Mini Pulse XT

Assembly Manual

Introduction................................................................3

Specifications.............................................................3

Using the Manual .......................................................3

Contents of Kit/Parts Layout .........................................4

Required Radio Equipment...........................................5

Important Information About Motor Selection .................6

Sport Outrunner Setup.................................................6

Optional Accessories ..................................................6

Required Tools and Adhesives......................................6

Note Regarding Hinges...............................................7

Note on Lithium Polymer Batteries.................................7

Warning....................................................................7

Limited Warranty Period ..............................................8

Limited Warranty & Limits of Liability.............................8

Safety Precautions.......................................................9

Questions, Assistance, and Repairs...............................9

Questions or Assistance...............................................9

Inspection or Repairs...................................................9

Warranty Inspection and Repairs................................10

Table of Contents

Non-Warranty Repairs...............................................10

Safety, Precautions, and Warnings..............................11

Landing Gear Installation...........................................12

Outrunner Motor Installation.......................................14

Cowling Installation ..................................................15

Tail Installation..........................................................19

Wing Preparation .....................................................24

Final Assembly .........................................................26

Control Throws .........................................................30

Range Testing the Radio ............................................31

Center of Gravity......................................................31

Preflight ...................................................................32

Notes ......................................................................33

2006 Official AMA

National Model Aircraft Safety Code..........................34

Introduction

Thank you for purchasing the Mini Pulse XT. Designed

from the beginning for electric power, the Mini Pulse XT

is developed from the Hangar 9®Pulse™ XT with the

same flight characteristics as the 40-size version. It is a

perfect transitional airplane for beginners who want to

learn aerobatics and for sport flyers who want an easy,

comfortable sport flyer. All flight control surfaces, hinges,

and control horns have been installed at the factory to

help speed up the building time.

Specifications

Wingspan: 42.5 in (1080mm)

Length: 37.5 in (875mm)

Wing Area: 330 sq in (21.5 sq dm)

Weight w/o Battery: 21–22 oz (710–820 g)

Weight w/ Battery: 25–27 oz (795–965 g)

Using the Manual

This manual is divided into sections to help make assembly

easier to understand, and to provide breaks between each

major section. In addition, check boxes have been placed

next to each step to keep track of each step completed.

Steps with a single circle () are performed once, while

steps with two circles () indicate that the step will

require repeating, such as for a right or left wing panel,

two servos, etc.

Remember to take your time and follow the directions.

Contents of Kit/Parts Layout

Large Replacement Parts:

EFL2376 Wing w/Ailerons

EFL2377 Fuselage

EFL2378 Tail Set

EFL2380 Main Landing Gear

EFL2381 Cowling

EFL2382 Wheel Pants

Small Replacement Parts:

EFL2379 Pushrod Set

EFL2383 Motor X-Mount

EFLA200 Micro Control Horns

FLA203 Micro Control Connectors

EFLA219 Steerable Tailwheel Assembly

EFLA223 Foam Park Wheels, 2"

EFLA213 E-flite/JR/Horizon Decals

You will need a minimum 4-channel transmitter, crystals,

micro receiver, and four sub-micro servos. You can choose

to purchase a complete radio system that includes all of

these items or, if you are using an existing transmitter, just

purchase the other required equipment separately.

Complete Radio System

SPM2460 DX6 DSM 6CH Park Flyer w/4-S75

Servos

Note: We recommend the crystal-free,

interference-free Spektrum®DX6 2.4GHz DSM®

6-Channel System, which includes a micro

receiver and 4 sub-micro servos.

Or Purchase Separately

SPM6000 AR6000 DSM DualLink™ 6-Channel

Park Flyer Rx

JSP30610 6-Channel UltraLite Rx w/o Crystal,

Positive Shift JR/AIR (72MHz)

JSP30615 6-Channel UltraLite Rx w/o Crystal,

Negative Shift FUT/HRC (72MHz)

JRPXFR** FM Receiver Crystal

JSP98110 6" Servo Extension (2)

JSP98030 12" Servo Extension (2)

JSP98020 Y-harness, Standard 6"

EFLRS75 7.5-Gram Sub-Micro Servo (4)

Required Radio Equipment

Important Information About Motor

Selection

We recommend the E-flite®Park 450 Brushless Outrunner,

890Kv (EFLM1400) to provide you with excellent sport

and aerobatic power and a worry-free outrunner motor.

The Mini Pulse XT does not include a propeller, but we

recommend our 10X8 Electric Prop (EFLP1080E).

Sport Outrunner Setup

EFLM1400 Park 450 Brushless Outrunner

Motor, 890Kv

EFLA1025 25-Amp Pro Brushless ESC

THP21003SPL 2100mAh 3-Cell 11.1V Li-Po,

16GA

EFLB1035 11.1V 2100mAh 3-Cell Li-Po,

16GA

EFLP1080E 10 x 8 Electric Prop

EFLAEC302 EC3 Battery Connector, Female (2)

EFLC3005 Celectra 1- to 3-cell Li-Po Charger

This is a sport flyer setup for smooth and stable flights.

