EarthQuake EQ8 Bedienungsanleitung

Specification

Nominal Basket Diameter

Nominal Impedance

Power Rating

Resonance

Usable Frequency Range

Sensitivity

Magnet Weight

Voice Coil Diameter

8", 203.2mm

4-Ohms

80 Watts

68Hz ±15%

68Hz - 10kHz

97 dB

43.7 oz.

2" 50.8mm

Thiele & Small Parameters

Resonant Frequency (fo)

DC resistance (Re)

Coil Inductance (Le)

Mechanical Q (Qms)

Electromagnetic Q (Qes)

Total Q (Qts)

Compliance Equivalent Volume (Vas)

Mechanical Compliance of Suspension (Cms)

BL Product (BL)

Diaphragm Mass (Mmd)

Maximum Linear Excursion (Xmax)

Surface Area of Cone (Sd)

87.763 Hz

3.800 Ohms

272.716 mH

6.324

0.330

0.313

21.004 liters/ft3

316.733mm/N

8.002 T-M

16.843 grams

4 mm

218.424 sqM

Mounting Information

Recommended Enclosure Volume

Sealed

Vented

Overall Diameter

Cut Out Diameter

Front Sealing Gasket

Rear Sealing Gasket

Mounting Holes Diameter

Depth

liters/ ft3

liters/ ft3

8 6/25", 209.5mm

7 2/25", 180mm

fitted as standard

fitted as standard

3 51/100", 89.3mm

Materials of Construction

Copper voice coil

Polyimide former

Ferrite magnet

Vented and extended core

Stamped steel basket

Paper cone

Cloth surround

Solid composition paper dust cap

Earthquake EQ8 Pro Audio Series

Sound That Will Move You.

Earthquake Sound Corporation

2727 McCone Avenue • Hayward, CA 94545 • phone: 800-576-7944

fax: 510-732-1095 • www.earthquakesound.com

.19" x .35", 5 x 9mm

8 6/25", 209.5mm

3 51/100"

89.3mm

7 2/25", 180mm
