User Manual

BR-6641 User Manual

Table of Contents

Chapter1 Quick Start ....................................................................................................4

1.1 Preparation ...............................................................................................................4

1.2 Access to the Web-based UI ....................................................................................6

1.3 BR-6641 Web-based UI Overview............................................................................8

1.4 How to use BR-6641 Web-based UI.......................................................................10

1.4.1 BR-6641 Operating Menu..........................................................................10

1.4.2 BR-6641 Rule/Filter/Policy Table............................................................... 11

Chapter 2 System........................................................................................................13

2.1 Summary.................................................................................................................14

2.2 Traffic Statistics .......................................................................................................16

2.3 Diagnostic Tools......................................................................................................17

2.4 Date&Time ..............................................................................................................20

2.4.1 Date&Time Setting.....................................................................................20

2.4.2 Busyhour Setting .......................................................................................21

2.5 Administration .........................................................................................................22

Chapter3 Network .......................................................................................................25

3.1 WAN Setting............................................................................................................26

3.1.1 Standard Mode ..........................................................................................28

3.1.2 DHCP Mode...............................................................................................31

3.1.3 PPPoE Mode .............................................................................................33

3.1.4 PPTP Mode ...............................................................................................35

3.1.5 Advanced Mode.........................................................................................37

3.2 LAN Setting.............................................................................................................39

3.3 DHCP Setting..........................................................................................................42

3.4 Host Names ............................................................................................................45

3.5 Service Names........................................................................................................47

3.6 IP Grouping.............................................................................................................49

3.7 Service Grouping ....................................................................................................51

Chapter 4 Service........................................................................................................53

4.1 Firewall....................................................................................................................54

4.2 Auto Routing ...........................................................................................................57

4.3 Virtual Server ..........................................................................................................60

BR-6641 User Manual

4.4 QoS.........................................................................................................................62

4.5 Per IP Max Connection ...........................................................................................66

4.6 Per IP Max Rate Control .........................................................................................68

4.7 Multihoming.............................................................................................................70

4.8 Internal DNS ...........................................................................................................75

4.9 SNMP......................................................................................................................77

4.10 UPnP.....................................................................................................................78

Chapter 5 Log..............................................................................................................79

5.1 View ........................................................................................................................80

5.2 Control ....................................................................................................................81

5.3 Notification ..............................................................................................................84

BR-6641 User Manual

publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or

translated into any language or computer language, in any form or by any means, electronic,

mechanical, magnetic,optical, chemical, manual or otherwise, without the prior written

permission of this company.

This company makes no representations or warranties, either expressed or implied, with

respect to the contents hereof and specifically disclaims any warranties, merchantability or

fitness for any particular purpose. Any software described in this manual is sold or licensed

"as is". Should the programs prove defective following their purchase, the buyer (and not

this company, its distributor, or its dealer) assumes the entire cost of all necessary servicing,

repair, and any incidental or consequential damages resulting from any defect in the

software. Further, this company reserves the right to revise this publication and to make

changes from time to time in the contents hereof without obligation to notify any person of

such revision or changes.

The product you have purchased and the setup screen may appear slightly different

from those shown in this QIG. For more detailed information about this product, please refer

to the User's Manual on the CD-ROM.The software and specifications subject to change

including all brand and product names mentioned in this manual are trademarks and/or

registeredtrademarks of their respective holders.

Linux Open Source Code

Certain Edimax products include software code developed by third parties,

including software code subject to the GNU General Public License ("GPL") or GNU

Lesser General Public License ("LGPL"). Please see the GNU (www.gnu.org) and

LPGL

(www.gnu.org) Web sites to view the terms of each license.

The GPL Code and LGPL Code used in Edimax products are distributed

without any warranty and are subject to the copyrights of their authors. For details,

see the GPL Code and LGPL Code licenses. You can download the firmware-files at

http://www.edimax.com under "Download" page.

BR-6641 User Manual

Chapter1 Quick Start

At the first time using the product of BR-6641, you may confronted with

complicated settings which prevents you from starting well. This chapter will

explain the basic functionalities of BR-6641 and how to operate and configure the

system.It will also cover related subjects in network structures and hardware

installation which will help you during your setup of BR-6641.

1.1 Preparation

Before you get started, there are few things you need to know:

The position of the BR-6641 LAN Port: It has five network interfaces, the last port is

LAN Port which is marked on the machine.

