

Internet.

P1~P3 Connecters for local network devices.

W2/P4 The function of this connector is adjustable and controlled by web

user interface. It can perform the job as a WAN port (for accessing

Internet) or as a LAN port (for local network devices).

Factory Reset Restore the default settings.

Usage: Turn on the router (ACT LED is blinking). Press the hole and

keep for more than 5 seconds. When you see the ACT LED begins to

blink rapidly than usual, release the button. Then the router will

restart with the factory default configuration.
