DURKOPP ADLER M-Type Delta D867 Betriebsanleitung

D867

Additional Instructions

Neat seam beginning (NSB)

Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents,

including extracts, is prohibited without the prior written approval of Dürkopp Adler AG.

IMPORTANT

READ CAREFULLY BEFORE USE

KEEP FOR FUTURE REFERENCE

Table of Contents

Additional Instructions M-TYPE DELTA - 00.0 - 05/2020 1

1 General information ...................................................................3

2 Assembling the neat seam beginning (NSB)...........................5

2.1 Presettings outside of the machine (optional) ..............................5

2.2 Checking and adjusting the cutting pressure................................7

2.3 Checking and adjusting the clamping spring pressure.................8

2.4 Assembling the NSB into the machine .........................................9

2.5 Activating the NSB in the software .............................................15

3 Changing the knives ................................................................16

4 Maintenance..............................................................................18

Table of Contents

2 Additional Instructions M-TYPE DELTA - 00.0 - 05/2020

General information

Additional Instructions M-TYPE DELTA - 00.0 - 05/2020 3

1 General information

The kit is used to create a neat seam beginning.

Components of the kit

Check whether the scope of delivery for kit 0867 594324 is correct prior

to installation.

Part number Quantity Description

0867 354314 1 NSB assembly, consisting of:

• 0867 350363, stop block

• 9790 201000, WI-E coupling (4 pieces)

• 0867 350423, block

• 0867 350470, plate

• 9700 234002, double cylinder D12x10 (2 pieces)

• 9330 000087, washer A4,3 (5 pieces)

• 9202 002067, screw M4x8 (5 pieces)

• 0867 350440, stop

• 9202 100328, countersunk screw M4x8 (3 pieces)

• 0867 350410, counter blade

• 0867 350330, thread-pulling knife

• 0867 350400, clamping spring

• 9204 431657, screw M4x8 (2 pieces)

• 0867 350313, holder

• 0867 354300, carrier plate

• 9712 867001, valve block

• 9731 004024, hose PUR, green (0.095 m)

• 9731 004034, hose PUR, yellow (0.115 m)

• 9731 004014, hose PUR, red (0.06 m)

• 9731 004044, hose PUR, blue (0.07 m)

• 9202 001727, screw M3x30 (5 pieces)

• 9202 100338, countersunk screw M4x10 (2 pieces)

• 0867 350290, retaining bracket

• 9790 060101, WI-E coupling

0579 140074 1 Container

0742 002096 2 Clip

0999 240392 1 WI-E coupling

0999 240402 1 T-R coupling

9202 002897 2 Screw M6x16

9790 610460 1 Plug-in connection WI-E DA6/4

9330200110 2 Washer A6.4

9731 005004 0.5 m Hose PUR, gray

9731 006004 1.5 m Hose PUR, gray

9732 010033 1 Hose ARMORVIN

9790 201001 1 WI-E coupling R1/8” D4

9840 120001 6 Nail clamp

9840 120026 1 Mounting clip

General information

4 Additional Instructions M-TYPE DELTA - 00.0 - 05/2020

Important

The use of the NSB requires that the new sewing equipment

4867 E21206 or 4867 E21209 has been installed (Parts List).

The new sewing equipment is comprised of

• Feed dog (needle hole size 2.2x3.2; saw-tooth cut)

• Throat plate with left and right throat plate slide

• Presser foot

• Walking foot (non-toothed)

9840 123003 6 Steel needle

9874 867019 1 Cable

9081 200810 1 Pin wrench

Part number Quantity Description

Assembling the neat seam beginning (NSB)

Additional Instructions M-TYPE DELTA - 00.0 - 05/2020 5

2 Assembling the neat seam beginning (NSB)

When the needle exits the sewing material after the first stitch, the thread-

pulling knife pulls the initial thread into the clamp. This ensures

secure sewing.

Following the 2nd stitch, the remaining thread is cut off and removed by

the suction device.

Important

The NSB will not be active until the completion of the 2nd stitch after the

machine was switched on.

The NSB is not active if the needle tip remains below the throat plate level

during sewing.

