War Bird II

Remote Control Helicopter

User Guide

HELICOPTER LAYOUT

Stabilizer

Tail

Rotor

Landing Skid

Main Rotor

Blade Main

Rotor Blade

AC Adaptor Plug

Repair Kit

Contents

Main Blade A

Main Blade B

Tail Blade C

Power

Switch

Throttle

Stick

Trim Control

Switch

Direction

Joystick

Power Indicator

Missile Light

Switch

CONTROLLER LAYOUT

Connecting Shaft

AC Adaptor Socket

Charging

Wire

male

Helicopter

Socket

ON/OFF

Switch

ON/OFF and charging

located on the left hand side

of chopper.

Congratulations on your new EXRCTM purchase! EXRCTM pilots experience

ight and excellence in the look and feel of our

products while commanding the skies. Now that you are an honorary EXRCTM

pilot, we recommend reading through this manual thoroughly before

ight tips, safety

precautions, and care instructions to keep your EXRCTM helicopter in tip-top

ight missions. Just follow the instructions, enjoy your

EXRCTM helicopter to the fullest, and command the skies.

BATTERY INSTALLATION & CHARGING

Installing Batteries in the Remote Control:

1. Using a Phillips-head screwdriver, remove the screw from the battery

compartment cover.

2. Insert 6 AA batteries, making sure to follow the battery polarity (+ and -)

drawing on product.

3. Replace the battery compartment cover and secure with the screw.

4. Turn on the remote. If the batteries are properly installed, the Red LED

light will blink. If the Red LED does not come on when you turn the

remote on, remove the batteries and reinstall. Some brands of batteries

have small size variations that can impact the connection.

Charging the Helicopter:

1. Turn the helicopter power OFF.

2. Disable the connection between the Charging Wire

(male) and the Helicopter Socket (female).

3. Plug the Charging Wire (male) into the AC Socket

(female).

4. Plug the AC Adaptor into the wall.

5. Charging requires approximately 120

ight.

when

charging. When the product is fully charged,

the LED will turn on. When

fully charged unplug the AC

Adaptor from the wall; disconnect the

Charging Wire from the AC Adaptor

Socket.

7. Reconnect the Charging Wire

ight.

y until the circuit between the Charging

Wire and Helicopter Socket is closed and Helicopter Power is turned back ON.

FLYING YOUR HELICOPTER

GETTING STARTED

•Switch the helicopter’s ON/OFF switch to the ON position. The LED lights

will turn on.

•Place the helicopter on the ground with the tail pointed toward you and

the nose facing away from you.

ying.

y if the helicopter has become damaged in any way.

y the helicopter around another person or animal.

OPERATING YOUR HELICOPTER

LEFT joystick - Slowly press UP on the Left joystick to increase the speed of

the rotor blades to cause the helicopter to ascend into the air. Slowly release

the Left joystick to cause the helicopter to descend.

AC Wall Unit

AC Adaptor Wire

AC Adaptor Socket

Switch

Charging Wire male

Helicopter

Charging Wire

Helicopter

Socket

Helicopter

Socket

Switch

RIGHT joystick - Keep the helicopter at a steady height. Press the RIGHT joy-

stick to the left to turn the helicopter counterclockwise. Press the RIGHT joystick

to the RIGHT to turn the helicopter clockwise. Adjust the trim to avoid spins.

Move the Right joystick up or down to move the helicopter forward or

backward.

Trimming Helicopter/Direction Control

Located underneath the RIGHT joystick is the Trim Control Switch. When the

y straight...

1. Counterclockwise Rotation - when the helicopter is spinning

counterclockwise, press the trim button on the right side. (See Diagram A)

2. Clockwise Rotation - when the helicopter is spinning clockwise, press the

trim button on the left side. (See Diagram B)

Diagram A

Trim Switch

Diagram B

Trim Switch

FLIGHT CONDITIONS

ight conditions

are optimal before launch.

•This chopper was built for outdoor terrain only with minimal wind

conditions. Heavy wind conditions can be to strong for this chopper

resulting in a“Mayday” situation.

ight to be at least 10 x 15 x 10 ft.