Optional Accessories

EFLA110 Power Meter

Required Tools and Adhesives

Tools & Equipment

EFLA250 Park Flyer Tool Assortment, 5-piece

Or Purchase Separately

EFLA257 Screwdriver, #0 Phillips (or included

with EFLA250)

EFLA251 Hex Wrench: 3/32" (or included

with EFLA250)

Nut driver: 1/4"

Drill

Drill bit: 1/16" (1.5mm), 5/64" (2mm)

Masking tape

Card stock

Felt-tipped pen

Needle-nose pliers

Canopy glue

Note Regarding Hinges

For your convenience and to speed the assembly process,

the hinges have already been installed and glued. We

suggest that you take a minute before beginning assembly

of your model to check them.

Grasp the wing and aileron at each hinge location, then

gently pull on the aileron to ensure the hinges are secure

and cannot easily be pulled away from either surface.

Use caution when gripping the wing and aileron to avoid

crushing or damaging the structure. Repeat this process for

the elevator and rudder.

If, however, you find that the hinges pull away, simply

wick thin CA into the hinge slots and reinstall the

hinges/surfaces.

Note on Lithium Polymer Batteries

Lithium Polymer batteries are significantly

more volatile than alkaline or Ni-Cd/Ni-MH

batteries used in RC applications. All

manufacturer’s instructions and warnings

must be followed closely. Mishandling of

Li-Po batteries can result in fire. Always follow

the manufacturer’s instructions when disposing

of Lithium Polymer batteries.

Warning

An RC aircraft is not a toy! If misused, it can cause

serious bodily harm and damage to property. Fly

only in open areas, preferably at AMA (Academy of

Model Aeronautics) approved flying sites, following all

instructions included with your radio.

Keep loose items that can get entangled in the propeller

away from the prop, including loose clothing, or other

objects such as pencils and screwdrivers. Especially keep

your hands away from the propeller.

Limited Warranty Period

Horizon Hobby, Inc. guarantees this product to be free

from defects in both material and workmanship at the

date of purchase.

Limited Warranty & Limits of Liability

Pursuant to this Limited Warranty, Horizon Hobby, Inc.

will, at its option, (i) repair or (ii) replace, any product

determined by Horizon Hobby, Inc. to be defective. In the

event of a defect, these are your exclusive remedies.

This warranty does not cover cosmetic damage or damage

due to acts of God, accident, misuse, abuse, negligence,

commercial use, or modification of or to any part of

the product. This warranty does not cover damage due

to improper installation, operation, maintenance, or

attempted repair by anyone other than an authorized

Horizon Hobby, Inc. service center. This warranty is

limited to the original purchaser and is not transferable.

In no case shall Horizon Hobby’s liability exceed the

original cost of the purchased product and will not

cover consequential, incidental or collateral damage.

Horizon Hobby, Inc. reserves the right to inspect any and

all equipment involved in a warranty claim. Repair or

replacement decisions are at the sole discretion of Horizon

Hobby, Inc. Further, Horizon Hobby reserves the right to

change or modify this warranty without notice.

REPAIR OR REPLACEMENT AS PROVIDED UNDER

THIS WARRANTY IS THE EXCLUSIVE REMEDY OF

THE CONSUMER. HORIZON HOBBY, INC. SHALL

NOT BE LIABLE FOR ANY INCIDENTAL OR

CONSEQUENTIAL DAMAGES.

As Horizon Hobby, Inc. has no control over use, setup,

final assembly, modification or misuse, no liability shall be

assumed nor accepted for any resulting damage or injury.

By the act of use, setup or assembly, the user accepts all

resulting liability.

If you as the purchaser or user are not prepared to accept

the liability associated with the use of this product, you

are advised to return this product immediately in new and

unused condition to the place of purchase.

Safety Precautions

This is a sophisticated hobby product and not a toy. It

must be operated with caution and common sense and

requires some basic mechanical ability. Failure to operate

this product in a safe and responsible manner could result

in injury or damage to the product or other property. This

product is not intended for use by children without direct

adult supervision.

The product manual contains instructions for safety,

operation and maintenance. It is essential to read and

follow all the instructions and warnings in the manual,

prior to assembly, setup or use, in order to operate

correctly and avoid damage or injury.

Questions,Assistance, and Repairs

Your local hobby store and/or place of purchase cannot

provide warranty support or repair. Once assembly, setup

or use of the product has been started, you must contact

Horizon Hobby, Inc. directly. This will enable Horizon to

better answer your questions and service you in the event

that you may need any assistance.

Questions or Assistance

For questions or assistance, please direct your email to

productsupport@horizonhobby.com, or call 877.504.0233

toll-free to speak to a service technician.

