EarthQuake EQ12S8 Bedienungsanleitung

Specification

Nominal Basket Diameter

Nominal Impedance

Max Power Rating

Resonance

Usable Frequency Range

Sensitivity

Magnet Weight

Voice Coil Diameter

12-1/4", 310 mm

8-Ohms

400 Watts

319 Hz

280 Hz - 6 kHz

97 dB (2.83V/1M)

50 oz.

1.97”, 50 mm

Thiele & Small Parameters

Resonant Frequency (Fs)

DC resistance (Re)

Coil Inductance at Fs (Lces)

Mechanical Q (Qms)

Electromagnetic Q (Qes)

Total Q (Qts)

Compliance Equivalent Volume (Vas)

Mechanical Compliance of Suspension (Cms)

BL Product (BL)

Diaphragm Mass (Mmd)

Maximum Linear Excursion (Xmax)

Surface Area of Cone (Sd)

319 Hz

6.8 Ohms

5.72

2.88

1.91

1.179 mH

4.0mm

Mounting Information

Recommended Enclosure Volume

Sealed

Vented

Overall Diameter

Cut Out Diameter

Front Sealing Gasket

Rear Sealing Gasket

Mounting Holes Diameter

Mounting Depth

ft , 28.3-59.5 liters

12-1/4”, 310 mm

fitted as standard

5/16” x 3/8” , 7 mm x 9 mm

4-9/16”, 116 mm

1.0-2.1

11-1/16”, 281 mm

Materials of Construction

Aluminum voice coil

Polyimide former

Ferrite magnet

Vented and extended core

Stamped steel basket

Paper cone

Cloth surround

Solid composition paper dust cap

Earthquake EQ12S8 Pro Audio Series

Sound That Will Move You.

Earthquake Sound Corporation

2727 McCone Avenue • Hayward, CA94545 • phone: 800-576-7944

fax: 510-732-1095 • www.earthquakesound.com
