DUROMAX XP13000HXT Bedienungsanleitung

REV: XP13000HXT-02272020

This manual provides information regarding

the operation and maintenance of these

products. We have made every effort to

ensure the accuracy of the information in this

manual. We reserve the right to change this

product at any time without prior notice.

5800 Ontario Mills Pkwy

Ontario, CA 91764 USA

www.duromaxpower.com

Call our Customer Care Team Toll Free 8-5 pm PST Mon-Fri

844-DUROMAX

XP13000HXT

SERVICE MANUAL

CONTENTS

Generator Components................................................................................................. 6

Generator Components

Specications................................................................................................................. 30

Torque Values ............................................................................................................... 31

Specications

Troubleshooting............................................................................................................ 33

Changing/Inspecting the Carbon Brushes................................................................. 34

Changing/Inspecting the AVR ...................................................................................... 36

Troubleshooting

Maintenance Schedule................................................................................................... 8

Break-In Period ............................................................................................................... 9

High Altitude Operation ................................................................................................. 9

Changing the Carburetor Main Jet.............................................................................. 10

Natural Gas Requirements .......................................................................................... 13

Checking the Oil ............................................................................................................ 14

Changing the Oil............................................................................................................ 15

Cleaning the Air Filter ................................................................................................... 16

Spark Plug Maintenance .............................................................................................. 18

Emptying the Gas Tank ................................................................................................ 20

Cleaning the Fuel Filter Cup......................................................................................... 22

Transporting the Generator ........................................................................................ 23

Storing the Generator for Same Day Use .................................................................. 24

Storing the Generator for Use Within 30 Days.......................................................... 25

Storing the Generator for Longer Than 30 Days....................................................... 26

Check and Adjust Valve Clearance.............................................................................. 28

Maintenance and Care

CONTENTS

Common Engine Parts................................................................................................... 39

Wiring Diagram .............................................................................................................. 46

Generator Diagrams

Maintenance Log............................................................................................................ 47

Maintenance Log

GENERATOR COMPONENTS

4. Fuel Tank

2. Air Cleaner

6. Handles

7. Battery

8. Oil Fill and Dipstick

1. Recoil Start

1. Recoil Start – Easy Pull Recoil Start to start the engine without the electric start.

2. Air Cleaner - A removable, cleanable, oiled element that cleans the air going into the engine.

3. Fuel Valve - On/O valve that allows gasoline to the fuel switch.

4. Fuel Tank - All-metal 8.3 gallon gasoline fuel tank.

5. Power Panel - Contains the start switch, plugs, meters, and circuit breakers.

6. Handles - Long handles allow maneuvering

acr

oss any surface

7. Battery - 12V DC Battery that powers the Electric Start System.

8. Oil Fill and Dipstick - Use to add or check the oil.

9. Gas Type - Fuel selection switch to choose Gas/Propane, or Natural Gas.

10. LPG/NG Inlet - Provides a regulated LPG/NG Fuel supply to the engine.

11. Fuel Type - Fuel selection switch to choose Gas, Propane/NG, or Storage.

12. Engine Switch – Push Button Start switch. Press for 2 second to start the generator. Hold for 3

seconds to stop the generator.

13. Charging Light - Lights up when the generator is charging the on-board battery.

5. Power Panel

3. Fuel Valve

14. Low Oil Alert

21. GFCI 20A Receptacles

14. Low Oil Alert – Will light only if the generator shuts down due to low oil.

15. Battery Switch – Prevents battery discharge during storage.

16. Idle Control - Slows the engine to save fuel and lower noise when no load.

17. Circuit Breaker - Protects the panel from overload and short circuits.

18. Multimeter – Displays gasoline fuel level, load, voltage, hertz, and time running.

19. 120/240V 4-Prong Receptacle - Use to connect electrical devices that run 120 or 240-Volt,

60Hz, single-phase, AC current (NEMA 14-50).

20. 120/240V 4-Prong Twist Lock - Use to connect electrical devices that run 120 or 240-Volt,

60Hz, single-phase, AC current (NEMA L14-30).

21. 120V 3-Prong GFCI Receptacle - Use to connect electrical devices that run 120-Volt, 60Hz,

single-phase, AC current (NEMA 5-20).

22. 120V 3-Prong Twist Lock - Use to connect electrical devices that run 120-Volt, 60 Hz, single-

phase, AC current (L5-30).

