EarthQuake EQ6S8 Bedienungsanleitung

Specification

Nominal Basket Diameter

Nominal Impedance

Power Rating

Resonance

Usable Frequency Range

Sensitivity

Magnet Weight

Voice Coil Diameter

6-5/8", 169.5mm

8-Ohms

60 Watts

377Hz

377Hz - 5kHz

93.2

37.8 oz.

1 3/8", 30.5mm

Thiele & Small Parameters

Resonant Frequency (fs)

DC resistance (Re)

Coil Inductance (Le)

Mechanical Q (Qms)

Electromagnetic Q (Qes)

Total Q (Qts)

Compliance Equivalent Volume (Vas)

Mechanical Compliance of Suspension (Cms)

BL Product (BL)

Diaphragm Mass (Mmd)

Maximum Linear Excursion (Xmax)

Surface Area of Cone (Sd)

377.331Hz ±15%

6.5 Ohms

278.353mH @ 1kHz

4.122

1.720

1.214

436.075mLtr/0.015 ft3

16.905mm/N

9.711 T-M

9.624 grams

0.2mm

134.782 sqM

Mounting Information

Recommended Enclosure Volume

Sealed

Vented

Overall Diameter

Cut Out Diameter

Front Sealing Gasket

Rear Sealing Gasket

Mounting Holes Diameter

Depth

6-5/8", 169.5mm

5-5/8", 142mm

fitted as standard

0.27" x 0.21" , 7.0mm x 5.5mm

2-7/8", 71.7mm

Materials of Construction

Copper voice coil

Polyimide former

Ferrite magnet

Vented and extended core

Stamped steel basket

Paper cone

Cloth surround

Solid composition paper dust cap

Earthquake EQ6S8 Pro Audio Series

20 Hz 50 100 200 500 1K 2K 5K 10K 20K

dBSPL

100

110 Ohm

Sound That Will Move You

Earthquake Sound Corporation

2727 McCone Avenue • Hayward, CA 94545 • phone: 800-576-7944

fax: 510-732-1095 • www.earthquakesound.com

SPL vs Freq
