DSC 1832 Quick Guide
https://alpha.adt.com/help/154[11/13/2018 7:40:59 PM]
DSC 1832 - Quick Guide
For a detailed review of the entire system, please view the DSC 1832 manual.
This manual includes instruction variations for LED and LCD keypads. Any instructional differences are
indicated by the use of ‘OR’.
« Help Center
Arm &
Disarm the
System
Battery Bypass
Protected
Areas
Date &
Time
Settings
Chimes &
Beeps
Reset Security
Codes
Trouble
Conditions
Volume
Arm and Disarm
Arm:
To arm all sensors in AWAY mode when you are leaving the premises, press and hold the [AWAY]
button.
To arm in STAY mode when you are not leaving the premises, press and hold the [STAY] button OR
enter your [security code] and do not leave the premises.
To Quick Arm, press [*] + [0]. To enable or disable the Quick Arm feature on your device, enter [*] +
Select
DSC 1832 Quick Guide
https://alpha.adt.com/help/154[11/13/2018 7:40:59 PM]
[9] + [Master Code] + [4].
Disarm:
To disarm, enter your [security code].
For more information on this topic please visit the complete DSC 1832 manual.
Battery
The DSC 1832 operates on a Battery Replacement Page.
Bypass Protected Areas
Bypassing a zone allows you to arm your system with certain protected areas intentionally
unarmed or to access a protected area when the system is armed.
To bypass a zone, press [*] to enter the function menu.
Press [1] OR [*], then your [security code].
Enter the two digit number of the zone to be bypassed OR use the [<>] keys to find the
zone.
Press [*] to select the zone.
A [B] will appear once a zone has been bypassed.
To exit bypassing mode and return to Ready state, press [#].
To unbypass a zone, enter the two digit zone number OR use [<>] to find the zone, then
press [*]. The [B] will disappear from the display.
For more information on this topic please visit the complete DSC 1832 manual.
Change Date and Time
Press [*] + [6] + [Master security code] OR use the [<>] to find the [Time and Date] option
from the menu, then press [1].
Either enter the time in 24-hour format, i.e., 16:30 for 4:30pm OR use the [<>] scroll keys
to find the desired time.
Either enter the date in MM:DD:YY format, i.e., 03/02/15 for March 2, 2015 OR use the [<>]
scroll keys to find the desired date.
Press [#] to exit.
Chimes and Beeps
DSC 1832 Quick Guide
https://alpha.adt.com/help/154[11/13/2018 7:40:59 PM]
When your system is in chime mode, a chime alert will sound three tones whenever a
protected door/window is opened.
To turn the door chime function off, press and hold the [Chime] key for two seconds OR
press [*] + [4].
To turn the door chime function on, press and hold the [Chime] key for two seconds OR
press [*] + [4].
For more information on this topic please visit the complete DSC 1832 manual.
Reset
To clear your alarm history after an event, first arm your system with your [security code],
then disarm your system to clear the event history.
Security Codes
You can program additional user codes and attributes. Additional users will be restricted to
arming and disarming functions, while the Master user code can perform all functions.
To program a new user, press [*] + [5] + [Master security code].
Enter the two digit number to be programmed, i.e., 06 for Access Code 6 or use the [<>] to
find the desired user code and press [*] to select.
Enter the new user’s new access code.
Continue adding additional user codes or press [#] to exit.
To erase an access code, select the code using [*] as the first digit. The system will
automatically erase the access code.
Some user numbers have been pre-programmed:
User Level Explanation Assigned User Code
Master Can perform all functions and assign codes [40], can only be changed
by an installer
User Access defined by Master User [1] - [32]
Supervisor Similar to Master level, but can be changed without
requiring an installer. [41], [42]
Duress Code secretly sends a duress report. Any user code
can be made a Duress code. [33], [34]
Zone
Bypassing
Can manually bypass zones and arm/disarm the
system. [3]
DSC 1832 Quick Guide
https://alpha.adt.com/help/154[11/13/2018 7:40:59 PM]
Return to Top
Onetime
User Code
Can disarm the system once per day. Reset daily at
midnight. [8]
For more information on this topic please visit the complete DSC PC1832 manual
Trouble Conditions
When a trouble condition is detected, the Trouble or System indicator will turn on and the
keypad will beep every 10 seconds.
To silence the Trouble Condition beeps, press [#].
To view the Trouble Condition, press [*] + [2].
To override the Trouble Condition and continue to arm, press [*] + [2], then press [9].
For more information on this topic please visit the complete DSC PC1832 manual.
Volume
The volume on the DSC 1832 is not adjustable.