Inspection or Repairs

If your product needs to be inspected or repaired, please

call for a Return Merchandise Authorization (RMA). Pack

the product securely using a shipping carton. Please note

that original boxes may be included, but are not designed

to withstand the rigors of shipping without additional

protection. Ship via a carrier that provides tracking and

insurance for lost or damaged parcels, as Horizon Hobby,

Inc. is not responsible for merchandise until it arrives and

is accepted at our facility. Include your complete name,

address, phone number where you can be reached during

business days, RMA number, and a brief summary of the

problem. Be sure your name, address, and RMA number

are clearly written on the shipping carton.

Warranty Inspection and Repairs

To receive warranty service, you must include your

original sales receipt verifying the proof-of-purchase

date. Providing warranty conditions have been met, your

product will be repaired or replaced free of charge.

Repair or replacement decisions are at the sole discretion

of Horizon Hobby.

Non-Warranty Repairs

Should your repair not be covered by warranty and the

expense exceeds 50% of the retail purchase cost, you will

be provided with an estimate advising you of your options.

You will be billed for any return freight for non-warranty

repairs. Please advise us of your preferred method of

payment. Horizon Hobby accepts money orders and

cashiers checks, as well as Visa, MasterCard, American

Express, and Discover cards. If you choose to pay by

credit card, please include your credit card number and

expiration date. Any repair left unpaid or unclaimed

after 90 days will be considered abandoned and will be

disposed of accordingly.

Electronics and engines requiring inspection or

repair should be shipped to the following address

(freight prepaid):

Horizon Service Center

4105 Fieldstone Road

Champaign, Illinois 61822

All other products requiring inspection or repair should be

shipped to the following address (freight prepaid):

Horizon Product Support

4105 Fieldstone Road

Champaign, Illinois 61822

Andere Handbücher für Mini Pulse XT

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere E-FLITE Spielzeug Handbücher

E-FLITE

E-FLITE A6M5 Zero 300 Bedienungsanleitung

E-FLITE

E-FLITE Ultra Micro FPV Vapor Bedienungsanleitung

E-FLITE

E-FLITE UMX PittsS-1S Bedienungsanleitung

E-FLITE

E-FLITE Apprentice STS Bedienungsanleitung

E-FLITE

E-FLITE Blade CP Bedienungsanleitung

E-FLITE

E-FLITE J-3 Cub 450 Bedienungsanleitung

E-FLITE

E-FLITE UMX MiG 15 DF Bedienungsanleitung

E-FLITE

E-FLITE Apprentice S 15e Bedienungsanleitung

E-FLITE

E-FLITE P-51D Mustang Bedienungsanleitung

E-FLITE

E-FLITE Mini Funtana Bedienungsanleitung

E-FLITE

E-FLITE Jenny JN-4 Slow Flyer Bedienungsanleitung

E-FLITE

E-FLITE Mini Pulse XT PNP Bedienungsanleitung

E-FLITE

E-FLITE P-38 Lightning 400 ARF Bedienungsanleitung

E-FLITE

E-FLITE Extra 260 480 ARF Bedienungsanleitung

E-FLITE

E-FLITE Shoestring 15e ARF Bedienungsanleitung

E-FLITE

E-FLITE UMX Habu 180 DF Bedienungsanleitung

E-FLITE

E-FLITE F86 Sabre 15DF Bedienungsanleitung

E-FLITE

E-FLITE Mini Ultra Stick PNP Bedienungsanleitung

E-FLITE

E-FLITE S.E.5a Slow Flyer ARF EFL1925 Bedienungsanleitung

E-FLITE

E-FLITE MINI EDGE 540 3D Bedienungsanleitung

E-FLITE

E-FLITE EFL9080 Bedienungsanleitung

E-FLITE

E-FLITE G210 Bedienungsanleitung

E-FLITE

E-FLITE Mini ShowTime 4D Bedienungsanleitung

E-FLITE

E-FLITE UMX GEE BEE R2 Bedienungsanleitung

Beliebte Spielzeug Handbücher anderer Marken

marklin

marklin 37321 Bedienungsanleitung

Canon

Canon PAPER CRAFT Bedienungsanleitung

GREAT PLANES

GREAT PLANES Pitts M-12S Bedienungsanleitung

NOCH

NOCH 14261 Bedienungsanleitung

Hausler

Hausler 450 SE V2 Bedienungsanleitung

Dynaflite

Dynaflite Daydream Bedienungsanleitung

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Handbuch

Kenner

Kenner Batman 63651 Bedienungsanleitung

LEGO

LEGO 8527 Bedienungsanleitung

iKarus

iKarus ECO 8 Bedienungsanleitung

Multiplex

Multiplex EasyStar II Bedienungsanleitung

Walkera

Walkera 38 Bedienungsanleitung

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Bedienungsanleitung

MD MXION SWD Bedienungsanleitung

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Bedienungsanleitung

marklin

marklin 39671 Bedienungsanleitung

Meccano

Meccano 15103 Bedienungsanleitung

LEGO

LEGO TECHNIC 8735 Bedienungsanleitung
