Dynaudio Sub 6 Bedienungsanleitung
Sub 6
User manual
▪About this operating manual: Signal words
▪Important safety instructions
▪About this manual
▪Safety Icons
▪Signal Words
▪User Manual Structure
▪Introduction
▪Getting to know the Sub 6
▪Unpacking
▪Packaging material
▪Disposal
▪Carton contents
▪Installation
▪Positioning
▪Impact of room-modes
▪Using multiple subwoofers
▪Positioning Possibilities
▪Sub 6 Feet
▪Sub 6 Mains and Signal Connections
▪Sub 6 Connections Schemes
▪Subwoofer Control
▪Control and configuration
▪Subwoofer controller
▪Configuration and Use
▪General Tips
▪Sub 6 Configuration Menus
▪Sub 6 In Use
▪Sub 6 Troubleshooting
▪Sub 6 Troubleshooting Matrix
▪Updating the Firmware
▪Requirements
▪Firmware versions
2Sub 6 User manual
4Sub 6 User manual
About this operating manual: Signal
words
The lightning flash with an arrowhead symbol within an equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the product.
Caution
Indicates a potentially hazardous situation which, if not avoided, could result in damage to equipment.
CAUTION
Indicates in combination with a safety sign a potentially hazardous situation which, if not avoided, could result in
minor or moderate injury or damage to equipment.
WARNING
Indicates in combination with a safety sign a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
DANGER
Indicates in combination with a safety sign a hazardous situation which, if not avoided, will result in death or
serious injury.
About this operating manual: Signal words 5
Important safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. WARNING: To reduce the risk of fire or electric shock, this apparatus should not be exposed to rain or moisture and
objects filled with liquids, such as vases, should not be placed on this apparatus.
16. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle.
17. The mains plug of the power supply cord shall remain readily operable.
WARNING
Risk of electric shock. Do not open.
To reduce the risk of electric shock, do not remove the rear panel and do not expose the apparatus to rain or
moisture. No user serviceable parts inside. Refer servicing to qualified personnel.
6Sub 6 User manual
About this manual
Safety Icons
In this operating manual following icons and symbols are used.
General safety sign
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the product.
Dangerous voltage
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence
of uninsulated “dangerous voltage” within the product’s enclosure that may be of sucient magnitude to constitute
a risk of electric shock to persons.
Signal Words
NOTICE
Indicates in combination with a safety sign a hazardous situation which, if not avoided, will result in damage to
equipment.
CAUTION
Indicates in combination with a safety sign a potentially hazardous situation which, if not avoided, could result in
minor or moderate injury or damage to equipment.
WARNING
Indicates in combination with a safety sign a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
DANGER
Indicates in combination with a safety sign a hazardous situation which, if not avoided, will result in death or
serious injury.
User Manual Structure
Following this introduction and a section describing the main features of the Sub 6, this manual is divided into
three sections in which you can find all the information needed to install and use your Dynaudio Sub 6:
▪Unpacking: Describes unpacking the subwoofer, environmental factors and the contents of the subwoofer carton.
▪Installation: This section describes subwoofer positioning in general and where to locate your Sub 6 for optimum
About this manual 7
performance.
▪Configuration and Use: This section describes the functions available through the Sub 6 user interface, how to
configure the subwoofer optimally for your system. This section also covers the Sub 6 in use and how to fix any problems
that might arise.
8Sub 6 User manual
Introduction
Dear music lover
Welcome to Dynaudio Sub 6 active DSP subwoofer.
The Sub 6 is a very high performance product that rewards thoughtful setup and installation so we suggest that
you take a little time to read this manual before you begin.
We’ve been designing, engineering and creating speakers at our Denmark headquarters since 1977, and ever
since we started we’ve been pouring advanced R&D technology into every model. What comes out is audio
reproduction at the highest level, making listening to even the most familiar recordings a new listening experience
altogether. Our aim: to reproduce exactly what was happening in the studio at the time of the original recording.
In fact, we’re one of very few companies who can realise such concepts. That’s thanks to Dynaudio Labs, our in-
house development and production facility. It’s so advanced, in fact, that we’ve been given TS16949 certification.
Each loudspeaker is constructed and rigorously tested by our master-craftsmen to these incredibly demanding
standards.
If you want to get the best possible performance from them (that’s why you bought Dynaudio in the first place,
after all), take a look at the information on the following pages. By considering our tips and suggestions, you’ll be
recreating what our engineers do in our testing rooms: extracting every ounce of detail and nuance in the music…
and then enjoying every second of it.
We wish you many years of enjoyment with your new subwoofer.
Dynaudio
Introduction 9
Getting to know the Sub 6
The Dynaudio Sub 6 is a DSP controlled active subwoofer intended to augment the bass performance of full
range speakers in conventional stereo systems.
The Sub 6 features a closed box acoustic system and incorporates dual opposed 24cm drivers to minimise
mechanical vibration.
Connection facilities include balanced XLR and unbalanced stereo inputs with output sockets provided to enable
the connection of active main speakers or a power amplifier for main speakers.
The Sub 6 incorporates low-pass filter presets configured to match a range of Dynaudio mains speaker models,
three bands of parametric equalisation, and an adjustable low pass filter that can be configured for use with main
speaker models from alternative manufacturers.
Sub 6 configuration and control is accomplished through a rear panel mounted display combined with a rotary
controller.
10 Sub 6 User manual