The default IP address for LAN interface is 192.168.2.1

Your IP addresses for computers in the LAN should be changed to

192.168.2.2 (or 192.168.2.x) in order to avoid conflicts with the default LAN

port.

Connect your computers in the LAN to the BR-6641 with a cross-over cable,

which is a standard attachment.

To access the web-based administration UI, open http://192.168.2.1/ in your

Internet Explorer 6.0.

The default password for the administrator account is “1234”, and “5678” for

the monitor account. We strongly recommend you to modify the passwords at

the first time you log into the web-based UI. It is also a wise idea to write

down your changed passwords and keep them in a safe place in case you

forget them.

Check your network environment carefully before installing BR-6641. A

well-designed network environment with the necessary information such as

your network structure, IP addresses, and network segments information will

BR-6641 User Manual

help you complete the setup of BR-6641 parameters.

BR-6641 uses a web-based management user interface (Web-based UI).

Due to internal design constraints, you have to use MS Internet Explorer 6.0

(IE 6.0), or higher to access the Web-based UI. A screen resolution of

800x600 or higher is recommended.

Use a cross-over cable to access BR-6641 Web-based UI from the LAN port.

BR-6641 is shipped with two types of network cable in the box; one is a

cross-over and the other is a straight cable. Please use the cross-over cable

to connect to the computer and LAN port of BR-6641, the LED of the plugged

in port will turn on when properly connected.

BR-6641 User Manual

1.2 Access to the Web-based UI

The Web-based UI enables you to easily perform every configuration task. Follow

the steps below to access the Web-based UI.

1. Connect your PC Ethernet LAN interface to LAN port of BR-6641 with a

cross-over cable. The default management LAN port of BR-6641 is LAN port.

2. After powering on BR-6641, the LED of LAN port will turn to orange. This

indicates that it is on-line.

3. Assign your PC Ethernet LAN interface with IP 192.168.2.2, subnet mask

255.255.255.0.

4. Check that the proxy setting of your IE browser is turned off, no proxy server

is required in order to access BR-6641 ’s Web-based UI. Open MS IE 6.0,

select Internet Option on the menu bar of Tools, click the Connection tab,

and then click LAN settings to open Local Area Network Settings dialog

box, under Proxy server, make sure proxy server is not selected.

5. In the URL of IE 6.0, type in http://192.168.2.1 to access the Web-based UI.

6. BR-6641 provides two types of user accounts:

Administrator - Has privileges to monitor and modify system parameters.

Monitor - Has privileges to monitor only.

BR-6641 allows up to 1 administrator and 1 monitor to access concurrently.

Default password for Administrator and Monitor are 1234 and 5678,

respectively. Please have your password change the first time you log in.

BR-6641 User Manual

Cancel the Proxy Setting

BR-6641 User Manual

1.3 BR-6641 Web-based UI Overview

After logging in, you will be able to start configuring or monitoring BR-6641

through the Web-based UI.

In order to help you to familiar with the basic operations, the explanations are as

follows:

The Web-based UI tasks are grouped into four categories. The categories are

located at the upper left-hand corner of Web-based UI task bar. These categories

cover all the configuration possibilities in BR-6641. The four categories are:

System

Network

Service

Log

In the later chapters, we will introduce the functions of these four categories. On

the first stage,you can login as Administrator in the Web-based UI and modify the

Administrator or Monitor password by performing the following: (1)Click System

and select Administration on task bar, (2) enter your new Administrator password

or Monitor password, after the system confirmation, using the new password next

time you log in.

What shall we do if we forget the new password?

If you forget your administrator password, use a Terminal (VT-100 compatible) to

establish the connection between PC RS - 232 series port and BR-6641 Console

interface, execute system reset to default.

Before you log into serial console, please complete following setting: Bits per

BR-6641 User Manual

second: 9600, Data bits: 8, Parity: None, Stop bits: 8, Flow control: None. The

serial console and Web-based UI use the same username and password pairs.

By default, the password of “Administrator” is 1234, and the password of “Monitor”

is 5678. If the password is changed via the Web-based UI, it will also be changed

in the serial console. In case you lose your password, you can use the username

“reset” and password “BR-6641_edimax” to log into serial console and reset the

system to default.

Open the IE browser to access the Web-based UI

Note: Please remember the changed password , otherwise it is not possible to

access the BR-6641 management interface.