CONTROL TIPS

•It is best to start with both joysticks on the remote control in the middle

position. Do not immediately push into extreme positions. Instead start

by gently easing the joystick into the direction you would like to go.

ight EXRCTM recommends focusing on learning to control

rst. Try to keep the helicopter at a constant

3-foot altitude before attempting to learn directional control. After you

have mastered the throttle joystick, then start to practice turning with the

directional joystick.

SAFETY TIPS

Read through the entire instruction manual, before attempting to pilot your

helicopter.

•This product is intended for outdoor use, and works best outdoors. We do

not recommend using the product indoors.

y your helicopter in a cluttered space. This helicopter

was intended for obstacle free wide area spaces.

•Make sure all people and animals are 3-5 feet from the helicopter before

ying it.

y/land/or

crash anywhere on or near any other people or animals.

•The rotating parts on the helicopter could lead to injury. Never put any

body part including the hands and face, close to the rotating parts. Only

operate this product standing, as it allows for quick movement away from

the helicopter if necessary.

•Never operate the helicopter using parts that are altered in shape or

damaged in any form.

•Make sure you use new or fully charged batteries in the controller.

•Do not try to crash or drop the helicopter, as it may cause damage.

TROUBLESHOOTING

For best results, do not use batteries with power strip indicators (such as

Duracell Ultra Power batteries and Duracell Ultra Advanced with Powercheck).

Should you wish to continue to use these batteries, please be sure that all

power strips are facing forward when placed in the battery compartment.

In some cases, it may also help to remove, reinsert and push the batteries

forward ensuring proper contacts are being made. If batteries have been

installed correctly the Red LED light on the remote control will begin to blink

once you turn the remote ON/OFF switch to the ON position.

Set the ON/OFF Switch to the ON

position.

Recharge the helicopter battery.

If this does not work, replace

the batteries in the remote and

fresh batteries.

Helicopter sud-

denly stops and

ight

or seems to have

weak performance

Weak battery

power

Recharge the helicopter battery.

If this does not work, replace

the batteries in the remote and

fresh batteries.

Propellers are not

moving

Helicopter is

Weak battery

power

Batteries are not

making contact

with battery leads

on the remote

Interference of

another remote

controlled device

Remove and reinstall the batteries

being certain they are installed in the

right direction and making proper

contact with the battery leads.

Avoid all other remote controlled

devices running on the same

channel/frequency.

Remote is not

turning on

Loss of control

Helicopter

spinning out of

control

Incorrect trim

adjustment

Adjust the trim as shown above

nd the proper adjustment.

Cause Correction

Helicopter is not

synced with the

remote control

Press throttle all the way up and all

the way down to sync. Slowly move

the throttle up and chopper will

begin to ascend.

Problem

Helicopter is

not responding

to remote

CARE & HANDLING

• Do not submerge in water or other liquids.

• Do not disassemble the product for any reason.

• Do not expose to extreme temperatures.

• Do not drop, throw, smash or otherwise cause physical shock.

• Clean using only a slightly damp cloth.

• Do not use cleaners with chemical agents.

• Do not short-circuit the battery terminals.

CAUTION – Battery Safety Information

• Non-rechargeable batteries are not to be recharged

• Rechargeable batteries must be removed before recharging

• Rechargeable batteries should only be recharged under adult supervision

• Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries

• Exhausted batteries are to be removed

• Do not mix old and new batteries

re; batteries may explode or leak

• If this product will not be used for an extended period, remove batteries from the

product

• The supply terminals are not to be short-circuited

• Batteries are to be inserted with correct polarity

• Clean the battery contacts and also those of the product prior to battery installation

• As always, dispose of batteries in an eco-friendly manner

FCC Part 15 Compliance

cations not expressly approved by the party responsible for compliance could void the user’s authority to

operate the product.”

AND

2. “NOTE: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

product generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If the product does cause harmful interference to radio or television reception, which can be determined by

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the product and receiver.

erent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Product replacement policy only covers normal wear and tear when the product is used as directed. Normal

wear and tear does not include damage caused by crashes, collisions, or any use other than directed.

Distributed by EB Brands

Hazleton, PA 18202

www.goexrc.com

service@EBExcalibur.com

Distributed in the United Kingdom by:

EB Brands UK, Worcester WR4 9FA

Actual product may differ slightly from photograph.