23. CO Alert - Shuts down the engine in the event of CO buildup.

9. Gas Type

15. Battery Switch

10. LPG/NG Inlet

12. Engine Switch

13. Charging Light

14. Low Oil Alert

16. Idle Control

17. Circuit Breaker

18. Multimeter

19. 50A Receptacle

20. 240v 4-Prong Twist Lock

21. GFCI 20A Receptacles

23. CO Alert

22. 120v 3-Prong Twist Lock

11. Fuel Type

MAINTENANCE AND CARE

Proper routine maintenance of your generator is essential for safe, economical, and trouble-free

operation. It will also help reduce air pollution.

Maintenance Schedule

Remember that this schedule is based on the assumption that your machine will be used for its

designed purpose. Sustained high-load, high-temperature operation, or use in unusually wet or

dusty conditions, will require more frequent service.

SERVICE

EVERY USE

1ST MO. OR

8 HRS.

(BREAK IN)

EVERY 3 MO. OR

50 HRS. OF

HEAVY USE

EVERY 6 MO.

OR 100 HRS. OF

NORMAL USE

EVERY 12 MO. OR

300 HRS.

EVERY 3 YRS. OR

500 HRS.

ENGINE OIL CHECK CHANGE CHANGE CHANGE

AIR CLEANER CHECK CHECK CHANGE CHANGE

SEDIMENT

CUP

CLEAN CLEAN

SPARK PLUG CLEAN /

ADJUST

CLEAN /

ADJUST

SPARK

ARRESTOR

CHECK CLEAN

IDLE SPEED CHECK /

ADJUST

VALVE

CLEARANCE

CHECK /

ADJUST

FUEL TUBE CHECK CHECK /

REPLACE

FUEL TANK /

FILTER

CLEAN

COMBUSTION

CHAMBER

CLEAN

WARNING: Improper maintenance, or failure to correct a problem before operation, can

cause a malfunction in which you can be seriously injured or killed. Always follow the

inspection, maintenance recommendations, and schedules in this instruction manual.

●Make sure the engine is o before you begin any maintenance or repairs.

●Let the engine and exhaust system cool before touching.

●To reduce the possibility of re or explosion, be careful when working around

gasoline. Use only a nonammable solvent, not gasoline, to clean parts. Keep

cigarettes, sparks, and ames away from all fuel-related parts.

Break-In Period

As the best practice for any new combustion motor it’s recommended to perform the break

in procedure as follows:

●Run the engine for the rst 6-8 hours on conventional oil, then change the oil. After

the break-in period synthetic oil may be used.

●During the break in period of the rst 6-8 hours keep the engine speed under 50% for

optimal results.

●Check and clean the air lter if necessary after the break-in period.

High Altitude Operation

At high altitudes, the standard carburetor air/fuel mixture will be too rich. The performance will decrease,

and fuel consumption will increase. A very rich mixture will also foul the spark plug and cause hard starting.

Operation at an altitude that diers from that at which this engine was certied, for extended periods of

time, may increase emissions. High altitude performance can be improved by specic modications to

the carburetor. If you always operate your engine at altitudes above 3,000 feet (900 meters), have a dealer

perform this carburetor modication. This engine, when operated at high altitude with the carburetor

modications for high altitude use, will meet each emission standard throughout its useful life. Even with

carburetor modication, engine horsepower will decrease by about 3.5% for each 1,000-foot (300-meter)

increase in altitude. The eect of altitude on horsepower will be greater than this if no carburetor

modication is made.

When the carburetor has been modied for high altitude operation, the air/fuel mixture will be too lean for

low altitude use. Operation at altitudes below 3,000 feet (900 meters) with a modied carburetor may cause

the engine to overheat and result in serious engine damage.

Note: Jet kits available for purchase upon request, please contact us at 844-DUROMAX to set up your

parts order.

Altitude Range Jet Kit Part Number

3,000 ft. - 6,000 ft. 93140-Z2F0110

6,000 ft. - 8,000 ft. 93141-Z2F0110

MAINTENANCE AND CARE (CONTINUED)

Changing the Carburetor Main Jet

Remove the lter cover screw

Remove the lter cover screw and remove air lter cover.

NOTE: Carburetor should be drained of all gasoline prior

to servicing.

Remove element and holder

Remove air lter nuts

Remove air lter bracket nut

Remove the air lter element and element holder from air

lter.

Remove the 2 front facing nuts connecting the air lter to the

carburetor.

Remove the nut attaching the bottom air lter bracket located

behind the air lter housing.