2.1 Presettings outside of the machine (optional)

The kit has been preset at the factory and does usually NOT have to be

adjusted.

Do not check or adjust the presettings outside of the machine UNLESS

the NSB is without function.

Order

1. Complete the presettings outside of the machine.

2. Check/adjust the cutting pressure (p. 7).

3. Check/adjust the clamping spring pressure (p. 8).

4. Assemble the NSB (p. 9).

5. Activate the NSB (p. 15).

Fig. 1: Presettings outside of the machine (1)

To complete the presettings outside of the machine:

1. Remove the clamping spring (1).

2. Loosen the nut (2).

3. Extend cylinder (4).

(1) - Clamping spring

(2) - Nut (3) - Piston rod

(4) - Cylinder

①

②

③

④

Assembling the neat seam beginning (NSB)

6 Additional Instructions M-TYPE DELTA - 00.0 - 05/2020

4. Turn the piston rod (3).

Measurement Amust be 8.8 mm with the cylinder fully extended (4).

5. Tighten the nut (2).

Fig. 2: Presettings outside of the machine (2)

6. Extend cylinder (6).

7. Retract cylinder (4).

8. Press the pin (5) against the threaded pin (7).

9. Turn the threaded pin (7).

Measurement Bmust be 2.8 mm when the pin (5) abuts on

the threaded pin (7).

Fig. 3: Presettings outside of the machine (3)

10. Retract cylinder (6).

11. Loosen the screw (8).

(5) - Pin

(6) - Cylinder (7) - Threaded pin

⑦⑤⑥

(5) - Pin

(6) - Cylinder (8) - Screw

(9) - Plate

⑤

⑦

⑧

⑨

Assembling the neat seam beginning (NSB)

Additional Instructions M-TYPE DELTA - 00.0 - 05/2020 7

12. Shift the plate (9).

Measurement Cmust be 1.3 mm when the pin (5) abuts on the

plate (9).

13. Tighten the screw (8).

14. Place the clamping spring (1).

2.2 Checking and adjusting the cutting pressure

Order

1. Complete the presettings outside of the machine (p. 5).

2. Check/adjust the cutting pressure.

3. Check/adjust the clamping spring pressure (p. 8).

4. Assemble the NSB (p. 9).

5. Activate the NSB (p. 15).

Fig. 4: Checking and adjusting the cutting pressure

Proper setting

Screw (1) is adjusted such that the thread-pulling knife (2) moves smooth-

ly and the counter blade (3) cuts the loose thread cleanly.

To check and adjust the cutting pressure:

1. Screw in screw (1) in such a way that the screw head abuts on

the counter blade (3).

NOTICE

Property damage may occur!

Risk of knife breakage if pressure is adjusted too high.

Do not adjust the cutting pressure too high.

(1) - Screw

(2) - Thread-pulling knife (3) - Counter blade

①

②

③

Assembling the neat seam beginning (NSB)

8 Additional Instructions M-TYPE DELTA - 00.0 - 05/2020

2. Turn the screw (1).

• Increase the cutting pressure: Turn screw (1) clockwise

• Reduce the cutting pressure: Turn screw (1) counterclockwise

3. Carry out a cutting test.

4. Readjust the cutting pressure if necessary.

2.3 Checking and adjusting the clamping spring pressure

The clamping spring clamps the needle thread after the 1st short stitch

and prior to cutting.

Order

1. Complete the presettings outside of the machine (p. 5).

2. Check/adjust the cutting pressure (p. 7).

3. Check/adjust the clamping spring pressure.

4. Assemble the NSB (p. 9).

5. Activate the NSB (p. 15).

Fig. 5: Checking and adjusting the clamping spring pressure

To adjust the clamping spring pressure:

1. Adjust screw (1) such that the needle thread is securely clamped by

the clamping spring (2).

Theclampingspringpressuredependsontheneedlethreadthickness.

Make sure that the needle thread can be effortlessly pulled out of

the clamped position.

2. Turn the screw (1).

• Increase the clamping spring pressure:

Turn screw (1) clockwise

• Reduce the clamping spring pressure:

Turn screw (1) counterclockwise

(1) - Screw (2) - Clamping spring

①

②
